Side 1/8

CAUTION!

All accessories, switches, climate

controls panels, and especially air bag indicator

lights must be connected before cycling the

ignition. Also, do not remove the factory radio

with the key in the on position, or while the

vehicle is running.

AX-ADDCAM

I N S TA L L A T I O N I N S T R U C T I O N S

INTERFACE FEATURES

TOOLS REQUIRED

INTERFACE COMPONENTS

TABLE OF CONTENTS

Introduction............................................................2

Connections to be made .......................................2

Conﬁguring the AX-ADDCAM ............................. 3-5

Installing the AX-ADDCAM .....................................5

Programming the AX-ADDCAM .............................6

Connector pin-out (20-pin) ..................................7

AX-ADDCAM

• (4) Camera inputs

• Programmable 12V 5-amp switched output (conﬁgured through the Axxess Updater program)

• Reverse signal trigger generated via CAN bus communication of the vehicle

• Turn signal trigger generated via CAN bus communication of the vehicle

• (4) Programmable camera control wires (conﬁgured through the Axxess Updater program)

• Can also be manually controlled, and used along with an aftermarket radio

• VSS (Vehicle Speed Sense) input and output

• Micro “B” USB updatable

• Wire cutter • Crimp tool • Solder gun • Tape

• Connectors (example: butt-connectors, bell caps, etc.)

• AX-ADDCAM interface

• AX-ADDCAM harness

INTRODUCTION CONNECTIONS TO BE MADE

The Axxess AX-ADDCAM interface is a camera switching interface that will provide up to (3)

additional camera inputs to the factory radio, while still retaining the factory camera. With this

interface a front camera, and also side cameras can be added to the factory radio. The cameras

function automatically*, no human interaction required, unless desired to do so. Axxess has also

created a line of vehicle speciﬁc “Plug & Play” harnesses for the AX-ADDCAM. These harnesses must

be used along with the AX-ADDCAM. The AX-ADDCAM can also be used if the factory system does

not originally come equipped with a backup camera, adding up to (4) cameras in this instance. In

addition, the AX-ADDCAM can be used along with an aftermarket radio as well. Pending that the

aftermarket radio has an input designated for a backup camera

* Only applicable vehicles listed in the drop down menu in the Axxess Updater program will

retain this feature.

Note:

Some vehicles may not have the turn signal, and/or reverse signal available on the vehicles

CAN-bus. For vehicles that do not have those signals available, or when an aftermarket radio will be

used instead of the factory radio, the interface will need to be manually controlled by analog triggers.

12-volt switched output

The wire labeled “Camera 12V” will be used in applications where a 12-volt switched Red

output is required. In the Axxess Updater there are two options for this feature, “CAN

Detection”, or “Camera Active”. If an aftermarket radio will be used instead of a factory radio,

this wire must be connected to the wire designated for a reverse trigger

• Will provide a 12-volt switched output when the interface detects a CAN bus Accessory Out:

signal. Pending that the vehicle is supported under vehicle selection.

• Camera Active: Will provide a 12-volt switched output if a camera has been activated.

Camera input/output

The RCA jacks labeled “Camera 1 – 4” are the camera inputs. The RCA jack labeled “Camera

output” will go to the factory radio (or aftermarket radio). Camera 1 should only be used for a

backup camera as it takes priority over the other cameras. Camera 2 and 3 can be used for either

a left side camera, or a right side camera, as they are programmable within the Axxess Updater

program. Camera 4 is only for use with a front camera due to how the camera switching functions.

Analog control wires

(available with the “Plug & Play” harness)

There are (4) control wires for activating the cameras manually. The control wires can be

conﬁgured in the Axxess Updater for either a negative or positive trigger. The control wires can

also be assigned to any camera

VSS (vehicle speed sense)

(available with the “Plug & Play” harness)

The AX-ADDCAM will generate a VSS signal for applicable vehicles listed in the drop down menu in

the Axxess Updater. Pending that the vehicles CAN bus has that signal available. For vehicles that

do not have that signal available, the VSS wire will need to be manually wired to the vehicle. But

only if that feature is required.

• Blue/Green - VSS in.

• - VSS out.Green/Blue
