AXAC-MZ2

I N S TA L L AT I O N I N S T R U C T I O N S

ATTENTION: With the key out of the

ignition, disconnect the negative battery

terminal before installing this product.

Ensure that all installation connections,

especially the air bag indicator lights, are

plugged in before reconnecting the battery

or cycling the ignition to test this product.

NOTE: Refer also to the instructions

included with the aftermarket accessory

before installing this device.

INTERFACE FEATURES

TOOLS REQUIRED

INTERFACE COMPONENTS

REQUIRED ITEMS

TABLE OF CONTENTS

Introduction............................................................2

Conﬁguration .....................................................2-4

Connections ............................................................5

Installation .............................................................6

Programming .........................................................6

• (4) Camera inputs

•

Reverse signal trigger generated via CAN bus communication of the vehicle

•

Turn signal trigger generated via CAN bus communication of the vehicle

• (4) Programmable camera control wires

• Micro-B USB updatable

• Crimping tool and connectors, or solder gun,

solder, and heat shrink

• Tape • Wire cutter • Zip-ties

• AXAC-MZ2 interface

• AXAC-MZ2 interface harness

• AXAC-MZ2 vehicle harness (qty. 2)

• 18-pin T-harness

• 28-pin T-harness (cam harness)

Update Cable: AXUSB-MCBL (sold separately)

Axxess Updater Program

† With full color LCD screen

Mazda† Camera Interface with Pre-Wired Harness

2014-Up

APPLICATIONS

Mazda

CX-3 2016-Up

CX-9 2016-Up

Mazda 3 2014-Up

Note: Only compatible with NTSC cameras.

Visit AxxessInterfaces.com for more detailed information

about the product and up-to-date vehicle speciﬁc applications
