Side 1/4

AXAMP-CH4

I N S T A L L A T I O N I N S T R U C T I O N S

TOOLS & INSTALLATION ACCESSORIES REQUIRED

• Crimping tool and connectors, or solder gun,

solder, and heat shrink

• Tape

• Wire cutter

• Zip-ties

• Multimeter

TABLE OF CONTENTS

Installation & Installation Options 2 ........................

Adding Amp/Amps to a Factory System 3 .............

Troubleshooting.....................................................4

APPLICATIONS

Visit for current application listAxxessInterfaces.com

INTERFACE COMPONENTS

• AXAMP-CH4 interface

• AXAMP-CH4 interface harness

• AXAMP-CH4 vehicle T-harness

• Bass knob

Fits Chrysler Amplifier Integration Interface

2007-2020

www.MetraOnline.com

MetraOnline.com may be used to assist

with dash assembly instructions. Simply

enter your Year, Make, Model vehicle

into the vehicle fit guide and look for the

Dash Kit Installation Instructions.

INTERFACE FEATURES

• Designed for both amplified and non-amplified models

• Provides 6 channels of 5-volt RMS audio

• Channels 5 & 6 are non-fading full range output

• Includes plug-n-play harnessing

• Simple behind the radio installation

• Dual colored LED feedback

• Input voltage 50 watts per channel

• Amp on turn-on output is rated at 250mA

• 2 channel S/PDIF out (Fronts)

ATTENTION: With the key out of the ignition,

disconnect the negative battery terminal before

installing this product. Ensure that all installation

connections, especially the air bag indicator lights, are

plugged in before reconnecting the battery or cycling

the ignition to test this product.

NOTE: Refer also to the instructions included with the

aftermarket accessory before installing this device.

Adding a subwoofer to a factory system:

This feature offers the ability to add a subwoofer to a factory system, whether amplified or non-

amplified (Refer to Page 3)

Adding a full-range amp and subwoofer to a factory system:

This feature offers the ability to add a full-range amp and sub to a factory system, whether

amplified*or non-amplified. (Refer to )Page 3

* For amplified models the amp must be bypassed/unplugged. Use either Axxess AXABH-CH2 or

AXABH-CH4 (sold separately) to bypass the amp for best results.

Note: The interface provides a 12-volt 1-amp output to turn on aftermarket amp(s). If installing

multiple amps, an SPDT automotive relay will be required if the amp turn-on current of all amps

combined exceeds 1-amp. Use Metra part number E-123 (sold separately) for best results.

1. Disassemble the dash, unplug all connectors, and then remove the factory radio.*

2. AXAMP-CH4 vehicle T-harness Install the to the vehicle and make all necessary

connections, but leave the amp turn-on wire disconnected.

3. AXAMP-CH4 vehicle T-harness AXAMP-CH4 interface Plug the to the .

4. AXAMP-CH4 interface harness AXAMP-CH4 interface Plug the to the .

5. Connect the amp turn-on wire.

6. Adjust your aftermarket amplifier to a desired listening level.

* For dash disassembly instructions, refer to . Enter the year, make, metraonline.com

and model of the vehicle in the and find instructions under Metra Vehicle Fit Guide

Radio Install kits.

INSTALLATION OPTIONS INSTALLATION
