AXAMP-TY1
I N S T A L L A T I O N I N S T R U C T I O N S
AxxessInterfaces.com © COPYRIGHT 2025 METRA ELECTRONICS CORPORATION REV. 2/5/25 INSTAXAMP-TY1
INTERFACE FEATURES
TOOLS & INSTALLATION ACCESSORIES REQUIRED
• Crimping tool and connectors, or solder gun,
solder, and heat shrink
• Tape
• Wire cutter
• Zip-ties
• Multimeter
TABLE OF CONTENTS
Installation & Installation Options 2 ........................
Adding Amp(s) to a Factory System 3 ....................
Troubleshooting.....................................................4
APPLICATIONS
Visit for current application list
AxxessInterfaces.com
INTERFACE COMPONENTS
• AXAMP-TY1 Amplifier Integration interface
• AXAMP-TY1 interface harness
• AXAMP-TY1 vehicle T-harness
• Bass knob
Amplifier Integration Interface
Fits Toyota
Select Models
2001-2015
www.MetraOnline.com
ATTENTION: With the key out of the ignition,
disconnect the negative battery terminal before
installing this product. Ensure that all installation
connections, especially the air bag indicator lights, are
plugged in before reconnecting the battery or cycling
the ignition to test this product.
NOTE: Refer also to the instructions included with the
aftermarket accessory before installing this device.
• Designed for amplified models
• Provides 6 channels of 5-volt RMS audio
• Non-fading full range output (Channels 5 & 6)
• Includes plug-n-play harnessing
• Simple behind the radio installation
• No programming required
• Dual colored LED Display
• Input power handling 50 Watts per channel
• Amp turn-on trigger (DC) 250mA
• 2 channel S/PDIF out (Front)
For refer Dash Disassembly Instructions,
to Enter the year, make, metraonline.com.
and model of the vehicle in the Vehicle Fit
Guide Radio Install kits.for
Visit for more detailed AxxessInterfaces.com
information about the product and up-to-date
vehicle specific applications.
