Side 1/5

REV. 5/19/20

axxessinterfaces.com • metraonline.com

Axxess Integrate

Installation Instructions for AXBUCS-NI246V

INTERFACE FEATURES

• Pre-wired AXSWC harness (AXSWC sold separately)

• Retains the factory AUX-IN jack

• Retains the factory backup camera to an aftermarket radio*

• Includes the AXCSD-6V 12-volt to 6-volt converter

* Will not work with models equipped with an "All Around Camera" system

AXBUCS-NI246V

Nissan (with NAV) 2011-Up

INTERFACE COMPONENTS

• AXBUCS-NI246V harness • AXCSD-6V 12-volt to 6-volt converter

• Wire cutter • Crimping tool • Solder gun • Tape

• Connectors (example: butt connectors, bell caps, etc.)

TOOLS REQUIRED

CAUTION!

All accessories, switches, climate controls panels, and especially air bag indicator lights

must be connected before cycling the ignition. Also, do not remove the factory radio with the key in the

on position, or while the vehicle is running.

NISSAN

Altima 2013-Up

Cube

2011-2014*

Frontier 2013-Up*

Juke 2011-2014*

NV 2012-Up*

NV200 2012-Up*

Rogue (w/ Bose)

2012-2013*

Rogue 2011*

Sentra 2011-Up*

Titan 2013-2015*

Versa 2013-Up*

Xterra

2013-2015*

APPLICATIONS

* For use when retaining the OE backup camera only

REV. 5/19/20

axxessinterfaces.com • metraonline.com

Axxess Integrate

Installation Instructions for AXBUCS-NI246V

K PNOWLEDGE IS OWER

Enhance your installat ion and fabrica tion skills by

enrolling in the most cognized and spect ed re re

mobile electronics s chool in our industry.

Log ont o www.installerinstit ute.com or call

800-354-6782 for mo information a nd t ake st eps re

toward a bett er t omorrow.

Metra r ecommends MECP

certified technicians

Connections to be made

• Connect the wire with a ring terminal to chassis ground.Black

• Connect the wire of the AXCSD-6V wire to chassis ground.Black

• Connect the wire labeled "Camera Power 6V" to the wire Red Blue/Red

of the AXCSD-6V.

• Connect the wire to the reverse wire of the aftermarket radio, Green/Purple

and also to the wire of the AXCSD-6V.Blue/White

• For all models except the Cube / Rogue, if retaining the factory AUX-IN jack,

connect the & RCA jacks to the AUX input.Red White

• Connect the Yellow RCA jack to the rear camera input of the aftermarket radio

12-pin pre-wired AXSWC harness:

This harness is to be used along with the optional AXSWC (not included) to

retain steering wheel audio controls. Please refer to the AXSWC instructions

for radio connections and programming.

Note: Disregard the harness that comes with the AXSWC.

• Connect the unlabeled wire to the accessory wire.Red
