Side 1/8

AXDI-CH13

I N S T A L L A T I O N I N S T R U C T I O N S

Product Info

INTERFACE FEATURES

INTERFACE COMPONENTS

TOOLS & INSTALLATION ACCESSORIES REQUIRED

• Crimping tool and connectors, or solder gun,

solder, and heat shrink • Tape • Wire cutter

• Zip ties

TABLE OF CONTENTS

Connections .........................................................2-3

Installation .............................................................3

Programming .........................................................3

Chrysler CAN Data Interface 2004-Up

APPLICATIONS

See inside front cover

• Provides accessory power (12-volt 10-amp)

• Retains R.A.P. (retained accessory power)

• Provides NAV outputs (parking brake, reverse, and speed sense)

• Prewired AXSWC harness (AXSWC sold separately)

• Can be used in both ampliﬁed and non-ampliﬁed models

• Retains balance and fade (non-ampliﬁed models only)

• Micro-B USB updatable

• AXDI-CH13 interface

• LD-BX-CH1 harness

• LD-BX-CH2 harness

From the LD-BX-CH1 OR LD-BX-CH2 harness to the aftermarket radio:

• Connect the wire to the ground wire.Black

• Connect the Yellow wire to the battery wire.

• Connect the wire to the accessory wire.Red

If installing an AXSWC (sold separately), there will be an accessory wire there to Note:

connect as well.

• If the aftermarket radio has an illumination wire, connect the Orange wire to it.

• If the vehicle is equipped with a factory ampliﬁer, connect the Blue/White wire to the amp

turn on wire. This wire must be connected to hear sound from the factory ampliﬁer.

• Connect the wire to the power antenna wire.Blue

• Connect the wire to the right front positive speaker output.Gray

• Connect the Gray/Black wire to the right front negative speaker output.

• Connect the wire to the left front positive speaker output.White

• Connect the wire to the left front negative speaker output.White/Black

• Connect the wire to the left rear positive speaker output.Green

• Connect the wire to the left rear negative speaker output.Green/Black

• Connect the wire to the right rear positive speaker output.Purple

• Connect the wire to the right rear negative speaker output.Purple/Black

Continued on the next page

APPLICATIONS CONNECTIONS

CHRYSLER

300 2005-2007

Aspen 2007

PT Cruiser 2006-2010

DODGE

Caliber 2007-2008

Charger 2006-2007

Dakota 2005-2007

Durango 2004-2007

Magnum 2005-2007

Ram 2500/3500 2009

Ram 2006-2008

Ram Chassis Cab 2006-2010

JEEP

Commander 2006-2007

Compass 2007-2008

Grand Cherokee 2005-2007

Patriot 2007-2008

MITSUBISHI

Raider 2006-2007

CHRYSLER

200 2011-2014

300 2008-2010

Aspen 2008-2009

Sebring 2007-2010

Town & Country 2008-2017

DODGE

Avenger 2008-2014

Caliber 2009-2012

Grand Caravan 2008-up

Challenger 2008-2014

Charger 2008-2010

Dakota 2008-2011

DODGE (CONT)

Durango 2008-2013

Journey 2009-2010

Magnum 2008-2009

Nitro 2007-2011

Ram 2010-2011

Ram 1500 2009

Ram Chassis Cab 2011

JEEP

Commander 2008-2010

Compass 2009-2017.5

Grand Cherokee 2008-2013

Liberty 2008-2012

JEEP (CONT)

Patriot 2009-2017

Wrangler 2007-2017

Wrangler (JK) 2018

Wrangler Unlimited 2007-2017

MITSUBISHI

Raider 2008-2009

RAM

1500/2500/3500 2012

Chassis Cab 2012

C/V Tradesman 2012-2015

Routan 2009-2013

Applications below use the LD-BX-CH1 harness:

Applications below use the LD-BX-CH2 harness:
