AXDIS-FD1
I N S TA L L A T I O N I N S T R U C T I O N S
AxxessInterfaces.com © COPYRIGHT 2019 METRA ELECTRONICS CORPORATION REV. 11/4/19 INSTAXDIS-FD1
Product Info
INTERFACE FEATURES
INTERFACE COMPONENTS
TOOLS REQUIRED
• Wire cutter • Crimp tool • Solder gun • Tape • Connectors (example: butt-connectors, bell caps, etc.) • Small flat-blade screwdriver
TABLE OF CONTENTS
Connections ........................................................ 3-5
- For models without a Sony/THX amplifier........4
- For models with a Sony/THX amplifier .............4
- 3.5mm jack steering wheel control retention ..5
Installation .............................................................5
Programming .........................................................6
Adjustments ...........................................................6
Extra features .........................................................7
Steering wheel control settings ......................7-10
- L.E.D. feedback ....................................................7
- Changing radio type ...........................................8
- Remapping ..........................................................8
- Dual assignment instructions .......................9-10
Troubleshooting ................................................... 10
Ford Data Interface with SWC 2007-Up
• Provides accessory power (12-volt 10-amp)
• Retains R.A.P. (retained accessory power)
• Provides NAV outputs (parking brake, reverse, speed sense)
•
Retains audio controls on the steering wheel
• Retains RSE (rear seat entertainment)
• Retains SAT (satellite radio)
• Retains SYNC
• Retains the factory AUX-IN jack
• Can be used in both non-amplified and amplified models
(including Sony/THX)
• Retains balance and fade (excluding Sony/THX)
• Micro-B USB updatable
• AXDIS-FD1 interface
• AXDIS-FD1 harness
• 16-pin harness with stripped leads
• Female 3.5mm connector with stripped leads
APPLICATIONS
See inside front cover
2
APPLICATIONS
FORD
Econoline (w/ CD) 2009-up
Edge 2007-2010
Escape 2008-2012
Expedition 2007-2014
Explorer (w/ NAV) 2009-2010
FORD (CONT)
Explorer Sport Trac
(w/ NAV) 2009-2010
F-150 * 2009-2012
F-150 STX/FX2 base/XLT base
2013
F-150 STX/XLT base 2014
FORD (CONT)
F-250/350/450/550 2011-2012
F-250/350/450/550 XLT, XL
(w/ CD) 2013-2016
F-650/750 (w/ CD) 2016-up
Focus 2008-2011
Fusion 2010-2012
FORD (CONT)
Mustang 2009-2014
Taurus 2010-2012
LINCOLN
MKX 2007-2010
MKZ 2007-2009
Navigator 2007-2014
MAZDA
Tribute 2008-2011
MERCURY
Mariner 2008-2011
Milan 2010-2011
* XL models must be equipped with a CD player
