AXDIS-FD2

I N S TA L L A T I O N I N S T R U C T I O N S

Product Info

INTERFACE FEATURES

TOOLS & INSTALLATION ACCESSORIES REQUIRED

• Crimping tool and connectors, or solder gun,

solder, and heat shrink • Tape • Wire cutter

• Zip ties

TABLE OF CONTENTS

Connections .........................................................2-3

Installation .............................................................3

Programming .........................................................4

Extra features .........................................................4

Steering wheel control settings ........................5-7

- L.E.D. feedback ....................................................5

- Changing radio type ...........................................5

- Remapping ..........................................................6

- Dual assignment instructions ............................7

Troubleshooting .....................................................8

Ford Data Interface with SWC 2011-2019

APPLICATIONS

• Provides accessory power (12-volt 10-amp)

• Retains R.A.P. (retained accessory power)

• Provides NAV outputs (parking brake, reverse, speed sense)

• Retains audio controls on the steering wheel

• Retains SYNC

• Retains the factory AUX-IN jack

• Designed for non-ampliﬁed models

• Retains balance and fade

• Micro-B USB updatable

FORD

Edge 2011-2014

Escape 2013-2019

Explorer 2011-2015

F-150 (with a 4.2” screen) 2013-2014

Fiesta (without MyFord Touch) 2014-2019

Focus (without MyFord Touch) 2012-2014*

Transit Connect

(with AM/FM/CD/SYNC radio) 2014-2018

* For models without SYNC, the AXSWC (sold separately) will be required to retain the audio buttons on the steering wheel.

INTERFACE COMPONENTS

• AXDIS-FD2 interface

• AXDIS-FD2 harness

• 16-pin harness

• 3.5mm adapter

CONNECTIONS

From the 16-pin harness to the aftermarket radio, connect the:

• wire to the accessory wire.Red

If installing an AX-LCD (sold separately), there will be an accessory wire there to Note:

connect as well.

• Orange/White wire to the illumination wire (if applicable).

• Brown wire to the mute wire, only if equipped with SYNC (if applicable).

If the mute wire is not connected, the radio will turn off when SYNC is activated.Note:

• wire to the right front positive speaker output.Gray

• Gray/Black wire to the right front negative speaker output.

• White wire to the left front positive speaker output.

• White/Black wire to the left front negative speaker output.

The following (3) wires are only for multimedia/navigation radios that require these wires.

• wire to the VSS/speed sense wire.Blue/Pink

• Green/Purple wire to the reverse wire.

• Light Green wire to the parking brake wire

• Tape off and disregard the following (5) wires, they will not be used in this application:

Blue/White Green Green/Black Purple Purple/Black, , , , .

From the AXDIS-FD2 harness to the aftermarket radio, connect the:

• wire to the ground wire.Black

• Yellow wire to the battery wire.

• wire to the power antenna wire.Blue

• Green wire to the left rear positive speaker output.

• Green/Black wire to the left rear negative speaker output.

• wire to the right rear positive speaker output.Purple

• wire to the right rear negative output.Purple/Black

• If the vehicle is equipped with SYNC, connect the and RCA jacks labeled “RSE/Red White

SYNC/SAT” to the audio AUX-IN jacks.

• If the vehicle is equipped without SYNC, connect the and RCA jacks labeled “FROM Red White

3.5” to the audio AUX-IN jacks.

Excluding F-150.Note:

• The DIN jack is to be used with the optional AX-LCD (sold separately) to retain SYNC information.

• wire to accessory power.Red

Continue to 3.5mm jack steering wheel control retention
