Side 1/24
AXDIS-TY1
I N S TA L L A T I O N I N S T R U C T I O N S
AxxessInterfaces.com © COPYRIGHT 2024 METRA ELECTRONICS CORPORATION REV. 4/22/24 INSTAXDIS-TY1
ATTENTION: With the key out of the ignition, disconnect
the negative battery terminal before installing this product.
Ensure that all installation connections, especially the air
bag indicator lights, are plugged in before reconnecting the
battery or cycling the ignition to test this product.
NOTE: Refer also to the instructions included with the
aftermarket accessory before installing this device.
INTERFACE FEATURES
INTERFACE COMPONENTS
• Wire cutter
• Crimp tool
• Solder gun
• Tape
• Small flat-blade screwdriver
• Connectors (example: butt-
connectors, bell caps, etc.)
TABLE OF CONTENTS
Applications 2 ...........................................................
Connections:
Non-Amplified Models:
LD-TYNOAMP 3 .................
Amplified Models: LD-BX-TY2
4 .............................
3.5mm Jack Steering Wheel Control Retention
....5
Installing the AXDIS-TY1 5 ........................................
Programming the AXDIS-TY1 6 ................................
Audio Level Adjustment 6 .......................................
Steering Wheel Control Settings 7-10 .....................
LED Feedback 7 .......................................................
Changing Radio Type 8 ..........................................
Remapping the SWC Buttons 8-9 .........................
Dual Assignment Instructions
........................... 10
Troubleshooting....................................................11
Lexus/Toyota Interface with SWC 2002-2015
• AXDIS-TY1 interface
• AXDIS-TY1 harnesses (LD-TYNOAMP, LD-BX-TY2 AND LD-2NAVAMP)
• Female 3.5mm connector with stripped leads
Visit for more detailed information AxxessInterfaces.com
about the product and up-to-date vehicle specific applications.
• Designed for both amplified and non-amplified models
• Provides accessory power (12-volt 10-amp)
• Retains audio controls on the steering wheel
• Provides NAV outputs (parking brake, reverse)
• Retains the factory AUX-IN jack
• Retains balance on amplified models
(non-amplifed models will retain balance and fade)
• Micro-B USB updatable
APPLICATIONS (See Page 2)
Product Info
TOOLS REQUIRED
2
APPLICATIONS
LEXUS
ES Series 2007-2012 ...............................................................
ES Series (w/ multi disc) 2002-2006 .....................................
IS Series 2002-2005 ................................................................
RX Series 2004-2008 ...............................................................
TOYOTA
4-Runner 2003-2013 ..............................................................
Avalon 2011-2012 ...................................................................
(Camry) Solara 2004-2008 .....................................................
Camry (w/o nav) 2012-2013 ................................................
Camry.................................................................... 2007-2011
Corolla 2003-2011 ...................................................................
FJ Cruiser............................................................... 2011-2014
Highlander 2008-2013 ............................................................
Matrix 2005-2012 ....................................................................
Prius 3rd Gen (w/o nav) 2012-2015 ......................................
TOYOTA (CONT)
Plug-In (PHV) (w/o nav) 2012-2015 .....................................
Prius 2004-2011 ......................................................................
Rav-4 2004-2014.5 ....................................................................
Sequoia (w/o nav)............................................... 2013
Sequoia 2005-2012 .................................................................
Sienna 2004-2014 ...................................................................
Tacoma 2005-2013 .................................................................
Tundra 2006-2013 ...................................................................
Tundra (Double Cab) 2004-2005 ...........................................
Venza (w/ SD card based nav) 2013-2014 ...........................
Venza 2009-2012 ....................................................................
APPLICATIONS
