AXDSPH-CH3

I N S T A L L A T I O N I N S T R U C T I O N S

ATTENTION: With the key out of the ignition,

disconnect the negative battery terminal

before installing this product. Ensure that all

installation connections, especially the air

bag indicator lights, are plugged in before

reconnecting the battery or cycling the

ignition to test this product.

NOTE: Refer also to the instructions included

with the aftermarket accessory before

installing this device.

TABLE OF CONTENTS

Installation Options 2 ...............................................

Installation 2 .............................................................

20-Pin Harness Pinout...........................................3

Adding A Subwoofer To A Factory System 4 .........

Adding A Full-Range Amp and

Subwoofer To A Factory System 5 .......................

AX-DSP T-Harness

The is a basic and simple plug-n-play harness for Axxess T-harness

easy installation of the or (sold separately) for AXDSP-X AXDSP-L

vehicle specific applications. Most T-harnesses created by Axxess

will have an 8-pin harness, with the speaker wires pinned. If you are

installing a 4-channel amplifier with one of the , AXDSP interfaces

leave these connectors disconnected. The only reason for connecting

these harnesses together would be if the is being AXDSP interface

used for adding a subwoofer amplifier only. Some T-harnesses

require additional wiring and/or installation steps, see page 2.

Refer to page 3 for a pinout legend for the 20-pin harness, and also

additional wiring and notes.

APPLICATIONS

Visit for more detailed

AxxessInterfaces.com

information about the product and

up-to-date vehicle specific applications.

Visit or Metraonline.com AxxessInterfaces.com

for harness and interface options.

Visit

AxxessInterfaces.com

for current application list.

INSTALLATION OPTIONS INSTALLATION

Adding a subwoofer to a factory system:

The diagram on shows the connections that need to be made to add a subwoofer to the Page 4

factory system.

Note: RCA jacks sold separately.

Adding a full-range of amps and subwoofer to a factory system:

The diagram on shows the connections that need to be made to add: Subwoofer (RCA jacks Page 5

sold separately)

Amplifier (SPDT required) orrelay E-123

Additional Amp (RCA jacks sold separately).

Note: The interface provides a 12-volt 1-amp output to turn on aftermarket amp(s). If installing

multiple amps, an SPDT automotive relay will be required if the amp turn-on current of all amps

combined exceeds 1-amp. Use Metra part number (sold separately) for best results. E-123

1. Disassemble the dash, unplug all connectors, and then remove the factory radio.†

2. AXDSPH-CH3 vehicle T-harness Install the to the vehicle and make all necessary

connections, but leave the amp turn-on wire disconnected.

3. AXDSPH-CH3 vehicle T-harness AXDSPH-CH3 interface Plug the to the .

4. AXDSPH-CH3 interface harness AXDSPH-CH3 interface Plug the to the .

5. AXDSP-XL app Download the from the Google Play Store or Apple App store.

6. AXDSP-X AXDSP-L Refer to the or for tuning instructions.

† For dash disassembly instructions, refer to metraonline.com. Enter the year, make,

and model of the vehicle in the and find instructions under Metra Vehicle Fit Guide

Radio Install kits.
