Installation instructions for part AXRC-GM44

REV. 5/6/2020 INSTAXRC-GM44

Axxess Integrate

CAUTION!

All accessories, switches, climate controls panels, and

especially air bag indicator lights must be connected before cycling

the ignition. Also, do not remove the factory radio with the key in the

on position, or while the vehicle is running.

• Provides accessory power

(12-volt 10-amp)

• Retains R.A.P. (retained

accessory power)

•

Provides NAV outputs (parking

brake, reverse, and speed sense)

• Used in non-amplified

models, or when bypassing a

factory amplifier

•

Used in models without OnStar

• Retains all warning chimes

• High level speaker input

• Retains balance and fade

• Micro “B” USB updatable

INTERFACE FEATURES

• Wire cutter • Crimping tool • Tape • Solder gun

• Connectors (butt-connectors, bell caps, etc.)

TOOLS REQUIRED

APPLICATIONS

• AXRC-GM44 interface

• AXRC-GM44 harness

INTERFACE COMPONENTS

*Only for models with factory navigation.

Note: This interface will not retain OnStar.

CHEVROLET

Avalanche* 2012-2013

Express* 2013-2015

Malibu (with single color,

monochrome screen)

2013-2015

Malibu Limited (with single

color, monochrome screen)

2016

CHEVROLET (CONT)

Silverado* 2012-2013

Silverado 2500/3500* 2014

Suburban* 2012-2014

Tahoe* 2012-2014

Trax 2015-2016

GMC

Savana* 2013-2015

Sierra * 2012-2013

Sierra 2500/3500* 2014

Yukon / Yukon XL* 2012-2014

Connections to be made ........................................ 2

Installing the AXRC-GM44 3 .....................................

Initializing the AXRC-GM44 3 ...................................

Table of Contents

AXRC-GM44

From the AXRC-GM44 harness to the aftermarket radio:

• Connect the wire to the ground wire.Black

• Connect the Yellow wire to the battery wire.

• Connect the wire to the accessory wire.Red

• Tape off and disregard the wire, it will not be used in this application.Pink

• Connect the wire to the power antenna wire.Blue/White

• If the aftermarket radio has an illumination wire, connect the wire to it.Orange/White

• Connect the wire to the left front positive speaker output.White

• Connect the wire to the left front negative speaker output.White/Black

• Connect the wire to the right front positive speaker output.Gray

• Connect the wire to the right front negative speaker output.Gray/Black

• Connect the wire to the left rear positive speaker output.Green

• Connect the wire to the left rear negative speaker output.Green/Black

• Connect the wire to the right rear positive speaker output.Purple

• Connect the wire to the right rear negative speaker output.Purple/Black

The following (3) wires are only for multimedia/navigation radios that require these

wires.

• Connect the wire to the VSS/speed sense wire.Blue/Pink

• Connect the wire to the reverse wire.Green/Purple

• Connect the wire to the parking brake wire.Light Green

Connections to be made
