Side 1/2

AXRSEH-GL29

INSTALLATIO N INSTRUCTI O N S

REV. 4/20/20

Integrate • AxxessInterfaces.com

• Retains the A/V-IN jack (if applicable)

• Provides A/V output to the factory installed rear seat overhead

entertainment system *

• Designed for models that have a DVD player built into the factory radio

INTERFACE FEATURES

• Wire cutter • Crimping tool

• Connectors (example: butt-connectors, bell caps, etc.)

TOOLS REQUIRED

GM RSE A/V Harness 2007-Up

APPLICATIONS

• AXRSEH-GL29 harness

• Connect to the AXRSEH-GL29 harness to the wiring harness in the

vehicle located at the radio location.

INTERFACE COMPONENTS

CONNECTIONS TO BE MADE

INSTALLATION

BUICK

Enclave 2008-Up

Cadillac

Escalade 2007-2011

Escalade ESV 2007-2011

Escalade EXT 2007-2011

SRX 2007-2009

CHEVROLET

Avalanche 2007-2013∆

Equinox 2007-2009

Silverado 2500/3500 2014∆

Silverado (new body) 2007-2013∆

Suburban 2007-2014∆

Tahoe 2007-2014∆

Traverse 2009-Up

GMC

Acadia 2007-2016

Acadia Limited 2017

Sierra 2500/3500 2014∆

Sierra (new body) 2007-2013∆

Yukon/Yukon XL 2007-2014∆

HUMMER

H2 2008-2009

PONTIAC

Torrent 2007-2009

SATURN

Outlook 2007-2010

SUZUKI

XL-7 2007-2009

* Only applicable for models with a second row RSE

∆ For 2012-Up models with NAV use the AXRSEH-G2.

•

Connect the wire with a ring terminal to the chassis of the aftermarket radioBlack

• From the RCA jacks labeled “FROM REAR A/V INPUT” to the A/V input of the

aftermarket radio:

• Connect the Yellow RCA jack to the video in.

• Connect the and RCA jacks to the audio in.Red White

• From the RCA jacks labeled “TO OVERHEAD SCREEN” to the A/V output of the

aftermarket radio:

• Connect the Yellow RCA jack to the video out.

• Connect the and RCA jacks to the audio out.Red White
