AXSSO-GM2
I N S T A L L A T I O N I N S T R U C T I O N S
Patent #10844821, 11459994, 11493012
AxxessInterfaces.com © COPYRIGHT 2023 METRA ELECTRONICS CORPORATION REV. 10/6/23 INSTAXSSO-GM2
ATTENTION: With the key out of the ignition,
disconnect the negative battery terminal
before installing this product. Ensure that all
installation connections, especially the air
bag indicator lights, are plugged in before
reconnecting the battery or cycling the ignition
to test this product.
NOTE: Refer also to the instructions included
with the aftermarket radio.
INTERFACE FEATURES
INTRODUCTION
INTERFACE COMPONENTS
TOOLS & INSTALLATION ACCESSORIES REQUIRED
• Zip ties • Zip tie cutter
• GM battery terminal wrench
TABLE OF CONTENTS
Installation 2 .............................................................
GM Stop/Start Override Interface 2016-Up
• Allows the override of the STOP/START engine feature
• Can be used with either a factory or aftermarket radio
• No programming required
• Simple 2-wire setup
The AXSSO-GM2 is designed to disengage the STOP/START feature of the vehicle,
and keep that feature disengaged even after the key has been cycled. Simple
2-wire installation (ground and power to the battery) is all that is required to
install the interface in the vehicle. No programming required!
• AXSSO-GM2 interface • LD-GM1-SSO harness
• LD-GM2-SSO harness
APPLICATIONS
Buick
Enclave 2018 .......
Encore 2016-2018 .........
Envision 2016-2019 ......
LaCrosse 2017-2019 ......
Regal 2017-2018 ...........
Cadillac
CTS 2019 ...............
XT5 2017-2018 ...............
Chevrolet
Cruze 2017-2018 ...........
Equinox 2018-2019 .......
Malibu 2016-2017 .........
Chevrolet (Cont)
Traverse 2018 ......
Trax 2016-2018 .............
GMC
Acadia 2017-2018 .........
Terrain 2018-2019 .........
Yukon 2018 ..........
Buick
Enclave 2019 .......
Encore 2019 .........
Regal 2019 ...........
Cadillac
CT6 2019-2020 ...............
Escalade 2019-Up ......
Cadillac (Cont)
XT4 2019-Up ..............
XT5 2019 ...............
XTS 2019 ...............
Chevrolet
Corvette 2019 ......
Cruze 2019 ...........
Chevrolet (Cont)
Silverado.....2019-Up
Tahoe 2019-Up ..........
Traverse 2019-Up ......
Trax 2019-Up .............
GMC
Acadia 2019-Up ..........
LD-GM1-SSO applications LD-GM2-SSO applications
Product Info
2
INSTALLATION
+
+
+
+
6
SSO
INTERFACE
T-HARNESSES
(LD-GM1-SSO
OR LD-GM2-SSO)
4
5
(Figure shown for illustration purposes only. Actual vehicle and installation locations will differ)
1. Open the hood and locate the hood pin switch
harness underneath the hood latch.
2. Unplug the hood pin switch harness, then plug in
the appropriate harness.
3. Route the power and ground wires to the vehicles
battery.
4. Black Connect the wire to the negative terminal.
5. Connect Yellow wire to the positive terminal.
6.
Find a safe and secure spot for the water resistant
AXSSO-GM2 interface, away from any heat sources
and moving parts. With the wiring harness facing
downward, zip tie the interface securely.
7. The installation is now complete.
There are 2 T-harnesses to choose from.Note:
After install, if the check engine light Tech Tip!
appears, remove ground connection that was
made to the battery and splice into the Brown
wire on the vehicle side of the T-harness.
