AXTC-CH13

I N S T A L L A T I O N I N S T R U C T I O N S

INTERFACE COMPONENTS

TOOLS & INSTALLATION ACCESSORIES REQUIRED

• Crimping tool and connectors, or solder gun,

solder, and heat shrink • Tape • Wire cutter

• Zip ties

TABLE OF CONTENTS

Applications 2 ...........................................................

Connections

LDSWCX-6502 Without Amp 3 ..............................

LDSWCX-6502 With Amp 4 ...................................

LDSWCX-6522 Without Amp 5 ..............................

LDSWCX-6522 With Amp 6 ....................................

Programming 7 .........................................................

Troubleshooting.....................................................8

APPLICATIONS

• AXTC-CH13 interface • LD-SWCX-6502 harness • LD-SWCX-6522 harness • 3.5mm adapter

See inside front cover

ATTENTION: With the key out of the ignition,

disconnect the negative battery terminal

before installing this product. Ensure that all

installation connections, especially the air

bag indicator lights, are plugged in before

reconnecting the battery or cycling the ignition

to test this product.

NOTE: Refer also to the instructions included

with the aftermarket accessory before

installing this device.

•

Provides accessory power (10-amp)

• Provides wires for multimedia

radios (park brake, reverse,

speed sense)

• Retains audio controls on the

steering wheel

• Can be used in both amplified

and non-amplified models

• Retains balance and fade (†)

• Designed to be compatible

with all major radio brands

• Auto detects vehicle type, radio

connection, and preset controls

• Ability to dual assign steering

wheel control buttons

• Retains memory settings even

after battery disconnection or

interface removal (non volatile

memory)

• Provides illumination output

• Micro-B USB updatable

(†) Non-amplified models only

INTERFACE FEATURES

•

Provides accessory power (10-amp)

• Provides wires for multimedia

radios (park brake, reverse,

speed sense)

• Retains audio controls on the

steering wheel

• Can be used in both amplified

and non-amplified models

• Retains balance and fade (†)

• Designed to be compatible

with all major radio brands

• Auto detects vehicle type, radio

connection, and preset controls

• Ability to dual assign steering

wheel control buttons

• Retains memory settings even

after battery disconnection or

interface removal (non volatile

memory)

• Provides illumination output

• Micro-B USB updatable

(†) Non-amplified models only

Chrysler SWC (Steering Wheel Control)

and Data Interface 2004-Up

APPLICATIONS

Chrysler

300 2005-2007 ....................................................

Aspen 2007 ..........................................................

PT Cruiser 2006-2010 ..........................................

Dodge

Caliber 2007-2008 ..............................................

Charger 2006-2007 ............................................

Dakota 2005-2007 ..............................................

Durango 2004-2007 ...........................................

Magnum 2005-2007 ...........................................

Ram 1500 2006-2008 .........................................

Ram 2500/3500 2006-2009 ..............................

Ram Chassis Cab 4500/5500 2008-2010 ...........

Jeep

Commander 2006-2007 ....................................

Compass 2007-2008 ..........................................

Grand Cherokee 2005-2007 ...............................

Patriot 2007-2008 ..............................................

Mitsubishi

Raider 2006-2007 ..............................................

Chrysler

200 2011-2014 ......................................................

300 2008-2010 ....................................................

Aspen 2008-2009 ...............................................

Sebring 2007-2010 .............................................

Town & Country 2008-2017 ...............................

Dodge

Avenger 2008-2014 ............................................

Caliber 2009-2012 ...............................................

Caravan, Grand Caravan.....................2008-up

Challenger 2008-2014 ........................................

Charger 2008-2010 .............................................

Dakota 2008-2011 ...............................................

Durango 2008-2013 ............................................

Journey 2009-2010 .............................................

Magnum 2008-2009 ..........................................

Nitro 2007-2011 ...................................................

Ram 1500 2009-2011 ...........................................

Ram 2500/3500 2010-2011 .................................

Ram Chassis Cab 4500/5500 2011 ......................

Jeep

Commander 2008-2010 .....................................

Compass 2009-2017.5 ........................................

Grand Cherokee 2008-2013 ...............................

Liberty 2008-2012 ...............................................

Patriot 2009-2017 ...............................................

Wrangler* 2018 ...................................................

Wrangler Unlimited* 2018 .................................

Wrangler............................................2007-2017

Wrangler Unlimited 2007-2017 ..........................

* JK body type

Mitsubishi

Raider 2008-2009 ..............................................

Ram

1500/2500/3500 2012 ..........................................

Chassis Cab 3500/4500/5500.....................2012

C/V Tradesman 2012-2015 ..................................

Volkswagen

Routan 2009-2013 ..............................................

LD-SWCX-6502 APPLICATIONS LD-SWCX-6522 APPLICATIONS

Produkt Specifikationer

Mærke:	AXESS
Kategori:	Ikke kategoriseret
Model:	AXTC-CH13
