BT8538

Installation Guide

www.btechavmounts.com

■

Universal design suitable for mounting two XL

screens side by side

■

Recommended screen size: 70-86" (177-218cm)

■

Max load: 100kg (220lbs) per screen

■

VESA

and non-VESA ﬁxings: up to 1000 x 800mm

■

Integrated VC shelf with an adjustable arm allows

a camera to be ﬁtted above or below the screen

■

Small footprint, ideal for installs where ﬂoor

space is limited

■

Simple ‘hook-on’ screen installation

■

Stand dimensions:

3000mm (118") 2408mm (95") 240mm (9.5")W. H. D.

XXL Twin Screen VC Bolt-Down Stand

Recommended

Max Screen

Max

Load

Max

VESA

Post Install

Alignment

1000

800

218cm

86"

100kg

[220lbs]

Installation Safety Notes 2

Parts List 4

Installation Instructions 6

Product Dimensions 15

B-Tech Contact Details 16

Installation Safety Instructions

Contents Pg

Caution: This mount is intended for use only with the

maximum weights indicated. Use with equipment heavier than the

maximum indicated may result in instability causing possible injury.

Do not attempt to install this product until all instructions and warnings have been read and properly understood.

Please keep these instructions for future reference.

Please check carefully to make sure there are no missing or defective parts - defective parts must never be used.

B-Tech AV Mounts, its distributors and dealers are not liable or responsible for damage or injury caused by improper

installation, improper use or failure to observe these safety instructions. In such cases, all guarantees will expire.

General

B-Tech AV Mounts recommends that a professional AV installer or other suitably qualif ied person install this product.

Great care must always be taken during installation as most AV equipment is of a fragile nature, possibly heavy and easily

damaged if dropped. If you do not fully understand the instructions or are not sure how to install this product safely, then

please consult a professional for advice and/or to install this product for you. Failure to mount this product correctly may

cause serious injury or death both during installation and at any time thereafter. Do not mount any AV equipment that

exceeds the speciﬁc weight limit of the product you are installing. This weight limit will be clearly stated on each product

and its packaging and will vary from product to product.

Product location

Please pay careful attention to where this product is located. Check load capacity of the ﬂoor prior to installation as some

surfaces are not suitable for installation. Designed for indoor use, this mount is suitable for public or home installation. If

located in a public or frequently populated area ensure that the product is out of the immediate reach of people. If any

AV equipment is to be suspended over the likely path or location of people then great care should be taken to secure all

parts of the installation from falling. When drilling holes it is essential to avoid contact with electrical cables and water or

gas pipes contained within. Use of a good quality live wire detector and hidden object locator is therefore recommended.

Only drill into structures when you are sure it is safe to do so.

Fixing hardware

It is highly recommended that all ﬁxing screws be used where supplied and that the purpose of all other ﬁxing hardware

is fully understood. In some cases more AV equipment ﬁxing hardware will be supplied to accommodate different models

of equipment and set up conﬁgurations. The installer must be satisﬁed that any supplied ﬁxing hardware is suitable for

each speciﬁc installation. The ﬁxing kit supplied with the product may not be suitable for all walls. If any ﬁxing screws or

included hardware are deemed not sufficient for a safe installation then please consult a professional or your local

hardware store.

Hazard limitation

When routing cables take advantage of any built in cable management features that the product might provide and ensure

that all cables are tidy and secure. Check to see that any moving aspect of the product can do so unhindered by any cabling.

Some products have moving parts and the potential to cause injury through the crushing or trapping of ﬁngers or other

body parts. Particular attention to the nature of moving parts is required especially when assembling installing and

adjusting during set up. Immediately after installation double-check that the work done is safe and secure. Double-check

all necessary ﬁxings are present and are of ample tightness. It is recommended that periodic inspections of the product

and its ﬁxing points are made as frequently as possible (no more than 6 months apart) to ensure that safety is maintained.

If in doubt consult a professional AV installer or other suitably qualiﬁed person.

BT8538
