FEATURES AT A GLANCE
Bakers Pride
®
P48 series ovens feature two
independently controlled baking chambers, each with
one deck in your choice of Cordierite (7" height) or brick-
lined Cordierite (7.5" height). The greater deck height
allows you to accommodate taller bake and roast items.
The brick-lined model adds a Cordierite ceiling, which
offers the benet of increased temperature and recovery
time. They may be easily installed at the factory or in the
eld.
Each chamber has an independent thermostat and
60-minute electric timer with continuous-ring alarm
and manual shut-off. All models come standard
with stainless steel exterior and 4" adjustable legs.
International voltages are available.
SERIES: P48S & P48BL
HEARTHBAKE SERIES COUNTERTOP ELECTRIC OVENS
• 208 V or 220/240 V @ 4300 watts,
single or three phase
• Independent top and bottom
controlled incoloy heating
elements
• 150–550°F (65–288°C)
thermostat
• Two high-heat, aluminized steel
baking chambers
• Two 20.75" (527 mm) sq. decks
• 7.5" (191 mm) deck height or 7”
(178 mm) deck height with brick-
lined option
• Cordierite or brick-lined
• Two 60-minute, electric timers
with continuous-ring alarm and
manual shut-off
• All stainless steel exterior
• 6' (1829 mm) cord and plug on
single-phase units
• 4" (102 mm) adjustable legs
• Fully insulated
• One-year limited warranty
• Stainless steel stand with or without
casters
• International voltages
• Stacking kits
• Brick-lined conversion kit (standard
on P48BL)
• Steel decks
• Lightstone decks
OPTIONS & ACCESSORIES
www.bakerspride.com | p: 800.527.2100 265 Hobson St. • Smithville, TN 37166
2M-Z24638 REV-A (10-21)
EQUIPMENT DIMENSIONS
REQUIRED CLEARANCES
Left 3" (76 mm)
Right 3” (76 mm)
Back 3" (76 mm)
In European Community Countries and
North America. In NON-COMBUSTABLE
locations only.
In European Community Countries only in
COMBUSTIBLE locations. NOT for North
America.
MECHANICAL SPECIFICATIONS
Model # Overall Dim
(W x H x D)*
Deck
Height
Deck Size
(W x D)
Decks Baking
Chambers
Thermostat
Range
Carton Dim
(W x H x D)
Cubic
Feet
Cubic
Meter
Ship
Wt.
P48S
26" x 28.5" x 28"
(660 x 724 x 711)
7.5"
(191)
20.75" x 20.75"
(527 x 527)
2 2 150°-550°F
(66-288°C)
30" x 32" x 32"
(762 x 813 x 813)
17.7 .51 278
(126kg)
P48BL
26" x 28.5" x 28"
(660 x 724 x 711)
7"
(178)
20.75” x 20.75”
(527 x 527)
2 2 150°-550°F
(66-288°C)
30" x 32" x 32"
(762 x 813 x 813)
17.7 .51 288
(131kg)
*Height excludes legs
POWER SUPPLY
Model # Watts Voltage Phase Amps Plug Style
USA Canada UK Europe
P48S &
P28BL
4300 208 1, 3 20.7 6-30P
220/240 1, 3 18.7
SERIES: P48S & P48BL
HEARTHBAKE SERIES COUNTERTOP ELECTRIC OVENS
Freight Class: 110
FOB: Smithville 37166
6-30P
FRONT VIEW
400
350
300
250
200
150
450
500
550
°F
°C
80
100
120
140
160
180
200
220
240
260
280
400
350
300
250
200
150
450
500
550
°F
°C
80
100
120
140
160
180
200
220
240
260
280
MINUTES0
1
12
15
14
13
11
10
9
8
7
6
5
4
3
2
MINUTES0
1
12
15
14
13
11
10
9
8
7
6
5
4
3
2
BAKERS PRIDE
BAKERS PRIDE
26"
(660mm)
28.5"
(724mm)
SIDE VIEW/SECTION
21"
(533mm)
6.75"
(171mm)
9.5"
(241mm)
9.5"
(241mm)
7.5"
(190mm)
7.5"
(190mm)
11.5"
(292mm)
TOP VIEW
Bake Chamber
22 .25"
(565mm)
21 .75"
(552mm)
28"
(711mm)
1 .5"
(38mm)
Bakers Pride reserves the right to modify specications or discontinue
models without incurring obligation. Dimensions nominal.
www.bakerspride.com | p: 800.527.2100 265 Hobson St. • Smithville, TN 37166
