Bauknecht BUC 3C26 PF X A Manual

Bauknecht Opvaskemaskine BUC 3C26 PF X A

Læs gratis den danske manual til Bauknecht BUC 3C26 PF X A (8 sider) i kategorien Opvaskemaskine. Denne vejledning er vurderet som hjælpsom af 65 personer og har en gennemsnitlig bedømmelse på 4.3 stjerner ud af 33 anmeldelser. Har du et spørgsmål om Bauknecht BUC 3C26 PF X A, eller vil du spørge andre brugere om produktet?

Download PDF

Side 1/8

DAILY REFERENCE

GUIDE

THANK YOU FOR BUYING A BAUKNECHT PRODUCT.

In order to receive a more complete assistance, please

www.bauknecht.eu/register

You can download the Safety Instructions and the Use

and Care Guide, by visiting our website

http://docs.bauknecht.eu and following the

Instructions on the back of this booklet.

Before using the appliance carefully read Health and Safety guide.

PRODUCT DESCRIPTION

APPLIANCE

1.Upper rack

2.Cutlery rack

3.Foldable flaps

4.Upper rack height adjuster

5.Upper spray arm

6.Lower rack

7.Space Zone

8.Lower spray arm

9.Filter Assembly

10.Salt reservoir

11.Detergent and Rinse Aid dispensers

12.Rating plate

13.Control panel

0000 000 00000

Service:

CONTROL PANEL

1. On-Off/Reset button with indicator light

2. Program selection button with indicator light

3. Multizone button with indicator light / Key lock

4. Eco program indicator light

5. Key lock indicator light

6. Display

7. Program number and remaining time indicator

8. Tablet (Tab) indicator light

9. Closed water tap indicator light

10. Rinse Aid refill indicator light

11. Salt refill indicator light

12. Power Clean button with indicator light / Tablet (Tab)

13. Delay button with indicator light

14. Start/Pause button with indicator light / Drain out

1454 6 7 10 11 129

FIRST TIME USE

SALT, RINSE AID AND DETERGENT

ADVICE REGARDING THE FIRST TIME USE

After installation, remove the stoppers from the racks and the retaining

elastic elements from the upper rack.

FILLING THE SALT RESERVOIR

The use of salt prevents the formation of LIMESCALE on the dishes and

on the machine’s functional components.

• It is important that the salt reservoir be never empty.

• It is important to set the water hardness.

The salt reservoir is located in the lower part of the dishwasher

(see PRODUCT DESCRIPTION) and should be filled when the

SALT REFILL indicator light in the control panel is lit.

1.Remove the lower rack and unscrew the

reservoir cap (anticlockwise).

2.Position the funnel

(see figure)

and fill the salt

reservoir right up to its edge (approximately 1 kg);

it is not unusual for a little water to leak out.

3.Remove the funnel and wipe any salt residue

away from the opening.

Make sure the cap is screwed on tightly, so that no detergent can get

into the container during the wash program (this could damage the

water softener beyond repair).

Whenever you need to add salt, we recommend carrying out the

procedure before the washing cycle is started.

SETTING THE WATER HARDNESS

To allow the water softener to work in a perfect way, it is essential that

the water hardness setting is based on the actual water hardness in

your house. This information can be obtained from your local water

supplier.

The factory setting is for average (3) water hardness.

1. Switch on the appliance by pressing the

ON/OFF

button.

2. Switch off the appliance by pressing the

ON/OFF

button.

3. Hold down button

START/PAUSE

for 5 seconds, until you hear a

beep.

4. Switch on the appliance by pressing the

ON/OFF

button.

5. The current selection level number and the salt indicator light both

flash.

6. Press button

to select the desired hardness level

(see Water

Hardness Table).

7. Switch off the appliance by pressing the

ON/OFF

button.

Setting is complete!

As soon as this procedure is complete, run a program without loading.

Only use salt that has been specifically designed for dishwashers.

After the salt has been poured into the machine, the SALT REFILL

indicator light switches off.

If the salt container is not filled, the water softener and the heating

element may be damaged as a result.

FILLING THE RINSE AID DISPENSER

Rinse aid makes dish DRYING easier. The rinse aid dispenser

should be filled

when the

RINSE AID REFILL indicator light

in the control panel is lit.

1. Open the dispenser

by pressing and pulling up the tab on the lid.

2. Carefully introduce the rinse aid as far as the maximum (110 ml) reference

notch of the filling space - avoid spilling it. If this happens, clean the spill

immediately with a dry cloth.

3. Press the lid down until you hear a click to close it.

NEVER pour the rinse aid directly into the tub.

ADJUSTING THE DOSAGE OF RINSE AID

If you are not completely satisfied with the drying results, you can adjust the

quantity of rinse aid used.

•

Switch the dishwasher on using the

ON/OFF

button.

•

Switch it off using the

ON/OFF

button.

•

Press button

START/PAUSE

three times - a beep will be heard.

•

Switch it on using the

ON/OFF

button.

•

The current selection level number and rinse aid indicator light flash.

•

Press button

to select the level of rinse aid quantity to be supplied.

•

Switch it off using the

ON/OFF

button

Setting is complete!

If the rinse aid level is set to 1 (ECO), no rinse aid will be supplied. The LOW

RINSE AID indicator light will not be lit if you run out of rinse aid.

A maximum of 5 levels can be set according to the dishwasher model.

The factory setting is for a medium level.

•

If you see bluish streaks on the dishes, set a low number (2-3).

•

If there are drops of water or limescale marks on the dishes, set a high

number (4-5).

FILLING THE DETERGENT DISPENSER

To open the detergent dispenser use the

opening device A

Introduce the detergent into the dry dispenser

B only.

Place the amount of detergent for pre-

washing directly inside the tub.

1.When measuring out the detergent refer to the

(see PROGRAMS TABLE)

to add the proper

quantity. Compartment

comprises a level showing the maximum

quantity of liquid or powder detergent that can be added to each cycle.

2. Remove detergent residues from the edges of the dispenser and close

the cover until it clicks.

3. Close the lid of the detergent dispenser by pulling it up until the closing

device is secured in place.

The detergent dispenser automatically opens up at the right time according to

the program.

If all-in-one detergents are used, we recommend using the

TABLET

button,

because it adjusts the program so that the best washing and drying results are

always achieved.

Water Hardness Table

Level °dH

German degrees

°fH

French degrees

1 Soft 0 - 6 0 - 10

2 Medium 7 - 11 11 - 20

3 Average 12 - 17 21 - 30

4 Hard 17 - 34 31 - 60

5 Very hard 35 - 50 61 - 90

Produkt Specifikationer

Mærke:	Bauknecht
Kategori:	Opvaskemaskine
Model:	BUC 3C26 PF X A
Bredde:	598 mm
Dybde:	590 mm
Højde:	820 mm
Kontroltype:	Knapper
Indbygget skærm:	Ja
Ledningslængde:	1.3 m
Placering af apparat:	Delvist indbygget
Installationsrum bredde:	608 mm
Installationsrum dybde:	590 mm
Støjniveau:	46 dB
Antal vaskeprogrammer:	8
Forsinket start-timer:	Ja
Børnesikring:	Ja
Justerbare fødder:	Ja
Dør farve:	Ikke anvendelig
Balje materiale:	Rustfrit stål
Vandforbrug pr. cyklus:	9.5 L
Bestik rum type:	Skuffe
Farve på kontrolpanel:	Sort
Antal kuverter:	14 kuverter
Cyklustid:	190 min.
Forsinket start (maks.):	24 t
Opvaskeprogrammer:	Glass/delicate, Intensive, Night, Pre-wash, Quick, Soak
Indikator for afspændingsmiddel:	Ja
Energieffektivitetsskala:	A til G
AquaStop funktion:	Ja
Indikator for resterende tid:	Ja
Installationsrum højde (min.):	820 mm
Installationsrum højde (maks.):	900 mm
Produktstørrelse:	Fuld størrelse (60 cm)
Vandpåfyldning:	Varm
Støjemissionsklasse:	C
Energieffektivitetsklasse:	E
Energiforbrug pr. 100 cyklusser:	95 kWh
Brugerdefineret panel klar:	Ja
Temperatur (maks):	65 °C
Saltindikator:	Ja
Kurves indstillelige placering:	Øvre
Maksimal varmtvandsforsyning temperatur:	60 °C
Nederste trådkurv type:	Enkelt
