Side 1/4

Further indications are given in the pages to follow and in the user instructions.

Water supply indicator

Check the appliance fills with water.

Lower spray arm blockindicator

Release the spray arm.

"Water stop” device indicator

"Water stop” device not working.

Switch off the dishwasher and shut off the

water tap.

Rinse aid level indicator

Add rinse aid.

Salt level indicator

Add regeneration salt; only add regeneration

salt immediately before starting a wash

programme.

Programme progress indicator Delayed start buttons

The wash cycle can be programmed to start after 1-24

hours. Then press the Start button. The dishwasher will

start at the set time.

Time and failure display

Indicates in hours the time remaining until the start of the

wash cycle. Switches off when the programme has started.

Toward the end of the programme, during the drying cycle,

the display will indicate the time remaining in minutes.

“F1-F9” Identification of faults for service technician.

Start button

Indicator lamp lit while the dishwasher is operating. Flashes

when a fault occurs.

Switches off at the end of the programme.

On / Off Button

Pre-rinse /

Pre-wash

Washing

Drying

Programme

end

Options

Eco-Dry button

Dry cycle without using fans.

Half Load button

This function can be used with any

programme. The indicator lamp switches on:

The wash cycle is activated for the

upper or

lower rack only.

Programme Symbol

and Temperature

Programme selection and

recommended load type

Place the detergent in the:

small compartment large compartment Consumption 1)

Normal load / (Half load)

Water

(Litres)

Energy

(kWh)

Time

(Min.)

Eco Normal 40 - 55° C Recommended programme for routine washes, for

crockery with little or no dried-on food. X X

(13.5)

(11.5)

(1.3)

(0.9)

(80)

(60)

Intensive 60 - 70° C

Recommended programme

for heavily soiled

crockery. with dried-on food. Especially suitable for

pans and saucepans.

X X

(19.5)

(11.5)

(1.7)

(1.3)

(98)

(90)

Pre-wash Crockery to be washed later. - - 5.0 (4.2) 0.02 (0.02) 9 (9)

Rapid 40° C Lightly soiled crockery with no dried-on food. - X 13.0 (13.0) 0.85 (0.75) 30 (30)

Glasses 40° C Light soiling, especially glasses. - X 12.5 (10.0) 0.82 (0.78) 60 (59)

Bio 50° C 2) Normally or heavily soiled crockery with dried-on food. X X 16.0 (14.5) 1.05 (0.90) 120 (117)

DYNAMIC SENSE: Energy savings and optimum wash results

The two sensor-controlled “DYNAMIC SENSE” wash options are

recommended for routine washes. They use double-sensor

technology. Separate sensors gauge turbidity and particles in

order to determine the degree of soiling of the wash water. In

accordance with values measured, a microprocessor establishes

optimum water, energy and time consumption. Optimum wash

results are thus achieved using only those resources strictly

required.

Quick Reference Guide

5019 100 90216

(We reserve the right to make technical modifications)

1) Values may vary in relation to usage, e.g.: different loads, water temperatures - above or below 15° C -

as well as water hardness and power supply voltage.

2) Reference programme for Test Institute and energy-label.

GSF 7396

1. After loading the dishwasher, close the

door properly and open the water

supply tap.

2. Press the On/Off button to switch the

dishwasher on.

One of the programme

indicator lamps will switch on.

3. Select the desired programme by

pressing the corresponding button.

The

corresponding indicator lamp lights

up. If required, select options (if supplied).

4. Press the Start button to start the

selected programme. The Start

indicator lamp will light up.

Once set,

the programmed data cannot be

altered by pressing the programme

selector buttons.

Note: Once the Start button has been

pressed, the dishwasher memorises the

last programme selected. This

information remains in the memory even

during interruption of the power supply.

To change the selected

programme, press the Start

button for about 5 seconds,until

the Start indicator lamp

switches off. Select a new

programme using the

programme selector knob and

press the Start button.

Note: If the dishwasher is switched off

during a wash programme, when

switched on again it will resume the wash

cycle from where it was interrupted.

Only open the dishwasher door if

strictly necessary during a wash

cycle and exercise maximum

caution. Danger of scalding from

steam.

5. To indicate the end of the programme,

the Start indicator lamp switches off

and

the End indicator lamp (if fitted)

switches on (for about 30 min.).

6. Once the Start indicator lamp has

switched off press the On/Off button to

switch the dishwasher off. All the

indicator lamps switch off.

7. Open the door (warning: beware of hot

steam). Unload the lower rack before

the upper one. Close the water tap.

Upper rack

Half Load:

If only the upper rack is to be loaded remove

the cutlery basket from the lower rack and

place it in the upper one.

Rack height adjustment:

(The dishwasher is delivered with the upper

rack in the top position).

The rack height can also be changed

when loaded.

• To lower: pull out the two side

handles and gently lower the rack.

• To raise: pull up the two side handles

until the rack clicks into place.

• The rack must be level on both

sides.

Crockery Holders:

• Down: cups and long-stemmed glasses.

•Up: plates.

"Vario Organizer” multi-purpose

support:

• To be used, for example, for long-

handled utensils (arrange knives

with the blade facing downwards),

cups and glasses.

• May be used in three different

positions (see also “Dishwasher

loading instructions” on Page 4).

1. Upon the left-hand side of the rack.

2. Upside-down, towards the centre of

the rack.

3. Upside-down, towards the left side.

Glass holder:

Lower rack

Half Load:

Loading the lower rack only gives

greater washing power, especially for

plates and saucepans.

Plate holders:

• May be lowered to increase

available space (A).

• May be removed to increase available

space(B). To remove: pull the handle

up.

Cutlery basket:

The cutlery basket can be removed to

increase (C) available space.

How to use the dishwasher

Please read the user instructions carefully.

Upper and lower rack
