Bauknecht GSF atlantic TW-WS Manual

Bauknecht Opvaskemaskine GSF atlantic TW-WS

Læs gratis den danske manual til Bauknecht GSF atlantic TW-WS (4 sider) i kategorien Opvaskemaskine. Denne vejledning er vurderet som hjælpsom af 57 personer og har en gennemsnitlig bedømmelse på 4.1 stjerner ud af 29 anmeldelser. Har du et spørgsmål om Bauknecht GSF atlantic TW-WS, eller vil du spørge andre brugere om produktet?

Download PDF

Side 1/4

Further indications are given in the pages to follow and in the user instructions.

Options

Delayed start buttons

The wash cycle can be programmed to start after

1-24 hours. Then press the Start button.

The dishwasher will start at the set time.

Time and failure display

Indicates in hours the time remaining until the start

of the wash cycle. Switches off when the programme

has started. Toward the end of the programme, during

the drying cycle, the display will indicate the time

remaining in minutes.

“F1-F4”,“F7-F9”

Identification of faults for service technician.

“F6” Turn on the water supply tap.

On button

Off button

Rinse aid level indicator

Add rinse aid.

Salt level indicator

Add regeneration salt; only add

regeneration salt immediately before

starting a wash programme.

Programme selection button

Start button

Indicator lamp lit while the dishwasher is operating.

Flashes when a fault occurs.

Switches off at the end of the programme.

Option

Half Load button

This function can be used with any programme.

The indicator lamp switches on: the wash cycle is

activated for the upper or lower rack only.

Programme Symbol

and Temperature

Programme selection and

recommended load type

Place the detergent in the:

small large

compartment compartment

Consumption 1)

Normal load / (Half load)

Water

(Litres) Energy

(kWh) Time

(Min.)

Pre-wash Crockery to be washed later. - - 5.0 (4.2) 0.02 (0.02) 9 (9)

Rapid 40° C Lightly soiled crockery with no dried-on food. - X 13.0 (13.0) 0.85 (0.75) 30 (30)

Bio-Normal 50° C 2) Normally or heavily soiled crockery with dried-on food. X X 16.0 (14.5) 1.05 (0.90) 120 (117)

Normal 65° C 3) Normally or heavily soiled crockery. X X 16.0 (14.2) 1.60 (1.40) 86 (83)

Intensive 70° C Heavily soiled pans and saucepans. X X 21.0 (18.0) 1.90 (1.65) 110 (105)

Quick Reference Guide

5019 100 90376

(We reserve the right to make technical modifications)

1) Values may vary in relation to usage, e.g.: different loads, water

temperatures - above or below 15° C - as well as water hardness and power supply voltage, etc.

2) Reference programme for Test Institute and energy-label.

3) Programme recommended when using detergents of type A (non enzyme-based detergents).

GSX 5851

1. After loading the dishwasher, turn on

the water supply tap and open the

dishwasher door.

2. Press the On button to switch the

dishwasher on. One of the programme

indicator lamps will light up.

3. Press the programme selector button

until the corresponding indicator lamp

switches on. If required, select options

(if supplied).

4. Press the Start button to start the

selected wash programme. The Start

indicator lamp will light up.

Once set,

the programmed data cannot be

altered by pressing the programme

selector buttons.

Note: once the Start button has been

pressed, the dishwasher memorises the

last programme selected. This

information remains in the memory even

during interruption of the power supply.

To change the selected

programme, open the door

(caution: danger of scalding

from steam!) and press the Start

button for about 5 seconds, until

the Start indicator lamp switches

off. Select a new programme and

press the Start button again.

Note: if the dishwasher is switched off

during a wash programme, when

switched on again it will resume the wash

cycle from where it was interrupted.

Only open the dishwasher door if

strictly necessary during a wash cycle

and exercise maximum caution.

Danger of scalding from steam.

5 To indicate the end of a programme,

an acoustic signal is activated 4 times,

the Start indicator lamp switches off

and the End indicator lamp (if fitted)

lights up (for about 30 min.)

6. Only open the door once the wash cycle

has terminated (caution: danger of

scalding from steam) and press the OFF

button to switch the dishwasher off.

All

the indicator lamps switch off.

7. Unload the lower rack before the upper

one. Close the water tap.

Upper rack

Half Load:

If the upper rack only is to be loaded,

remove the cutlery basket from the lower

rack and place it in the upper one.

Rack height adjustment:

(The dishwasher is delivered with the

upper rack in the top position).

The rack height can also be changed

when loaded.

•To lower: pull out the two side

handles and gently lower the rack.

•To raise: pull up the two side handles

until the rack clicks into place.

•The rack must be level on both sides.

Crockery holders:

•Down: cups and long-stemmed

glasses.

•Up: plates.

“ ”Vario Organizer multi-purpose

support:

•To be used, for example, for

long-handled utensils (arrange

knives with the blade facing

downwards), cups and glasses.

•May be used in three different

positions (see also “Dishwasher

loading instructions” on Page 4).

1. Upon the left-hand side of the rack.

2. Upside-down, towards the centre of

the rack.

3. Upside-down, towards the left side.

Glass holder:

Lower rack

Half Load:

Loading the lower rack only gives

greater washing power, especially

for plates and saucepans.

Plate holders:

•May be lowered to increase

available space (A).

Cutlery basket:

•The cutlery basket (B + C)

can be removed to increase

available space.

•Some models are provided with

a grid (D) that can be fitted onto

the cutlery basket.

How to use the dishwasher

Please read the user instructions carefully.

Upper and lower rack

Produkt Specifikationer

Mærke:	Bauknecht
Kategori:	Opvaskemaskine
Model:	GSF atlantic TW-WS
