Side 1/4

5019 496 90425

GSIP 6198 Quick Reference Guide

Before using the dishwasher, read the user instructions!

(We reserve the right to make technical modifications)

Add regeneration salt

Only add regeneration salt immediately before

starting a wash programme.

Add rinse aid

Time and failure display3)

Indicates in hours the time remaining until the start of

the wash cycle. Switches off at programme start and

indicates the remaining time in hours and minutes.

“F....” Information for the After-Sales Service

“Delayed start” button

The wash cycle can be programmed to start after 1 -

24 hours. With each successive touch of the button,

the delayed start indicator increases by 1 hour, and

after 24 returns to 00. Then press the Start button.

The dishwasher will start at the set time.

“Half load - Multizone” button

Load the upper or lower rack only.

This function can be used with any programme.

Press once = upper rack (the indication lamp/

symbol comes on)

Press twice = lower rack (the indication lamp/

symbol comes on)

Press 3 times = Off (half load function deactivated).

When washing without the top rack, press the “Half

Load” button twice, or “Lower rack wash” (the

corresponding LED/symbol comes on).

Antibacterial rinse 4)

This function adds an antibacterial rinse at the end of

the wash cycle, thereby guaranteeing a perfectly

clean and sanitized load. The lamp will light up when

the function is activated. If the temperature is not

maintained during the antibacterial cycle (e.g. if the

door is opened and remains open for a long time),

the lamp will start blinking to indicate that sanitation

is not guaranteed.

1) Reference programme for energy label EN 50242

(Liter = 13.0, kWh = 1.05, Min. = 145);

2) Refer to “User instructions”;

3) Program data obtained in conformity with European standard

EN 50242. Values may vary in relation to usage, e.g.: different

loads, water temperatures - above or below 15°C - as well as water

hardness and power supply voltage, etc.

4) The bacteria removal efficiency has been tested by the Institut

Pasteur de Lille (France), based on the NF EN 13697 standard

of November 2001.

5) These programmes can be used with the Antibacterial rinse

option.

Programme selection button

On / Off button

Start button

Switches “on” when the dishwasher is operating.

Flashes when a fault occurs. Switches off at the

end of the programme.

Indicators

Options

Programme chart Detergent2) Consumption 3)

Programmes Loading instructions A B Litres kWh Minutes

Sensor + 1) 5) 40-70°C Lightly, normally or heavily soiled

crockery, including pots and pans. X X 7.0-17.0 0.99-1.58 90-162

Pre-Rinse cold Crockery to be washed later. - - 4.0 0.03 14

Glass 40°C Light soiling, for example glasses

and cups. X - 10.0 0.80 55

Rapid 30 min 40°C Lightly soiled crockery with no

dried-on food. X - 10.0 0.65 30

Important information for Test Laboratories:

For detailed information on the EN comparison test and other tests, contact the following address: “nk_customer@whirlpool.com”.

How to use the appliance

Further indications are given in the single chapters and in the user instructions.

Press the ON / OFF button.

Compartment A:

With each wash cycle.

Compartment B:

For programmes with pre-wash only.

Mechanical indicator lamp C.

Electric indicator on control panel (if provided).

On models with water softener

system only.

Mechanical indicator lamp D. Electric

indicator on control panel (if provided).

Refer to the dishwasher loading instructions.

The last programme selected will light up.

Select the desired programme (using the specific button or knob).

The corresponding indicator lamp lights up.

If necessary (and if provided).

The corresponding indicator lamp lights up.

The selected programme is

then memorised (even in the

event of power failure).

- Only open the dishwasher if necessary

(Warning: beware of hot steam).

- If the appliance is switched off during a

wash cycle, when switched on again it

will resume the cycle from where it was

interrupted.

Only after the START button has switched off: Press the ON / OFF button.

All the indicator lamps switch oﬀ.

Warning: When the door is opened steam comes out!

Unload the appliance, starting from the lower rack.

Switch on the appliance

Fill the detergent dispenser

A B C

Check the rinse aid level

Check the

regeneration salt level

Load the racks

Close the dishwasher door,

turn on the water tap

Select a programme

Select additional options

Press the Start button

“Change programme in progress”

Press the START button for 2 sec. until the

Start indicator lamp switches off.

Select another programme and press the

START button again.

Wash cycle

Switch off the appliance

Turn oﬀ the water tap,

unload the racks
