GSX 7998 Quick Reference Guide
Before using the dishwasher, read the user instructions!
BK/I/FD/GB
(We reserve the right to make technical modifications)
Add rinse aid
Add regeneration salt
Only add regeneration salt
immediately before starting a wash
programme.
Time and failure display 3)
Indicates in hours the time
remaining until the start of the wash
cycle. Toward the end of the
programme, during the drying cycle,
the display will indicate the time
remaining in minutes.
“F...” Information for the
After-Sales Service
“Delayed start” buttons
The wash cycle can be programmed
to start after 1 - 24 hours. With each
successive touch of the button, the
delayed start indicator increases by 1
hour, and after 24 returns to
00.Then press the Start button. The
dishwasher will start at the set time.
“Half Load” button
This function can be used with any
programme. The indicator lamp
switches on. The wash cycle is
activated for the upper or lower
rack only.
1) Reference programme for energy label in
compliance with EN 50242 regulations;
2) Refer to “User instructions“;
3) Program data obtained in conformity with
European standard EN 50242. Values may vary in
relation to usage, e.g.: different loads, water
temperatures - above or below 15°C - as well as
water hardness and power supply voltage, etc.
On button
Off button
Programme selection button
Start button
Switches “on” when the dishwasher
is operating. Flashes when a fault
occurs. Switches off at the end of
the programme.
Indicators
Options
Programme chart Detergent 2) Consumption 3)
Programmes Loading instructions A B Litres kWh Minutes
AutoNormal 40-55°C
Automatic programme
recommended for routine washes,
with no dried-on or burnt food (not
for EN 50242).
X X 10-13 0.8-1.05 60-120
AutoIntensive 60-70°C
Automatic programme
recommended for heavily soiled
crockery with dried-on or burnt food,
for example pans and saucepans.
X X 13-20 1.1-2.0 100-150
Pre-Rinse cold Crockery to be washed later. - - 4.0 140.03
Glass 40°C Light soiling, for example glasses
and cups. X - 10.0 0.80 55
Rapid 30 min 40°C Lightly soiled crockery with no
dried-on food. X - 10.0 0.65 30
Standard 1) 50°C Normally or heavily soiled crockery. X X 13.0 1.05 145
Important information for Test Laboratories:
For detailed information on the EN comparison test and other tests, contact the following address:
“nk_customer@whirlpool.com”.
