Side 1/8
1
GB
Before using the dishwasher, read the
installation and maintenance instructions carefully!
GSXP 70 POWER
5019 496 01108
1) Programme data obtained in conformity with European standard EN 50242. The data may vary, for example, according to different loads,
extra functions, sensor settings (only with sensor programmes), water supply temperatures, water hardness and power supply voltage.
2) Energy label programme in compliance with EN 50242. - Information for Test Laboratories: for more detailed information on the
EN comparison test and other tests, contact the following address: “nk_customer@whirlpool.com”.
3) The antibacterial action has been tested by the Institut Pasteur of Lille (France), based on Standard NF EN 13697 - November 2001.
ON button
OFF button
Programme selection button
Press button P (repeatedly) until the required programme
number appears on the display.
Fault indication and wash time display
In normal operation it indicates the remaining time (h:mm),
whereas with “Delayed start” selected it indicates the time
remaining until programme start (hh).
In the presence of a fault indication “F..” –, consult the section
“5. What to do if…”.
Rinse aid level indicator and salt level indicator
These indicator lamps light up when rinse aid or salt need to
be added.
Add just before starting a wash cycle.
Set the detergent
Press button P (repeatedly) to set the type of detergent used.
This deactivates the rinse aid and/or salt indicator.
“Half Load”/“Multizone”
Load the upper or lower rack only.
Press once = wash upper rack (the indicator/symbol lights up)
Press twice = wash lower rack (the indicator/symbol lights up)
Press 3 times = Off (“Half load”/“Multizone” deactivated).
When washing without the top rack, press the “Half load” (i.e.
“wash bottom rack”) button twice; the indicator /corresponding
symbol lights up.
Powder, gel, tablets (standard): indicator off
Detergent with rinse aid: left indicator
Detergent with salt + rinse aid: right indicator
Power Clean
High pressure with an additional jet for better washing results
and greater bottom rack load flexibility.
“Delayed Start” button
Press the button (repeatedly) to delay the start of the
programme. Adjustable from 1 to 24 hours. With each press
of the button, the delayed start indicator increases by one
hour and after 24 restarts from 00. Then press the START
button. The dishwasher will start after the set time.
START button
The indicator lights up during operation, flashes when a fault
occurs, and goes off at the end of the programme.
RESET button - for programme change or indication of faults
Press this button to cancel a started programme and selected
extra functions. Press this button to cancel the main fault
indicators (F..); also refer to the section “5. What to do if…”.
The programme can then be selected and started.
Running programme indicator
A LED light projected on the floor indicates that the
dishwasher is working.
Table 1.1.
Programme chart Detergent
dispenser Consumption 1)
PProgrammes Available
options Loading instructions large small Litres kWh Minutes
1Sensor + 40-70°C Normally or heavily soiled
crockery, including pots and pans. X X 7-17 0.99-1.58 65-170 ±1)
2Pre-Rinse cold Crockery to be washed later. — — 4.0 0.03 14 ± 1)
3Hand washing 40°C Light soiling, e.g. glasses and cups,
with a lower pressure jet. X — 10.0 0.85 125 ±1)
4Quickwash 40°C Lightly soiled crockery, with no
dried-on food. X — 10.0 0.65 30 ± 1)
5Eco 2) 50°C Normally soiled crockery. Energy
Saving Programme. X X 11.0 1.05 170 ±1)
6Hygienic + 3)
Normally or heavily soiled crockery,
with additional antibacterial wash.
Programme interruption (e.g. due to
door opening) can compromise
elimination of germs.
X X 13.0 1.50 115 ±1)
7Overnight 55°C Normally soiled crockery, gentle
and quiet (39 dbA) thanks to the
lower pressure jet. X X 13.0 1.20 290 ±1)
2
2. QUICK REFERENCE GUIDE
Detailed instructions are given in the following pages, see also chapter “5. What to do if...”
1. Switch on the
appliance Open the dishwasher door.
Press the ON button.
2. Select a programme Press the button or to bring up the desired programme on the display.
Select options, if available.
3. Select the type of
detergent
The detergent selection procedure varies depending on the dishwasher model.
Chapter “1. Overview” provides instructions for selecting detergent type.
4. Fill in the detergent 4a. Powder/gel/tabs
Fill the detergent dispenser compartments in
accordance with the wash programme selected.
Large compartment A for every wash cycle, additional
small compartment B for programmes with pre-wash
(see table 1.1.).
4b. Combined action detergents (2 in 1/3 in 1/... etc.)
Place the detergent in compartment A, as per the
manufacturer's recommendations.
5. Check the rinse aid
level
6. Check the salt level Depending on the model:
7. Load the racks
Make sure that the spray arms can turn freely and are not impeded by crockery
or cutlery in the racks.
Detailed instructions on loading the racks are given in chapter “3. How to use
the appliance”, under “How to load the racks”.
8. Start the appliance Press the START button.
9. Turn on the water
tap and close the
dishwasher door
When the door is closed the dishwasher
starts automatically.
Wash cycle
If the appliance is switched off during a
wash cycle, when switched on again it will
resume the cycle from where it was
interrupted. Care must be taken when
opening the door, as steam will escape!
10.End of programme At the end of the programme an acoustic signal will sound.
The START indicator lamp switches off.
11.Open the door,
switch off the
appliance
Press the OFF button. All the indicator lamps switch off.
12. Turn off the water
tap, unload the racks
Unload the appliance, starting from the lower rack in order to avoid any
residual drips of water falling onto crockery below.
A CB
Visual indicator in dispenser C
dark ➯sufficient rinse aid present,
clear ➯add rinse aid (approx. 150 ml).
The indicator lamp on the control panel lights up when rinse aid
needs to be added. Not all models are equipped with such an
indicator.
window in salt reservoir cap on bottom of appliance inside
orange ➯when sufficient salt is present,
clear ➯when salt needs to be added.
The indicator lamp on the control panel lights up when salt needs
to be added. Even once salt has been added, the indicator lamp
only switches off after several wash cycles!
Change the programme in
progress:
- Press the RESET button.
- Close the door.
- (Water drains for up to 60 seconds).
- Open the door.
- Select a new programme.
- Press the START button.
