LMB1040IP

153.282 V1.0

SAFETY INSTRUCTIONS ........................................................................................................................................................................................................................................................................................ 3

UNPACKING INSTRUCTION .................................................................................................................................................................................................................................................................................. 4

POWERSUPPLY ......................................................................................................................................................................................................................................................................................................... 4

RIGGING ......................................................................................................................................................................................................................................................................................................................... 4

DMX512 CONTROL .................................................................................................................................................................................................................................................................................................... 5

RDM CONTROL ........................................................................................................................................................................................................................................................................................................... 5

PROTECTION CLASS IP65 .................................................................................................................................................................................................................................................................................... 5

MAINTENANCE 5...........................................................................................................................................................................................................................................................................................................

TROUBLE SHOOTING .............................................................................................................................................................................................................................................................................................. 6

VEILIGHEIDSINSTRUCTIES .................................................................................................................................................................................................................................................................................. 7

UITPAKKEN .................................................................................................................................................................................................................................................................................................................. 8

AANSLUITSPANNING .............................................................................................................................................................................................................................................................................................. 8

DMX BEDIENING ........................................................................................................................................................................................................................................................................................................ 9

RDM BEDIENING ........................................................................................................................................................................................................................................................................................................ 9

BESCHERMINGSKLASSE IP65 ........................................................................................................................................................................................................................................................................... 9

ONDERHOUD ............................................................................................................................................................................................................................................................................................................... 9

PROBLEMEN OPLOSSEN .................................................................................................................................................................................................................................................................................... 10

SICHERHEITSHINWEISE ........................................................................................................................................................................................................................................................................................11

AUSPACKEN ............................................................................................................................................................................................................................................................................................................... 12

NETZANSCHLUSS ................................................................................................................................................................................................................................................................................................... 12

DMX BEDIENUNG ..................................................................................................................................................................................................................................................................................................... 13

RDM BEDIENUNG ..................................................................................................................................................................................................................................................................................................... 13

SCHUTZKLASSE IP65 ........................................................................................................................................................................................................................................................................................... 13

PFLEGE ......................................................................................................................................................................................................................................................................................................................... 13

FEHLERSUCHE ......................................................................................................................................................................................................................................................................................................... 14

INSTRUCCIONES DE SEGURIDAD .................................................................................................................................................................................................................................................................... 15

INSTRUCCIONES DE DESEMBALAJE ........................................................................................................................................................................................................................................................... 16

FUENTE DE ALIMENTACIÓN ............................................................................................................................................................................................................................................................................. 16

INSTALACIÓN ............................................................................................................................................................................................................................................................................................................ 16

CONTROL DMX512 ................................................................................................................................................................................................................................................................................................... 17

CONTROL RDM .......................................................................................................................................................................................................................................................................................................... 17

PROTECCION CLASE IP65 ................................................................................................................................................................................................................................................................................... 17

MANTENIMIENTO ..................................................................................................................................................................................................................................................................................................... 17

SOLUCIÓN DE PROBLEMAS ...............................................................................................................................................................................................................................................................................18

Immediately upon receiving the product, carefully unpack the carton, check the contents to ensure that all parts are present, and

have been received in good condition. Notify the shipper immediately and retain packing material for inspection if any parts appear damage from

shipping or the package itself shows signs of mishandling. Save the package and all packing materials. In the event that the product must be returned to

the factory, it is important that the product be returned in the original factory box and packing.

If the unit has been exposed to drastic temperature fluctuation (e.g. after transportation), do not switch it on immediately. The arising condensation water

might damage your unit. Leave the unit switched off until it has reached room temperature.

The label on the backside of the unit indicates the mains voltage to which it must be connected. Check that the mains voltage corresponds to this. Any

other voltage than the one indicated may cause irreparable damage to the unit. The unit must also be connected directly to the mains voltage and no

dimmer or adjustable power supply may be used.

The unit has a powerconnector output on board. Depending on the local conditions several units can be linked by powerconnector - and output. Connect in

a maximum of four (when using 230V/16A) units in a row. Use an approved three-core cable with a cross-section of at least 1.5 mm². The installation

instructions of the manufacturer and the colour coding of the cable must be observed. Do not turn off the unit by turning the powerconnector but use the

power on/off switch or schuko!

Always connect the unit to a protected circuit (circuit breaker or fuse). Make sure the unit has an appropriate electrical ground to

avoid the risk of electrocution or fire.

The unit may be set up on a stable and even surface. By means of the fixing facilities of the baseplate, the unit can also be mounted upside down to a truss,

see below picture. For fixing, certified clamps with correct save working load are required. According to the figure, the quick lock bolts of the omega

brackets are placed into the openings provided in the base plate and turned clockwise until they lock (to the stop). The mounting place must be of

sufficient stability and be able to support a weight of 10 times of the unit’s weight. Secure the unit with a safety cable so that it cannot fall down.

When carrying out any installation, always comply European and national guidelines concerning rigging, truss and all other safety issues. Always let the

installation checked out by an authorized dealer !

If you are using a standard DMX controller, you can connect the DMX output of the controller directly to the DMX input of the first unit in a DMX chain.

Always connect the output of one unit with the input of the next unit until all units are connected.

At the last unit, you must close the DMX line with a terminating resistor. Take an XLR connector and solder a 120 Ohm resistor

between signal (-) and signal (+) and connect it to the DMX output of the last unit in the line.

This unit can communicate using RDM (Remote Device Management) via DMX512. RDM is a bi-directional communication protocol for use in DMX512

control systems, it is the open standard for DMX512 configuration and status monitoring.

The RDM protocol allows data packets to be inserted into a DMX512 line without affecting the existing non-RDM equipment. The system allows a controller

or special RDM controller to send and receive commands from specific fixtures.

The RDM function allows you, for example to remotely set the DMX start address of your fixtures. This is especially useful when the fixture is installed in an

inaccessible location. Each unit has an RDM UID (unique identification number).

Units with protection class IP65 are dust-tight and completely protected against contact (first code number). They are also protected against splash water

from any angle (second code digit). That is why this unit can also be used out doors. Events units generally only designed for temporary use however ‐are

(event lighting) and not for permanent use outdoors. The specif d protection class does not make a statement about the weather resistance of the units ie

(resistance to changing ambient conditions as well as against the effects of sunlight and UV rays). The seals and screw connections of the units must be

checked regularly to ensure a fault-free operation.

This unit is virtually maintenance-free, but you should check the unit regularly for mechanical and electrical aspects.

Assess the operating environment and establish an inspection and cleaning schedule that follows the guidelines below:

• Disconnect the unit from the power supply and allow it to cool completely before inspecting and cleaning.

• Check that the screws and bolts used to install the unit are securely tightened and free from corrosion.

• Check the housing, fixing points and installation points, they must not show any signs of deformation, wear or fatigue.

• Check the mechanically moving parts, these must not show any signs of wear or fatigue.

• Check the electrical power and signal cables, they must not show any damage or fatigue.

• Do not use solvents, abrasives or other aggressive products to clean the unit .

• Wipe the unit and clean the glass plate with a soft, clean, lint-free cloth moistened with a weak cleaning solution. Place the solution on the cloth

and not on the surface to be cleaned. Avoid rubbing glass surfaces.

• Dry the unit, connectors and contacts with a soft, clean, lint-free cloth or low-pressure compressed air before re-powering the unit.

Onmiddellijk na ontvangst, zorgvuldig uitpakken van de doos, controleer de inhoud om ervoor te zorgen dat alle onderdelen aanwezig

zijn en zijn in goede staat zijn ontvangen. Bij transportschade of ontbreken van onderdelen onmiddellijk de verkopende partij inlichten. Bewaar

de verpakking en het verpakkingsmateriaal. Indien het product moet worden teruggestuurd, is het belangrijk dat het product in originele verpakking wordt

geretourneerd.

Als het apparaat is blootgesteld aan drastische temperatuurverschillen (bv. na het transport), schakel het apparaat niet onmiddellijk in. De ontstane

condensatie kan het apparaat beschadigen. Zorg ervoor dat het apparaat op kamertemperatuur komt en steek vervolgens de voeding stekker in het

stopcontact.

Op achterzijde van het apparaat staat aangegeven op welke netspanning deze moet worden aangesloten. Controleer of de netspanning hiermee

overeenkomt, bij alle andere netspanningen dan aangegeven kan het apparaat onherstelbaar worden beschadigd. Tevens moet het apparaat direct op de

netspanning worden aangesloten en mag géén dimmer of regelbare voeding worden gebruikt.

Het apparaat heeft een powerconnector uitgang aan boord. Afhankelijk van de plaatselijke omstandigheden kunnen meerdere apparaten via de in- en

uitgang met elkaar worden verbonden. Sluit maximaal vier (bij gebruik van 230V/16A) apparaten op een rij aan. Gebruik een goedgekeurde 3-aderige

kabel met een doorsnede van minimaal 1,5 mm². De installatievoorschriften van de fabrikant en de kleurcodering van de kabel moeten in acht worden

genomen. Schakel het apparaat niet uit door de powerconnector te draaien, maar gebruik de aan/uit-schakelaar of trek de stekker uit het stopcontact!

Sluit het apparaat altijd aan op een beschermd circuit (aardlekschakelaar of zekering). Zorg ervoor dat het apparaat

voldoende elektrisch is geaard om het risico op elektrocutie of brand te vermijden.

Het apparaat kan op een stabiele en gelijkmatige ondergrond worden opgesteld. Door middel van de bevestigingsmogelijkheden van de grondplaat kan het

apparaat ook ondersteboven aan een truss gemonteerd worden, zie onderstaande afbeelding. Voor de bevestiging zijn gecertificeerde klemmen met de

juiste werklast vereist. Volgens de afbeelding, worden de quick-lock bouten van de omega beugels in de openingen in de bodemplaat geplaatst en

rechtsom gedraaid tot ze vergrendelen (tot aan de aanslag). De montageplaats moet voldoende stabiel zijn en een gewicht van 10 keer het gewicht van

het apparaat kunnen dragen. Borg het apparaat met een veiligheidskabel, zodat deze niet naar beneden kan vallen.

Volg bij het uitvoeren van een installatie altijd de Europese en nationale richtlijnen met betrekking tot rigging, truss en alle andere veiligheidskwesties.

Laat de installatie altijd controleren door een geautoriseerde dealer!
