Technical Specications

EURORACK UB1002

Ultra-Low Noise Design 10-Input 2-Bus Mic/Line Mixer

2EURORACK UB1002 Technical Specifications

EURORACK UB1002

Ultra-Low Noise Design 10-Input 2-Bus Mic/Line Mixer

Ultra low noise design, highest possible headroom, ultra-transparent audio

2 state-of-the-art, studio-grade IMP “Invisible” Mic Preamps with 130 dB dynamic range for 24-bit, 192 kHz sampling rate inputs

Eective, extremely musical 3-band EQ plus switchable low-cut lter on all mono channels

10 balanced high-headroom line inputs with +4/-10 level selection on all stereo channels

One post fader FX send per channel for external FX devices

Clip LEDs on all mono channels

Main mix outputs plus separate control room, headphone and 2-track outputs

2-track inputs assignable to main mix or control room/headphone outputs

FX to control room function helps to monitor eects signal via headphone and control room outputs

Switchable +48 V phantom power for condenser microphones

External power supply for noise-free audio and superior transient response

High-quality components and exceptionally rugged construction ensure long life

Conceived and designed by BEHRINGER Germany

Specications

Line Input

Type ¼" TRS jack, electronically balanced

Impedance approx. 20 kΩ balanced,

approx. 10 kΩ unbalanced

Gain range -10 dB to +40 dB

Max. input level +22 dBu @ 0 dB GAIN

Fade-Out Attenuation2 (Crosstalk Attenuation)

Main fader closed 90 dB

Channel muted 89.5 dB

Channel fader muted 89 dB

Frequency Response (Mic In Main Out)

<10 Hz - 90 kHz +0 dB / -1 dB

<10 Hz - 160 kHz +0 dB / -3 dB

Stereo Inputs

Type ¼" TRS jack, electronically balanced

Impedance approx. 20 kΩ

Max. input level +22 dBu

Mono Inputs

Microphone Inputs (IMP “Invisible” Mic Preamp)

Type XLR connector, electronically

balanced, discrete input circuit

Mic E.I.N.1 (20 Hz - 20 kHz)

@ 0 Ω source resistance -134 dB / 135.7 dB A-weighted

@ 50 Ω source resistance -131 dB / 133.3 dB A-weighted

@ 150 Ω source resistance -129 dB / 130.5 dB A-weighted

Frequency Response

<10 Hz - 150 kHz -1 dB

<10 Hz - 200 kHz -3 dB

Gain range +10 dB to +60 dB

Max. input level +12 dBu @ +10 dB GAIN

Impedance approx. 2.6 kΩ balanced

Signal-to-noise ratio 110 dB / 112 dB A-weighted

(0 dBu In @ +22 dB GAIN)

Distortion (THD + N) 0.005% / 0.004% A-weighted

Produkt Specifikationer

Mærke:	Behringer
Kategori:	Blander
Model:	Eurorack UB1002
Bredde:	189 mm
Dybde:	220 mm
Højde:	47 mm
Vægt:	1800 g
Produktfarve:	Sort, sølv
Equalizer:	Ja
Equalizerbånd, antal:	3
Videofunktion:	Ingen
Mikrofonindgangsimpedans:	2600 ohm (Ω)
Udgang til hovedtelefoner:	Ja
DJ mixer:	Ingen
Mikrofon, signal-til-støjforhold:	112 dB
