GRAPHICS CARD FULL INSTALL MANUAL

Version 2.0 INT

Table of Contents

Basic Setup (16 Steps)

Section I Preparing for Installation . . . . . . . . . . . . . . . . . . . . pg. 2-3

Section II Installing the Graphics Card . . . . . . . . . . . . . . . . . pg. 3-5

Section III Installing the Drivers . . . . . . . . . . . . . . . . . . . . . . pg. 5

Advanced Setup

Section IV Advanced Driver Installation . . . . . . . . . . . . . . . . . pg. 5-7

Section V Setting up nView and HDTV/Video-Out . . . . . . . . . pg. 7-8

Section VI Setting up Video-In . . . . . . . . . . . . . . . . . . . . . . . pg. 8-9

Troubleshooting and Technical Support

Section VII Troubleshooting . . . . . . . . . . . . . . . . . . . . . . . . . pg. 9-12

Section VIII Technical Support . . . . . . . . . . . . . . . . . . . . . . . pg. 12

Important! Some steps are divided into an A and B step. Read both steps over carefully to

determine which is the most appropriate to follow for your installation.

I. Preparing for Installation

Step 1A. If you are replacing an existing graphics card with your new BFG Tech graphics card,

you must first uninstall the current drivers for that graphics card. Please consult your system or

graphics card documentation for instructions. Most often the task can be accomplished through

the “Add/Remove Programs” feature in “Control Panel”. Look for drivers that match your

existing graphics card, click “Remove” and select “Display Drivers” only if prompted.

Step 1B. If you are adding your new BFG Tech graphics card to a system with integrated on-

the-motherboard graphics, you must disable the integrated graphics first. The most effective

method is to disable it in the BIOS. Please contact your system or motherboard manufacturer as

the method can vary a great deal. You may also be able to disable the integrated graphics in the

“Device Manager” using the following steps:

Microsoft Windows 2000 or XP

1. Click “Start” > “Control Panel” > “Performance and Maintenance” > “System” >

“Hardware”.

2. Click on “Device Manager” and then click on the “+” by “Display Adapter”.

3. Right click on the current graphics card and select disable. Click “Yes” if asked “Do you

really want to do this”. Click “No” if prompted to restart your system.

4. Close all open windows and shut down your system.

Your system is now prepared for the installation of your new BFG graphics card.

Produkt Specifikationer

Mærke:	BFG Tech
Kategori:	Grafikkort
Model:	GeForce GTX 285
Bredde:	95.2 mm
Dybde:	266.7 mm
Højde:	38.1 mm
HDCP:	Ja
Maksimal opløsning:	2560 x 1600 pixel
HDMI:	Ja
Effektkrav:	12V, 42A
Mac kompabilitet:	Ingen
Processorfrekvens:	702 MHz
Hukommelsesur hastighed:	2664 MHz
Kompatible operativsystemer:	Windows Vista/XP
Grænsefladetype:	PCI Express 2.0
TV-tuner, integreret:	Ingen
Minimum plads på lagerdisk:	100 MB
Minimum systemkrav:	CD-ROM
Antal DVI-I-porte:	2
Kølingstype:	Aktiv
Minimum RAM:	1024 MB
Grafikprocessor:	GeForce GTX 285
Grafisk adapter, RAMDAC:	400 MHz
CUDA:	Ja
Diskret grafikadapterhukommelse:	1 GB
Hukommelsestype for grafikadapter:	GDDR3
Hukommelsesbus:	512 Bit
Hukommelsesbåndbredde (maks.):	170.5 GB/sek.
Antal DVI-porte:	2
DirectX-version:	10
Shader model version:	4.0
OpenGL-version:	2.1
DVI dobbelt link:	Ja
PhysX:	Ja
Minimum system strømføring:	575 W
Tv-udgang:	Ja
Stream processorer:	240
Shader ur:	1584 MHz
NVIDIA 3D Vision:	Ja
Struktur påfyldningsrate (TFR):	56.2 GT/s
