DISPLAYPORT 1.4

ACTIVE OPTICAL

CABLE, 8K

24/7 TECHNICAL SUPPORT AT 877.877.2269 OR VISIT BLACKBOX.COM

DATA SHEET

SOURCE

1.877.877.2269 BLACKBOX.COM

INTRODUCTION

Black Box DisplayPort Active Optical Cables awlessly

transmit uncompressed, full Ultra HD 8K video signals hundreds

of meters. This all-in-one cable design is plug-and-play, and

eliminates the need for a modular solution including a transmit-

ter, receiver, copper cabling, power and all

of the potential points of failure that come with it. Simply

connect the cable between your source and display like

a standard copper cable and leave it to awlessly transmit your

audio/video signal without worry of signal loss or degradation.

The cable is unidirectional—the source side connector connects

to the source and the display side connector connects to the

display.

Built-in technology inside the connectors actively converts

the electrical DisplayPort signal into an optical signal for

transmission, and then back to electrical for display. They also

use a hybrid design that includes both copper and ber, in which

the ber technology allows for signicantly increased

bandwidth that supports transmission of full Ultra HD video

resolutions at distances that the copper alternatives just can’t

come close to. It also provides higher immunity to EMI/RFI

interference and electromagnetic noise. And the inclusion

of copper wiring in the design allows for power to go over the

cable, meaning no external power is required. This design also

makes for a much thinner and more exible cable with a

tighter bend radius, making it easy to pull through tight spaces

and more freely navigate around corners and bends, not to

mention much lighter than its all-copper counterparts.

Black Box Active Optical Cables are the perfect A/V

distribution solution for control rooms, digital signage,

healthcare, conference rooms, mass transit and any other

application where uncompromised, Ultra High Denition video

is required at extended distances.

FEATURES

§§ UP TO FULL 7680 X 4320 (8K) VIDEO SIGNALS UP TO 100 M

§§ DATA TRANSFER RATES UP 32.4 GBPS

§§ HIGH DYNAMIC RANGE (HDR) VIDEO FOR EXPANSIVE CONTRAST

RATIO AND COLOR ACCURACY

§§ SUPPORTS DELIVERY OF DUAL VIDEO STREAMS TO A DISPLAY

(IF SUPPORTED BY DISPLAY)

§§ 21:9 CINEMA ASPECT RATIO

§§ SUPPORTS BT.2020 COLORIMETRY

§§ UP TO 32 AUDIO CHANNELS WITH 1536 KHZ SAMPLING RATE

§§ SUPPORT DPCP/EDID/CEC/DDC

§§ LATCHING CONNECTORS PREVENT ACCIDENTAL DISCONNECTION

§§ PLUG AND PLAY, NO SOFTWARE TO INSTALL. THE SOURCE SIDE

CONNECTOR CONNECTS TO THE SOURCE, AND THE DISPLAY SIDE

CONNECTOR CONNECTS TO THE DISPLAY

§§ HYBRID CONSTRUCTION USES BOTH COPPER AND FIBER.

NO EXTERNAL POWER IS REQUIRED

§§ ULTRA-THIN, FLEXIBLE CABLING MAKES IT EASY TO PULL THROUGH

TIGHT SPACES AND NAVIGATE CORNERS AND BENDS WITH LOW

RISK OF SIGNAL LOSS

§§ FIBER TECHNOLOGY GREATLY REDUCES EMI/RFI EMISSIONS

§§ TRIPLE-SHIELDING FURTHER PROTECTS AGAINST INTERFERE NCE

TO ENSURE OPTIMAL SIGNAL QUALITY

§§ FEATURES ZINC ALLOY CONNECTORS FOR ENHANCED DURABILITY

DISPLAYPORT 1.4 ACTIVE OPTICAL CABLE, 8K, 32.4 GBPS DATA SHEET

OVERVIEW

Produkt Specifikationer

Mærke:	Black Box
Kategori:	AV forlænger
Model:	AOC-HL-DP4-50M
Type:	AV sender & modtager
Antal pr. pakke:	1 stk
Produktfarve:	Sort
Bluetooth:	Ingen
Opbevaringstemperatur (T-T):	-10 - 70 °C
Relativ luftfugtighed ved drift (H-H):	10 - 85 %
Relativ luftfugtighed ved opbevaring (H-H):	5 - 89 %
HDCP:	Ja
Driftstemperatur (T-T):	0 - 70 °C
Maksimal opløsning:	7680 x 4320 pixel
Forbindelsesteknologi:	Ledningsført
Certificering:	CE, FCC
DC-in-stik:	Ingen
Kabellængde:	50 m
AUX-indgang:	Ingen
Bæredygtighedscertifikater:	RoHS
Integreret antenne:	Ingen
Plug and play:	Ja
Firmware kan opgraderes:	Ingen
Maksimal overførselsafstand:	50 m
DisplayPort-version:	1.4
Ekstern strømadapter:	Ingen
Monteringssæt:	Ingen
Line-in:	Ingen
Stik 1:	DisplayPort
Stik 2:	DisplayPort
Stik 1 køn:	Hanstik
Stik 2 køn:	Hanstik
Stativ-montering:	Ingen
Stikforbindelse kontakter plettering:	Nikkel
HDCP-version:	2.2
HDBaseT-port:	Ingen
Kabeldiameter:	4.8 mm
Båndbredde:	34200 MB/s
3,5 mm ind:	Ingen
AUX udgang:	Ingen
DisplayPorts udgang:	2
HDBaseT certificeret:	Ingen
Udvidet display identifikationsdata (EDID):	Ja
Magnetisk afskærmet:	Ja
3,5 mm ud:	Ingen
Materiale for kapper:	Lav røg ingen halogen (LSZH)
Kabelmateriale:	Fiber optic/Copper
HDCP gennemgang:	Ja
CEC gennemgang:	Ja
DisplayPort Content Protection (DPCP):	Ja
Låsestik:	Ja
Antal afskærmningslag:	3
