Side 1/2

Bluetooth Audio Receiver for Mixers & Active PA/DJ Systems

Features:

XLR output Bluetooth audio receiver for mixers and active PA speakers

Connects smartphones & laptop to audio broadcast systems via Bluetooth to amplify music or

other audio

One blafili XLR Bluetooth audio receiver for mono audio

Two blafili XLR units can be linked in order to receive a stereo signal

Internal rechargeable battery provides 10 hours of operation

USB Type-C port for charging via any 5V USB power source

Stable connectivity over a 32.8 ft range (line-of-sight without obstacles). Gives you ample coverage

for parties, events and weddings

Support to connect any computer as a USB sound card

Note: blafili XLR may not be fully charged upon purchase. While it is safe to use it right away, charging for 2 hours

before initial use will ensure a full charge and the best performance.

Specifications:

Bluetooth profiles: 5.1, A2DP, AVRCP

Supported Bluetooth Codecs: SBC,

AAC, aptX, aptX LL, aptX HD

Balanced Audio Output: XLR male

Audio Inputs: Bluetooth and USB-C

XLR Output level: 1.23V RMS

Bluetooth range: Up to 32.8 feet (10 m)

Frequency band: 2402 to 2480MHz

USB charging: Type-C 5V, 500mA

USB-C Charging Port

/Audio Input

PAIR LED Status:

Flash blue and red alternately:

in pairing mode

Cyan = aptX

Green = aptX HD

Blue = SBC

Pink = AAC

TWS LED Status:

Solid blue: successful TWS connection

Flashing blue: TWS connecting

Turn ON / OFF TWS: Hold the “TWS”

button for about 3s to force the device to

enter / exit the TWS pairing mode (Turn

ON blafili XLR First)

Reconnect: short press “TWS” when out

of connection

CHG LED Status:

Solid red: charging

Off: fully charged

Red LED flashes 5 times every minute:

battery low needs to recharged again

PAIR LED

PAIR,

Power ON/OFF button

TWS LED

TWS button

Battery Status LED

XLR Output

Rechargeable battery: Built-in lithium-ion 320mAh

Battery life: Up to 10 hours

Recharging time: Up to 2 hours

A2DP frequency response: 20 Hz - 20 kHz (ref 1

kHz, ± 3 dB)

USB DAC resolution: 16-bit / 48 kHz

Dimensions: 117 x 30 x 25 mm

Weight: 0.09 lbs / 40 g

Controls:

Turn blafili XLR ON / OFF: Hold the

“PAIR” button for about 3s to Turn ON /

OFF the device

Play / Pause: short press “PAIR” when

playing music

Reconnect: short press “PAIR” when

out of connection

White = aptX LL

Bluetooth Pairing a Single blafili XLR:

1. Power on your Bluetooth device.

2. Press and hold the PAIR button for 3 seconds on blafili XLR. The PAIR LED will flash blue and red

alternately while blafili XLR is in pairing mode . (Time out: 2 minutes)

Stereo-Linking TWO blafili XLR Units:

1. Follow steps 1-5 in the Bluetooth Pairing a Single blafili XLR section to connect the 1st unit of blafili

XLR, and follow step 2 to turn on the 2nd blafili XLR.

2. Press and hold the TWS button for 3 seconds on the first blafili XLR. Then press and hold the TWS

button for 3 seconds on the secondary blafili XLR.

3. Both blue TWS LEDs will blink while each blafili XLR searches for the other .(Time out: 2 minutes)

4. When they are successfully linked, the blue TWS LEDs on both units will be lit solid.

3. Navigate to your Bluetooth device’s setup screen, find “blafili XLR” and click/connect.

4. When paired successfully, the PAIR LED will illuminate solid color:

Note: Double press PAIR button to enter pairing mode again.

Note: Before pairing, turn off Wi-Fi on your device and stop any audio playback.

Note: If your Bluetooth device prompts for a pairing code, enter “0000”.

5. Adjust the volume on your Bluetooth device or connected mixer/powered speaker.

To erase previous pairing settings, first turn on blafili XLR, then hold the “PAIR” and “TWS”

buttons until all the THREE lights(PAIR: White & TWS: Blue & CHG: Red) are lit indicating that

pairing settings have been erased. You can now pair to a new device.

Note: When two units are stereo-linked and connected to Bluetooth, the primary unit will send

the left channel audio, and the secondary unit will send the right channel audio. If it is wrong,

just exchange the position of the two blafili XLR units on your mixer.

Front View Side View Back View

Cyan = aptX

Green = aptX HD

White = aptX LLBlue = SBC

Pink = AAC

When TWO blafili XLR devices are paired successfully, the PAIR LED of the primary blafili XLR

will illuminate solid color:

Cyan = aptXBlue = SBC
