P030A Split Phase Fusion Box PRO
Please read this manual before use and follow its guidance. Keep this manual for future reference.
User Manual
Please read this manual before use and follow its guidance. Keep this manual for future reference.
BRIEF INTRODUCTION
Split Phase is used for connecting two EP500Pro or AC300+B300 (exclusive for
the 100 -120V version)by bonding them effectively into one larger power system to
double the output power, voltage, and capacity.
- 01 -
(EP500Pro Split Phase Power System)
SAFETY INSTRUCTION
●P030A Split Phase Fusion Box Pro is only designed for AC300 and EP500Pro
models(100-120V version), it is forbidden to connect P030A to any other power
source such as wall outlet, power station, generator or grid.
●DO NOT place the P030A near heat sources. It is prohibited to place the P030A
in an environment with flammable, explosive gas, or smoke.
●DO NOT attempt to replace any internal/exterior component of the equipment by
anyone other than authorized personnel.
- 02 -
(AC300 + B300 *2 Split Phase System)
IN THE BOX
- 03 -
Split Phase Fusion Box Pro
x1 pcs
Certificate of QC Pass
x1 pcs
User Manual
x1 pcs
Communication Cable
x1 pcs
●DO NOT operate P030A in wet conditions. If the equipment becomes wet,
please let the unit dry completely before using.
●Please ensure proper ventilation while in use, inadequate ventilation may cause
permanent damage to P030A.
●Warning: DO NOT insert foreign objects into any ports of the P030A. P030A
generates the same potentially lethal AC power as a household wall outlet.
Please use it carefully and keep children away from it.
●In case of fire, only a dry powder fire extinguisher is suitable for the product.
a.NEMA L14-30: has an L-shaped neutral blade. available in ratings to 30A, allow-
ing for 240V when supplied by split-phase power.
b. NEMA TT-30: connector which is the 120V/30 A recreational vehicle standard,
also known as RV 30. The TT-30R receptacle is commonly available in nearly all
RV parks in the United States and Canada.
c. Standard AC receptacle: wildly used in 100-120V areas, generates the almost
same AC power as a household wall outlet.
d.When Split Phase System installation finished successfully, both of the two LED
lights stay ALWAYS ON.
If the LED light is not active, please check the connection.
FEATURES OF P030A
- 04 -
a
b
c
d
LET`S GET STARTED
- 05 -
a
f
d
ce
b
CONNECTION 1 (Standard Mode)
Step1.
Connect two EP500Pro/AC300 with communication cables. (a-b)
Step2.
Plug the AC Input Cables into P030A from L14-30 receptacle of EP500Pro
/AC300. (c-d, e-f)
