USER MANUAL

On-Line UPS

1000VA/1500VA/2000VA/3000VA

Uninterruptible Power Supply System

CONTENT

USER MANUAL ....................................................................................... 1

1. Safety and EMC Instructions ............................................................ 1

1.1 Installation .......................................................................................... 1

1.2 Operation ............................................................................................ 9

1.3 Maintenance, servicing and faults .................................................... 10

1.4 Transport .......................................................................................... 13

1.5 Storage ............................................................................................. 13

1.6 Standards ......................................................................................... 14

2. Description of Commonly Used Symbols ..................................... 15

3. Introduction ...................................................................................... 16

4. Panel Description ............................................................................. 17

5. Connection and Operation .............................................................. 19

5.1 Inspection ......................................................................................... 19

5.2 Connection ....................................................................................... 19

5.3 Battery charge .................................................................................. 21

5.4 Turn on the UPS ............................................................................... 21

5.5 Test function ..................................................................................... 21

5.6 Turn oﬀ the UPS ............................................................................... 22

5.7 Audible alarm mute function ............................................................. 22

5.8 Operation procedure of external battery for long backup time model

(“S” model) ............................................................................................. 22

6. Operating Mode for All Models ....................................................... 24

6.1 Line mode ......................................................................................... 24

6.2 Battery mode .................................................................................... 25

6.3 Bypass mode .................................................................................... 25

6.4 NO output mode ............................................................................... 26

6.5 EPO (Emergency Power Oﬀ) ........................................................... 26

6.6 ECO mode (Economy mode) ........................................................... 26

6.7 Converter mode ................................................................................ 27

6.8 Abnormal mode ................................................................................ 27

7. Setting by LCD Module .................................................................... 28

8. Trouble Shooting .............................................................................. 30

9. Maintenance ...................................................................................... 32

Produkt Specifikationer

Mærke:	BlueWalker
Kategori:	Uafbrydelig strømforsyning (UPS)
Model:	PowerWalker VFI 1500RT LCD
Bredde:	438 mm
Dybde:	436 mm
Højde:	86.5 mm
Vægt:	19700 g
Produktfarve:	Sort
Skærmtype:	LCD
Pakkevægt:	22700 g
Formfaktor:	Reolbeslag/tårn
Relativ luftfugtighed ved drift (H-H):	0 - 95 %
Antal USB 2.0-porte:	1
Driftstemperatur (T-T):	0 - 40 °C
Støjniveau:	45 dB
Udgangseffekt:	1350 W
Pakkens dimensioner (BxDxH):	535 x 535 x 215 mm
Batteritype:	4x 12V / 7.2Ah
Opladningstid for batteri:	3 t
Medfølgende software:	Winpower
Indgangsfrekvens:	45/66 Hz
RS-232-porte:	1
Lydalarmer:	Ja
AC udgange, antal:	8 AC stikkontakt(er)
Indgående driftsspænding (maks.):	276 V
Output strømkapacitet (VA):	1.5 kVA
Indgående driftsspænding (min.):	120 V
Udgangs driftsspænding (min.):	208 V
Udgangs driftsspænding (maks.):	240 V
Typisk backup tid ved halv styrke:	- min.
Typisk backup tid ved fuld styrke:	4 min.
Nødstrøm Off (EPO):	Ja
Crestfaktor:	3:1
