The illustrations and descriptions herein are applicable to production as of the date of this Technical Data Sheet. Revised 6/30/15 R/A Printed in U.S.A.
The manufacturer reserves the right to, and does from time to time, make changes and improvements in designs and dimensions. © 2015 by Bobrick Washroom Equipment, Inc.
Cabinet — 18-8, type-304, 24-gauge (0.6mm) stainless steel. All-welded construction. Exposed surfaces have satin finish.
Equipped with a concealed locking device; opens with special key provided. Secured to concealed wall plate with pivot hinges.
Capacity: one box of 100 two-ply facial tissues.
Wall Plate — 18-8, type-304, 22-gauge (0.8mm) stainless steel.
Cabinet unlocks with special key provided, then swings down to replace box of 100 two-ply facial tissues.
Mount unit on wall or countertop apron with four #8 x 1-1/4" (4.2 x 32mm) sheet-metal screws (not furnished) at points
indicated by an . For plaster or dry wall construction, provide concealed backing to comply with local building codes, then S
secure unit with sheet-metal screws. For other wall surfaces, provide fiber plugs or expansion shields for use with sheet-metal
screws, or provide 1/8" (3mm) toggle bolts or expansion bolts.
Note: Provide a 2-1/4" (55mm) minimum clearance above unit to provide access to lock and 2-1/4" (55mm) clearance below
unit to allow tissue dispenser to swing down for refilling.
Surface-mounted facial tissue dispenser shall be type-304 stainless steel with all-welded construction; exposed surfaces shall
have satin finish. Cabinet shall be secured to a concealed wall plate with pivot hinges and equipped with a concealed locking
device that is opened only with special key provided. Unit shall hold one box of 100 two-ply facial tissues.
Surface-Mounted Facial Tissue Dispenser shall be Model B-8397 of Bobrick Washroom Equipment, Inc.,
Clifton Park, New York; Jackson, Tennessee; Los Angeles, California; Bobrick Washroom Equipment Company,
Scarborough, Ontario; Bobrick Washroom Equipment Pty. Ltd., Australia; and Bobrick Washroom Equipment
