Owner’s Manual

Precautions When Connecting

To prevent malfunction and equipment failure, always turn

down the volume, and turn o all the units before making any

connections.

Once the connections have been completed, turn on power to

your various devices in the order specied. By turning on devices

in the wrong order, you risk causing malfunction and/or damage

to speakers and other devices.

When powering up: Turn on the power to your guitar amp last.

When powering down: Turn o the power to your guitar amp rst.

Due to the characteristics of its analog circuitry, this unit’s CHECK

indicator may be lit (eect on) or unlit (eect o) when you turn

the power on.

Use of Battery

A battery was installed in the unit before it left the factory. The life

of this battery may be limited, however, since its primary purpose

was to enable testing.

If you handle batteries improperly, you risk explosion and uid

leakage. Make sure that you carefully observe all of the items

related to batteries that are listed in “USING THE UNIT SAFELY” and

“IMPORTANT NOTES” (supplied on a separate sheet).

When operating on battery power only, the unit’s indicator will

become dim when battery power gets too low. Replace the

battery as soon as possible.

Batteries should always be installed or replaced before connecting

any other devices. This way, you can prevent malfunction and

damage.

If the battery runs extremely low, the sound may distort or

the delay time may be shortened, but this does not indicate a

malfunction. If this occurs, please replace the battery.

OUTPUT/DIRECT OUT jacks

Connect to only the OUTPUT jack

DM-2W

The direct sound + delay sound is output.

Connect to the OUTPUT jack and the DIRECT OUT jack

DM-2W

Direct soundDelay sound

The delay sound is output from the OUTPUT jack, and the direct sound is

output from the DIRECT OUT jack.

Connect to the SEND/RETURN jacks of a guitar amplier

DM-2W

RETURN

Dummy plug

SEND

INPUT

If you’re using this unit in a parallel-connected eect loop, insert a dummy

plug into the DIRECT OUT jack so that only the delay sound is output to

the RETURN jack.

Caution When Using the RATE Jack

Use only the specied expression pedal (Roland EV-5; sold

separately). By connecting any other expression pedals, you risk

causing malfunction and/or damage to the unit.

Use the minimum volume of the EV-5 to specify the maximum

delay time, and use the REPEAT RATE knob of the DM-2W to

specify the way in which the delay time will change (i.e., the curve

of change).

Some settings of these knobs might not produce the correct

eect. Listen to the sound while you adjust the minimum volume

and the REPEAT RATE knob.

Depending on the setting of the INTENSITY knob, oscillation may

occur while you operate the pedal, causing the volume to increase

suddenly. Take care to avoid damaging the connected guitar amp

or speaker.

Changing the Battery

1. Hold down the pedal and

loosen the thumbscrew ,

then open the pedal upward.

* The pedal can be opened without

detaching the thumbscrew completely.

2. Remove the old battery from

the battery housing , and

remove the battery snap

connected to it.

3. Connect the battery snap to the new battery, and place

the battery inside the battery housing.

* Be sure to carefully observe the battery’s polarity (+ versus -).

4. Slip the coil spring onto the spring base on the

back of the pedal, and then close the pedal.

* Carefully avoid getting the battery snap cord caught in the

pedal, coil spring, and battery housing.

5. Insert the thumbscrew into the guide bush hole and

tighten it securely.

Specications

Nominal Input Level -20 dBu

Input Impedance 1 MΩ

Nominal Output

Level

-20 dBu

Output Impedance 1 kΩ

Recommended Load

Impedance

10 kΩ or greater

Power Supply Alkaline battery (9 V, 6LR61) (9 V, 6F22) or

Carbon-zinc battery

AC adaptor (PSA series: sold separately)

Current Draw 35 mA

* Expected battery life under continuous use:

Alkaline: 15 hours

Carbon: 5 hours

These gures will vary depending on the

actual conditions of use.

Dimensions 73 (W) x 129 (D) x 59 (H) mm

2-7/8 (W) x 5-1/8 (D) x 2-3/8 (H) inches

Weight 460 g / 1lb 1 oz (including battery)

Accessories Leaet (“USING THE UNIT SAFELY,” “IMPORTANT

NOTES,” and “Information”)

Alkaline battery (9 V, 6LR61)

Options

(sold separately)

AC adaptor (PSA-series)

Expression pedal: Roland EV-5

* 0 dBu = 0.775 Vrms

* This document explains the specications of the product at the

time that the document was issued. For the latest information,

refer to the Roland website.

9 V Battery

English

Main Features

Panel Descriptions

Before using this unit, carefully read the sections entitled: “USING THE UNIT SAFELY” and “IMPORTANT NOTES” (supplied on a separate sheet).

After reading, keep the document(s) where it will be available for immediate reference.

7This is a “WAZA CRAFT series” eect unit featuring analog circuitry painstakingly designed in every detail for the best possible sound.

7This is a painstakingly designed analog delay using carefully selected BBD components.

7In addition to the sound of the original DM-2, you’ll enjoy a custom tone that’s been fully tuned-up by BOSS engineers.

INPUT jack

This jack accepts signals coming from

a guitar or other musical instrument, or

another eects unit.

* The INPUT jack doubles as the power switch.

Power to the unit is turned on when you plug into the

INPUT jack; the power is turned o when the cable is

unplugged.

To prevent unnecessary battery consumption, be sure

to disconnect the plug from the INPUT jack when not

using the eects unit.

AC Adaptor

(PSA series: optional)

Electric Guitar

Guitar Amplier

REPEAT RATE knob

Adjusts the delay time. Turning the knob toward the right shortens the delay

time.

* Delay time (maximum)

S (standard): 300 ms, C (custom): 800 ms

DIRECT OUT jack

Only the direct sound is output from this

jack.

Guitar Amplier

RATE jack

If you connect an expression pedal (Roland EV-5) to this

jack, you can use it to control the delay time.

* Refer to “Caution When Using the RATE Jack.”

Roland EV-5

DC IN jack

Accepts connection of an AC Adaptor (PSA series; optional). By using an AC Adaptor, you can play without

being concerned about how much battery power you have left.

* Use only the specied AC adaptor (PSA series; optional), and connect it to an AC outlet of the correct

voltage. Do not use any other AC adaptor, since this may cause malfunction.

* If the AC adaptor is connected while a battery is installed, the power supply

is drawn from the AC adaptor.

* We recommend that you keep batteries installed in the unit even though

you’ll be powering it with the AC adaptor. That way, you’ll be able to

continue a performance even if the cord of the AC adaptor gets accidently

disconnected from the unit.

CHECK indicator

This indicator shows whether the eect is on or o, and also doubles as the battery check

indicator. The indicator lights when the eect is on.

* If you’re powering the unit with a battery and the CHECK indicator goes dim— or doesn’t

light at all—when you try to turn the eect on, the battery is near depletion and should be

replaced. For instructions on changing the battery, refer to “Changing the Battery.”

OUTPUT jack

The direct sound and delay sound are

mixed and output from this jack.

If a plug is inserted in the DIRECT OUT

jack, only the delay sound is output from

this jack.

Pedal switch

This switch turns the eect on/o.

Thumbscrew

When this screw is loosened, the

pedal will open, allowing you to

change the battery.

* For instructions on changing

the battery, refer to “Changing

the Battery.”

ECHO knob

Adjusts the volume of the delay sound. Turning the knob toward the right makes

the delay sound louder. If you turn the knob all the way to the left, only the

direct sound is heard.

INTENSITY knob

Adjusts the number of delay repeats. Turn this knob toward the right to increase

the number of repeats. If you turn the knob all the way to the left, a single delay

is heard.

* If you turn the knob all the way to the right, oscillation might occur.

Mode switch

Switches the tonal character.

S (standard) The original tone of the DM-2.

C (custom) A clear, customized tone with an extended delay time.
