CP1013 Thermal Printer
Baud Rate: 1200 up to 115,200
*Data Bit fixed at 8
Serial RS-232
Factory Default: 9600, 8, N, 1*
*Configuration cable AWT05-508092 needed to
change configuration
Paper Width: 58.4 mm / 2.3"
Print Speed: 90 mm / s max
Paper Out Sensor
Data Buffer: 10K
Resolution: 8 dot/mm (203 dpi)
Number of Columns: 24 or 32
*Configuration cable "AWT05-508092 (inlcuded)
Operating Temperature:
0° C to 50° C / 41° F to 104° F
Product Dimension (L x W x H):
4" x 3" x 1.8"
104 mm x 75 mm x 48 mm
Product Weight: 0.32 lb / 0.15 kg
Packaging Contents: CP103 printer, two paper rolls,
RS-232 serial/configuration cable, CD and manual
Note: Not available for EU/UK markets.
Options:
AWT05-508020: Universal 12VDC 2.5 AMP power supply
AWT05-507396: 12VDC US adapter 2.5 AMP
AWT25-501226: Direct DC power cable
AWT05-508093: CP103 to tin leads
AWT25-501825: CP103 to York Chiller cable
AWT25-501826: CP103 to 15-pin D sub
(Agricultural indicators)
AWT05-508092: RS-232 conguration cable to DB9
AWT05-505963: Null modem adapter DB9M to DB9M
AWT05-505964: Null modem adpater DB9M to DB9F
AWT05-505965: DB9 female gender changer
AWT05-505966: DB9 male gender changer
AWT05-507979: Receipt rolls,10 rolls per box, 40 mm dia
SpecicationsSpecications
