USER GUIDE

MiX Carts

T30C-P-AC-US! EVER Charging Cart AC for up to 30 devices w/180° front doors w/Back Panel

T30CB-P-AC-US! EVER Charging Cart AC for up to 30 devices w/180° front doors w/Rear Door

T30CD-P-AC-US! EVER Charging Cart AC for up to 30 devices w/270° front doors w/Back Panel

T30CDB-P-AC-US! EVER Charging Cart AC for up to 30 devices w/270° front doors w/Rear Door

T45C-P-AC-US! EVER Charging Cart AC for up to 45 devices w/180° front doors w/Back Panel

T45CB-P-AC-US! EVER Charging Cart AC for up to 45 devices w/180° front doors w/Rear Door

T45CD-P-AC-US! EVER Charging Cart AC for up to 45 devices w/270° front doors w/Back Panel

T45CDB-P-AC-US! EVER Charging Cart AC for up to 45 devices w/270° front doors w/Rear Door

T30C-P-DC-US! EVER Charging Cart USB for up to 30 devices w/180° front doors w/Back Panel

T30CB-P-DC-US! EVER Charging Cart USB for up to 30 devices w/180° front doors w/Rear Door

T30CD-P-DC-US! EVER Charging Cart USB for up to 30 devices w/270° front doors w/Back Panel

T30CDB-P-DC-US! EVER Charging Cart USB for up to 30 devices w/270° front doors w/Rear Door

T45C-P-DC-US! EVER Charging Cart USB for up to 45 devices w/180° front doors w/Back Panel

T45CB-P-DC-US! EVER Charging Cart USB for up to 45 devices w/180° front doors w/Rear Door

T45CD-P-DC-US! EVER Charging Cart USB for up to 45 devices w/270° front doors w/Back Panel

T45CDB-P-DC-US! EVER Charging Cart USB for up to 45 devices w/270° front doors w/Rear Door

CAPACITY per slot width! 1.00”! 1.25”! 1.50”

T30 Series 2 modules! 30! 24! 20! devices

T45 Series 3 modules! 45! 36! 30! devices

COMPATIBILITY Designed for various sized laptops & chromebooks, yet versatile

enough to support most tablets.

AC versions use the device manufacturer supplied AC power cord and adapter.

DC versions provide USB ports for USB to Lightning or USB to Micro USB plugs

! OUTSIDE DIMENSIONS 33.50”W x 26.00”D x 44.5”H"

! SLOT DIMENSIONS! 1.00” or 1.25” or 1.50” W x"

!!10.00”H or 12.00”H x 17”D"

! WEIGHT WITHOUT DEVICES! T30 series 176 pounds"

!!T45 series 190 pounds"

! POWER MANAGER! Digital"

! POWER REQUIREMENTS! 100 -125V ac, 12A, 50/60Hz;

!!220-240Vac, 8A, 50/60Hz;

!!optional USB output; 5Vdc, 2.4A

! SHIPPING Ships fully assembled, ready to load devices

! WARRANTY For product speciﬁc warranty information,

!!please visit: bretford.com/warranty

Part # 031-10609 rev December 2016

MADE IN USA

with globally

sourced products

www.bretford.com

Technical Speciﬁcations

POWER SWITCH

Located on the left side

of the cabinet, in the

Power Cord Shroud

POWER CORD SHROUD

Located on the left side

of the cabinet, provides

a cord winder for the

power cord, and an IEC

outlet for plugging in the

12-foot power cord

DIRECTIONAL LOCK CASTERS

When engaged, keep the

cart rolling in the right

direction. When

unengaged, allow the cart

to be easily maneuvered

into small spaces. Marked

with a Green Locking Tab

CORD PASS-THRU ON TOP

Allows devices to be

powered on top of the cart,

while their power cords are

plugged inside the cart.

DOOR LOCK SHROUD

Protects the padlock

and the locking

handle during

transport

DURABLE PLASTIC TOP

Provides a soft, skid-

resistant platform for

objects placed on top of

the cart.

WARNING: Maximum

weight restriction on top

shelf = 25 pounds.

USER GUIDE | MiX Carts // EVER CARTS

SETTING THE COMBINATION LOCK

Your new EVER Cart comes equipped with a resettable Combination Padlock. You can program the

lock with your own combination. The lock starts with 0-0-0-0. Follow the directions with the look for

changing the combination. Remember to depress the shackle before un-engaging it from the lock.

General Use

UNIQUE POWER ACCESS CENTER

Directly behind the left front door is a

cutout for the following:

•

A short power whip which provides

a single outlet for plugging in a

device on the top of the cart,

accessible through the Cord Pass-

Thru.

•

A Circuit Breaker rated for 2 amps

that is tied to that short power whip.

•

A USB Port which allows for

upgrades and updates to the Power

Manager inside the cart, as power

requirements might change for

future decides. This truly is a

Future-Proof Cart!

REAR SECURITY PANEL

VERSION

Can be securely held in place

with accessory Security Bolts, in

the hardware pack Panel easily

lifts off to expose the back of the

cart, where the adapters and

cord sets are kept in cable bins.

Also access to the removable

MiX Modules

REAR LOCKING DOOR

VERSION

Hinged rear door provides easy

access to the back of the cart.

Door locks in place with a key.

Keys found in the Hardware

Pack.

Rear Access Versions

180° DOORS

VERSION

Doors open wide to provide

access to the devices inside the

cart. Do not fold back agains

the sides of the cart.

270° DOORS

VERSION

Fold-back front doors swing

around, out of the way, snug

against the sides of the cart.

Front Door Versions

Produkt Specifikationer

Mærke:	Bretford
Kategori:	Oplader til mobilenhed
Model:	T30CD-P-AC-US
Type:	Bærbar enhedsadministrationsvogn
Vekselstrømsindgangsspænding:	120 V
Vekselstrømsindgangsfrekvens:	50 - 60 Hz
Bredde:	851 mm
Dybde:	660 mm
Højde:	1130 mm
Vægt:	79800 g
Produktfarve:	Grå
Strøm:	12 A
Husmateriale:	Stål
Kabler inkluderet:	Vekselstrøm
Placering:	Gulv
Håndtag:	Ja
Antal hylder:	2 hylder
Antal understøttede enheder:	30
Låsning:	Ja
Justerbare hylder:	Ja
Understøttede bærbare enheder:	Tablet
Spaltebredde:	25.4 mm
Slothøjde:	254 mm
Spaltedybde:	431.8 mm
