INSTALLATION GUIDE

Model ERV70S

(side ports)

Model ERV70T

(top ports)

Models HRV80S

and HRV90S*

(side ports)

Models HRV80T

and HRV90T*

(top ports)

* These products earned the ENERGY STAR

by meeting strict energy efficiency guidelines set by Natural Resources

Canada and the US EPA. They meet ENERGY STAR requirements only when used in Canada.

RESIDENTIAL INDOOR USE ONLY

! !

READ AND SAVE THESE INSTRUCTIONS

22633 rev. 05

VB0262

VB0269

VB0263

VB0272

Broan-NuTone LLC; Hartford, Wisconsin www.broan-nutone.com 800-558-1711

For additional information - visit www.broan-nutone.com

Because of the amount of models covered in this publication, the illustrations are typical ones. Some details of your unit may be slightly

different than the ones shown.

Please take note that this manual uses the following symbols to emphasize particular information:

Identifies an instruction which, if not followed, might cause serious personal injuries including possibility of death.

Identifies an instruction which, if not followed, may severely damage the unit and/or its components.

NOTE: Indicates supplementary information needed to fully complete an instruction.

WARNING

CAUTION

ABOUT THIS GUIDE

ABOUT THESE UNITS

LIMITATION

For residential (domestic) installation only. Installation work and electrical wiring must be done by a qualified person(s) in accordance with

all applicable codes and standards, including fire-rated construction codes and standards.

WARNING

TO REDUCE THE RISK OF FIRE, ELECTRIC SHOCK, OR INJURY TO PERSON(S) OBSERVE THE FOLLOWING:

1. Use this unit only in the manner intended by the manufacturer. If you have questions, contact the manufacturer at the address or

telephone number listed in the warranty.

2. We recommend that your unit be inspected by a specialized technician once a year.

3. Before servicing or cleaning the unit, disconnect power cord from electrical outlet.

4. This unit is not designed to provide combustion and/or dilution air for fuel-burning appliances.

5. When cutting or drilling into wall or ceiling, do not damage electrical wiring and other hidden utilities.

6. Do not use the units with any solid-state speed control device other than the corresponding ones listed below:

7. This unit must be grounded. The power supply cord has a 3-prong grounding plug for your personal safety. It must be plugged into a

mating 3-prong grounding receptacle, grounded in accordance with the national electrical code and local codes and ordinances.

Do not remove the ground prong. Do not use an extension cord.

8. Do not install in a cooking area or connect directly to any appliances.

9. Do not use to exhaust hazardous or explosive materials and vapors.

10. When performing installation, servicing or cleaning the unit, it is recommended to wear safety glasses and gloves.

11. Due to the weight of the unit, two installers are recommended to perform installation.

12. When applicable local regulations comprise more restrictive installation and/or certification requirements, the aforementioned requirements

prevail on those of this document and the installer agrees to conform to these at his own expenses.

MAIN CONTROL AUXILIARY CONTROL

VT8W, VT7W, VT4W OR VT6W 59W, VB20W, VB60W

CAUTION

1. To avoid prematurate clogged filters, turn OFF the unit during construction or renovation.

2. Please read specification label on product for further information and requirements.

3. Be sure to duct air outdoors – Do not intake/exhaust air into spaces within walls or ceiling or into attics, crawl spaces, or garage.

4. Intended for residential installation only in accordance with the requirements of NFPA 90B.

5. Do not run any air ducts directly above or closer than 2 ft to any furnace or its supply plenum, boiler, or other heat producing appliance.

If a duct has to be connected to the furnace return plenum, it must be connected not closer than 9’ 10” from this plenum connection to

the furnace.

6. The ductwork is intended to be installed in compliance with all applicable codes.

7. When leaving the house for a long period of time (more than two weeks), a responsible person should regularly check if the unit

operates adequately.

8. If the ductwork passes through an unconditioned space (e.g.: attic), the unit must operate continuously except when performing

maintenance and/or repair. Also, the ambient temperature of the house should never drop below 65°F.
