SIS/SIG SERIES

SIDE INTAKE SUPPLY UNIT /

SIDE INTAKE GALVANIZED SUPPLY UNIT

OPERATION INSTRUCTIONS AND PARTS MANUAL

SIS SERIES MODELS: SIS-9, SIS-10, SIS-12, SIS-15, SIS-18, SIS-20

SIG SERIES MODEL: SIG-9, SIG-10, SIG-12, SIG-15

GENERAL SAFETY

Rotating parts, (pulleys, shafts and belts) on fans should not be exposed. Where these components are not protected by ductwork, cabinets

or covers, appropriate guards should be employed to restrict exposure to rotating parts. Access doors should not be opened with the fan

operating to avoid foreign objects being drawn into the system. On initial start-up, a careful inspection should be carried out to ensure no

foreign material is present which could become airborne in the system.

Read installation and operation instructions carefully before attempting to install, operate or service Canarm/Delhi SIS/SIG Series Blowers.

Failure to comply with instructions could result in personal injury and/or property damage. Retain instructions for future reference.

BEFORE YOU BEGIN

Inspect unit for damage, report any shipping damage to carrier. Check all fasteners, re-tighten as required. Rotate the blower wheel by

hand to ensure free rotation. If rubbing occurs, loosen the set screw(s), re-position the wheel to the shaft center, re-tighten set screws.

INSTALLATION

Remove hood and filters from inside the cabinet. Caulk top of curb before setting unit in place. (Curb must be smaller than unit “A”

dimension). Secure unit to curb through holes located around the bottom of the unit. Tighten wheel set screw.

BOTTOM VIEW

SIZE QUANTITY

SIS-9 24 3/8" 19 3/8" 10 1/4" 11 13/16" 6 9/32" 7 1/16" 7 1/16" 19 1/4" 16 9/16" 21 1/4" 16" x 24" x 1" 1

24"x 24" 70

SIS-10 28 3/8" 21 3/8" 11 3/8" 13 1/8" 7 5/8" 8 1/2" 8 1/2" 20 1/2" 18 9/16" 25 3/4" 15" x 20" x 1" 2

28"x 28" 87

SIS-12 32 3/8" 24 5/8" 13 7/16" 15 5/8" 8 3/8" 9 15/32" 9 15/32" 25 3/8" 21 9/16" 30 3/4"

20" x 25" x 1" &

16" x 25" x 1"

1 & 1 32"x 32" 117

SIS-15 36 3/8" 28 3/8" 15 7/8" 18 5/8" 8 7/8" 8" 12 1/2" 31 3/16" 25 13/16" 33 1/2" 20" x 28 1/2" x 1" 2

36"x 36" 175

SIS-18 36 3/8" 42 1/2" 18 7/8" 21 7/8" 7 1/4" 6 1/4" 11 1/4" 35 5/8" 32 11/16" 40 1/4"

20" x 25" x 1" &

16" x 25" x 1"

2 & 2 36"x 36" 262

SIS-20 44 3/8" 49" 24 3/4" 24 3/4" 9 13/16" 5 3/16" 14 7/16" 38 5/8" 35 9/16" 45 1/2"** 20" x 25" x 1" 6

44"x 44" 497

SIG-9 22" 24" 10 1/4" 11 7/8" 5" 3 7/8" 7 7/8" 16" 18 1/8" 19 7/8" 16" x 25" x 1" 1 21 7/8" x 21 7/8" TBA

SIG-10 22" 24" 11 7/8" 13 1/4" 4 7/16" 3 1/4" 6 7/8" 16" 18 1/8" 19 7/8" 16" x 25" x 1" 1 21 7/8" x 21 7/8" TBA

SIG-12 32" 32" 13 3/4" 15 7/8" 8 1/16" 4 1/4" 14" 25" 24 5/8" 25"

16" x 25" x 1" 2

31 7/8" x 31 7/8" TBA

SIG-15 32" 32" 16 1/8" 18 7/8" 6 9/16" 3" 12 7/8" 25" 24 5/8" 25" 16" x 25" x 1" 2 31 7/8" x 31 7/8" TBA

* Curb size to be smaller than inside cabinet to allow for flashing and roofing.

** Includes filter section

*INSIDE

CABINET

UNIT WEIGHT (LBS)

(without motors & drives)

SIG MODELS

SIS MODELS

GHLMZ

FILTERS

MODEL A B D E F

SIS_SIG-M-07_20_16 Page 1 of 5

REMOVE CAP FOR

FILTER ACCESS

Ø5/16" HOLES

FOR FASTENING

TO CURB

MOTOR, PULLEYS & BELTS (See Table next page)

1. Mount the blower pulley on the blower shaft and tighten the set screw securely on the key of the shaft.

2. Mount the motor pulley on the motor shaft. Leave some clearance between the pulley and the motor end bell. Tighten the set screws

on the key of the motor shaft.

3. Install the motor on the motor platform using the hardware provided.

4. With the platform in its minimum position, install the V-belt within the pulley grooves. Position the motor on the motor platform to

ensure proper pulley alignment (see Figure 1) and secure to the motor platform. (A straight edge across the face of the driven pulley

should be parallel to the belt once proper alignment has been achieved).

Note: Adjustments in the variable speed pulley require pulley re-alignment.

SIS SERIES

SIG SERIES

5. Pivot the motor platform to tension the V-belt and lock in place using the 2 bolts on both sides of the blower. (Ideal belt tension

is the lowest tension at which the belt will not slip during start up.) As shown in illustration to right, a proper deflection of 1/64 of

the belt span is desired for belt tension.

6" 7" 8" 9" 10" 12"

824-1125 RPM

680-929 RPM 580-792 RPM 505-690 RPM 447-611 RPM 401-548 RPM 533-455 RPM

4L37 4L39 4L41 4L42 4L44 4L45 --

4L39 4L41 4L42 4L44 4L46 4L47 --

4L42 4L44 4L46 4L47 4L49 4.51 --

-- -- -- -- 4L55 4L57 4L60

-- -- -- -- 4L59 4L60 4L64

Motor Pulley

Cast Iron

Blower Pulley

Cast Iron

RPM

Range

SIS-9

SIG-9

SIS-10

SIG-10

SIS-12

SIG-12

SIS-15

SIG-15

SIS-18

SIG-18

SIS-20

BEL

T LENGTH

BASED ON

MOTOR FRAME

HB47T 1630 - 1232

B37 B39 B43

-- -- --

HB57T 1329 - 1005 B39 B41B44

-- -- --

HB67T 1121 - 848B40B43B46

-- -- --

HB77T 969 - 733 B42B44 B48 B52 B56

HB87T 854 - 645B43B46B49B54 B57

HB97T 763 - 577 B46B48 B51 B56 B59

HB107T 690 - 521 B47 B50 B53 B58 B61

HB117T 629 - 476 B49 B51 B55 B59 B63

HB127T 578 - 437

B51 B53 B55 B61 B64

HB137T 535 - 404 B53 B55 B58 B63 B66

HB157T466 - 352 B57 B59 B62

B70

HB187T 390 - 295 B64 B65 B68

-- -- --

HB77T

756 - 568 -- -- --

B51 B54

HB87T

667 - 500 -- -- --

B53 B56

HB97T

596 - 447 -- -- --

B55 B58

HB107T

538 - 404-- -- --

B56 B60

HB117T

491 - 368 -- -- --

B58 B61

HB127T

452 - 339 -- -- --

B60 B63

HB137T

418 - 314-- -- --

B62 B65

HB157T

364 - 372 --

-- -- -- B69 --

HB87T 854 - 645 -- -- -- -- --

B79

HB97T

763 - 577 -- -- -- -- --

B81

HB107T

690 - 521 -- -- -- -- --

B83

HB117T

629 - 476 -- -- -- -- --

B84

HB127T

578 - 437 -- -- -- -- --

B86

HB137T

535 - 404-- -- -- -- --

B88

HB157T

466 - 352 -- -- -- -- --

B91

HB187T

390 - 295 -- -- -- -- --

B97

HB117T

828 - 686 -- -- -- -- -- B86

HB127T

756 - 618 -- -- -- -- -- B88

HB137T

697 - 575 -- -- -- -- -- B90

HB157T

616 - 509 --

-- -- -- -- B93

12.4 X 2B

830 - 700 -- -- -- -- -- B90

13.6 X 2B

759 - 631 -- -- -- -- -- B92

FOR FRACTIONAL HP APPLICATIONS "4L" BELTS MAY BE SUBSTITUTED BY ADDING 2" TO THE SPECIFIED "B" BELTS. Eg. B50 BELT = 4L52

BLOWER MODEL

BELT LENGTH

BASED ON

MOTOR FRAME

3 1/4 CAST IRON BLOWER PULLEY - DIAMETER & RPM RANGE

48 FRAME

56 FRAME

IVL44

O.D. 4.15"

SIS-9 / SIG-9

SIS-10 / SIG-10

SIS-12 / SIG-12

SIS-15 / SIG-15

SIS-18 / SIG-18

DOUBLE GROOVE

D8600

O.D. 6"

8550

O.D. 5.35"

213, 215T

FRAME

182, 184T FRAME

(DEDUCT 2" FOR

56, 143, & 145T)

48 FRAME

(ADD 1" FOR 56

FRAME)

MODELS SIS-15,

SIG-15 & SIS-18,

SIG-18

143, 145T FRAME

8325

O.D. 3.25"

143T & 145T

FRAME

8400

O.D. 4.15"

182, 184T FRAME

(DEDUCT 2" FOR

56, 143, & 145T)

SIS/SIG SERIES

SIDE INTAKE SUPPLY UNIT / SIDE INTAKE GALVANIZED SUPPLY UNIT

SIS_SIG-M-07_20_16 Page 2 of 5

MOTOR, PULLEYS & BELTS (See Table below)

WARNING

EXCESSIVE BELT TENSION IS THE MOST FREQUENT CAUSE OF BEARING WEAR AND RESULTING NOISE.

PROPER BELT TENSION IS CRITICAL FOR QUIET EFFICIENT OPERATION.

Ideal belt tension is the lowest value under which belt slip will not occur at peak load conditions.

BELT ALIGNMENT

FIGURE 1
