Side 1/2

Network Video Recorder

VK-64/VK-16 v2.2

Viewer Operation Guide

This guide explains a basic operation of VK Viewer. For more detailed explanations, refer to the Administrator's

Manual Setup Guide and .

* This guide also applies to VK-Lite Viewer (simplified version of VK Viewer).

Location/Zone

[Location] Groups of zones.

[Zone] Areas in which

cameras are located.

Camera Selection Area

Thumbnails from all the

cameras located in each zone

are displayed. The number

of thumbnails represents the

number of cameras in the zone.

Video Window

Live or recorded video from

a camera is displayed in this

window.

Viewing Area

Video Windows are displayed

here.

Timeline

Recording information and

events that have occurred are

displayed.

Playhead

The time of the video currently

being played is displayed.

Launching VK Viewer

Double-click the [VK Viewer v2.2] desktop icon.

The connect option menu (Startup Screen) for the Storage Server is

displayed.

* Different icon is displayed for VK-Lite.

Select [Master Storage

Server] and click

[Connect].

If you select [ ] or [localhost Use

IP address Login], the [ ] dialog

box appears.

Enter your [User Name]

and [Password] and click

[Login].

VK Viewer starts up.

Make a note of your user

name and password here.

User Name

Password

Select [File] [Exit] in →

the menu bar.

VK Viewer shuts down.

Memo

Note that the login information is case-sensitive.

Check with the system administrator for your user name and

password.

If you note down your user name and password in this guide,

take particular care to ensure that this does not lead to unwanted

disclosure of your login details.



Exiting VK Viewer

Memo

If you are using a screensaver on your PC, the screen saver may

start up after VK Viewer shuts down. To restore the viewing window,

simply move the mouse.



VK Viewing Screen

Memo

For information on operations such as changing the video window display position, size or layout, see "Chapter 5 Viewer Reference" in the

Administrator's Manual.

The camera selection area, timeline and video window title bars can all be hidden using options in the [View] menu in the menu bar.



Video Window

Video display

Live or recorded video is displayed.

Live video The video currently being shot.

Recorded video Video recorded on the storage server.

Title bar

The camera name and the video status are displayed.

The title bar color changes according to the displayed video content, as shown below.

Title bar color Video status

During live video display Black Live

During recorded video

display Black Recording time

COPY

Controlling A Camera

2Select [View] [Camera Control] in the →

menu bar.

The [ ] panel appears.Camera Control

3Click [Get Control] in the [Camera Control]

panel.

Once you have the camera control, all the buttons in

the [ ] panel become active.Camera Control

Memo

For details, see "Chapter 5 Viewer Reference" in the .Administrator's Manual

If you have the camera control and do not make any changes for 30

seconds, a message appears saying "Control will be lost in 10 seconds".

You will then lose the control if it is left for another 10 seconds.

To control a camera while it is recording, check with the administrator and

review the procedure beforehand.



Playing Recorded Video

1Click a video window of the camera you want to play.

3Click the time you want to play.

The recorded video appears in the selected video window.

2Click and drag the time bar to the left or right to change the

playback time.

1Click a video window of the camera you want to play.

Rewind Play/Pause

Fast

forward

2Click [Jump to Time].

The [Jump To Time] dialog box

appears.

3Select a date and time and

click [OK].

The recorded video appears in the

selected video window.

Memo

If a message appears saying "Can't get

camera control", system administration

privileges of other Viewers of tools may

be controlling the camera. Contact the

administrator.

Depending on your camera, some

functions may be unavailable. For more

details, see Administrator's Manual.



Memo

Rewind and nudge back cannot be used when viewing recorded MPEG-4 video. *MPEG-4 video cannot be recorded with VK-Lite.

QuickTime version 6.5.1 or later is recommended.

On Windows Vista, videos cannot be saved into the Program Files folder or Windows folder on the system drive.



Jump to next event

You can use these controls to play, pause, rewind, fast forward, nudge

forward or back and jump to the previous or next event. You can also

change the rewind and fast forward speeds sequentially from 1x 2x →

→ → 5x 10x.

This button switches the video display from recorded video back to live

video.

You can save recorded videos to any location in .mov format.

The saved videos can then be viewed in QuickTime Player or any other

player that supports the .mov format.

File-Saving format QuickTime (file extension: mov)

Recording duration Max. 1 hour

These controls change the level of detail shown in the timeline.

[Zoom In] To view the timeline in more detail.

[Zoom Out] To view the entire timeline at once.

Jump to previous event Nudge forward

Pan (left/right) and Tilt (up/down)

These controls move the PT camera in the

direction of the arrows.

Pan and tilt either by briefly clicking an arrow, or

by clicking and holding the arrow.

Zoom

Click and drag the zoom slider to zoom in or out.

Pan/Tilt/Zoom speed

Set the camera pan/tilt, and zoom speed.

Pan/Tilt/Zoom Control

Adjusting/Saving Played Video

1Click a video window for the camera you want to control.

[ ]Preset

Choose one of preset positions from a list.

Nudge back

Using the timeline to play video

Controlling playback

Playing video of a specified time

Zooming in and out on the timeline

Returning to Live Video

Saving a specified video

COPY

Produkt Specifikationer

Mærke:	Canon
Kategori:	Foto/video software
Model:	VK-16 v2.2
Type:	Video editor
Understøttede billedformater:	JPG
Video komprimeringsformater:	MPEG4
Kompatible operativsystemer:	Windows XP Professional (SP2, SP3), Windows Server 2003 Standard Edition (SP2), Windows Server 2003 R2 Standard (SP2), Windows Vista Business/Enterprise/Ultimate (SP1), Windows Server 2008 Standard
Minimum plads på lagerdisk:	2048 MB
Minimum systemkrav:	1024 x 768
Minimum processor:	Pentium 4, 2.2GHz
Minimum RAM:	1024 MB
Anbefalet RAM:	1536 MB
Anbefalet processor:	Pentium4, 3.4GHz
Anbefalet plads på lagerdisk:	20 GB
