INTRODUCTION
HyperStat is a wall-mount thermostat. Its thoughtful design ensures that it blends into most
commercial spaces while still giving a fresh and contemporary feel compared to dated
building control interfaces.
PACKAGE CONTENTS
• Mounting accessories
SPECIFICATIONS
Power
Power
Power
PowerPower
Power Source: 24V /DC - AC input (+/ 15%)
Peak consumption: 1.4VA Maximum
Operat
Operat
Operat
OperatOperating range
ing range
ing range
ing rangeing range
Temperature 32 to 122°F (0°C to 50°C)
Humidity 20-85% non-condensing.
Commu
Commu
Commu
CommuCommunication
nication
nication
nicationnication
S ensor bus for daisy chained sensor communication and low power 3V dc.
4-wire interface for RS 485 communication @ 115200 baud and 5V
DC, A 100m power source
9 - - 00 928 MHz Mesh IEEE 802.15.4 compliant, for communications to CCU
Bluetooth: BLE 4.1 for commissioning, and communication to wireless sensors
Onboa
Onboa
Onboa
OnboaOnboard Senso
rd Senso
rd Senso
rd Sensord Sensors
rs
rs
rsrs
Temperature range of 32 to 122°F with an accuracy of +/-1°F
Humidity 0 to 100% with an accuracy of 2%
CO2 sensor with a range of - - 0 40,000 ppm, accuracy of +/ 30ppm
VOC sensor; Typical Accuracy: 15% of measured value; TVOC: 0 - 60,000
ppb;
Occupancy sensor based on passive infrared (PIR) with a
detection range of
4m with a 15 degree angle-
Light Sensor. Ambient light sensor • <100 LUX resolution • High-accuracy UV
index sensor • Matches erythermal curve
Sound sensor with 40- 120dB response for 100Hz to 10KHz
PM2.5, PM10 sensor (optional). Detection range of 0-1000µg/m3 and accuracy
of +/- 0- - -10µg/m3 (PM2.5, 100µg/m3) or +/ 25µg/m3 (PM10, 0
100µg/m3). - Maximum long term mass concentration precision limit drift:
• 0 to 100 µg/m3 ±1.25 µg/m3/year
• 100 to 1000 µg/m3 ±1.25 % mV/year
Inpu
Inpu
Inpu
InpuInputs
ts
ts
tsts
2 x 10K Type- 2 thermistor inputs with 2% accuracy
2 x 0- A - 10V nalog voltage inputs with 2% detection accuracy (2 10V)
Touch slider for temperature control along with 3 mechanical buttons
HYPERSTAT
(7C- -C2W-X)HS
INSTALLATION GUIDE
Scan this QR
code to get a
more detailed
version of the
Installation
Guide
For more information, contact your local Carrier Controls Expert
©2023 Carrier. All Rights Reserved. Cat. No. 11- -9808 59-01
Outputs
Outputs
Outputs
OutputsOutputs
6 x Relays rated for 24V DC/1A
3 0- - A x 10V or 4 20m analog outputs
2.8" 240x320 pixel TFT display
PRECAUTIONS
:
:
:
: :
• Failure to wire devices with correct polarity when using a shared transformer,
may result in damage to any device powered.
• Never connect or disconnect the wiring with the power ON.
• Do not allow the powered wires to touch the circuit boards.
• Always install complying with all state and local codes.
• Do not assemble the front to the back plate while it is powered on.
• Once Installed the HyperStat takes seven days to auto-calibrate and settles at a
steady state value.
• Avoid mechanical stress on the CO2 sensor to get accurate readings.
MOUNTING
1. HyperStat Interface - Conventional
5. Rubber cover 2
2. HyperStat Main 6. Gang Box
3. Allen head screws
7. PHP screws
4. Rubber cover 1 8. Backplate
