Shuttle Brewer & Airpot/Shuttle Brew ers

Operation and Instruction Man u al

For Models P300E, P400E, P400ESHP, RAP300E,

RAP400E, RAPS300E, RAPS400E

Installation:

See rough-in drawings in this manual for di men sions and lo ca tions of

electric and water input.

Set-Up/Position

1) Remove the brewer from the packing material and attach its legs.

2) Position the brewer on a strong, stable table or counter. Check

the level front to back and side to side. Adjust the legs to the cor-

rect level.

IMPORTANT:

THE PERSON INSTALLING THIS APPLIANCE IS RESPONSIBLE

FOR ENSURING THAT ELECTRIC AND WATER CONNECTIONS

MEET THE RE QUIRE MENTS OF THE NATIONAL ELECTRIC

CODE, NATIONAL PLUMBING CODE, AND ANY LOCAL

ORDINANCES.

The electric and water hook-up locations are behind the front pan el.

Re move the four screws fastening this panel for access to these

con nec tions.

Table of Contents

Installation and Start-up ....................................... 1-2

Warning Labels ...........................................................3

Operation .......................................................... 4

Adjustments ........................................................ 5-8

Care and Cleaning ............................................... 9-10

Service ............................................................... 10-11

Troubleshooting

Filling Problems ....................................... 12

Heating Problems ................................. 13

Brewing Problems ................................ 14

Parts Illustrations

Models P300E & P400E ....................... 15

Model P400ESHP .....................................16

Model RAP400E ..................................... 17

Model RAPS400E ................................... 18

VSB-400................................................ 19

Shuttle CS-LL .......................................... 20

Rough-In Drawings

Model P300........................................................... 21

Model P400 & P400ESHP ...................... 22

Model RAP300 ......................................... 23

Model RAP400 ........................................ 24

Model RAPS300 ....................................... 25

Model RAPS400 ..................................... 26

VSB-300 .................................................. 27

VSB-400 ................................................ 28

Wiring Diagrams

P300E/P400E with 1 Batch Timer ......... 29

P300E/P400E with 2 Batch Timer........ 30

RAP300E/RAP400E................................31

RAPS300E/RAPS400E........................32

P400ESHP ...........................................33

Drawing #091-548 .................................34

Drawing #091-182 .....................................35

Water Hook-up

1) The water line may enter through holes on the rear or the bottom of the brewer. Use the right hand opening for water.

2) Use 3/8" copper or flexible water line to prevent strain. Do not use low temperature plastic tubing. The connection

to the fill valve is 3/8" flare.

3) Water line pressure must be from 30 to 70 psi.

4) Hot (up to 160°F) or cold water may be used. Hot water offers faster recovery between brews.

5) Install a shut-off valve near the brewer.

6) Installing a filtering system can improve the taste of brewed coffee and extend the life of the brewer. If your water

has high calcium (lime), chlorine, or iron content, this is especially important. The filter should be the lime inhibiting

type if cold water is used. Contact your local water treatment professional regarding the type of filter you should use

based on water quality and volume of water used.

PRINTED IN U.S.A.

0307 FORM # AM-309-08

Part # 090-077

Prior authorization must be obtained from Grindmaster Corporation for all warranty claims.

Grindmaster Corporation

4003 Collins Lane

Louisville, KY 40245 USA

(502) 425-4776

(800) 695-4500 (USA & Canada only)

(800) 568-5715 (Technical Service Only)

FAX (502) 425-4664

www.grindmaster.com

WARNING

ELECTRIC SHOCK HAZARD!

Installation of this appliance should be performed by

qualified service per son nel only. Improper installation

could result in elec tro cu tion.



Page 2

Shuttle Brewers & Airpot/Shuttle Brewers

Installation (con't)

Electric Hook-up

1) The electric ratings for your brewer are printed on its nameplate. Typical electric ratings

are:

P300, P400, RAP300, RAP400

Optional 120/208V, 3.8kW, 18A or 120/240V 5.0kW, 21A, 1 phase

Standard 120/208V, 5.0kW, 24A or 120/240V 6.6kW, 28A, 1 phase

RAPS300, RAPS400

Standard 120/208V, 4.4KW, 21A or 120/240V, 5.6KW 24A, 1 phase

P400ESHP

Standard 440V, 12.5KW, 16.3A, 3 phase WYE

If the brewer includes the three heater tank option C21A, the ratings will be different. Always

see the nameplate for correct ratings.

2) The brewer should be connected to its own circuit with a fused disconnect switch or a

circuit breaker near the brewer.

3) Attach the appropriately sized cord to the brewer with a cord grip for the 1 1/2" electric input

opening. The cord may enter through the rear or bottom on the left side of the brewer. Use

an oil resistant cord such as type SO, SOO, SAO, STOO, SEO, SJO, SJOO, SJTO, SJTOO,

SJEO, HSO, HSOO, HSJO, or HSJOO. Alternatively, flexible conduit and type THHN wires

may be used. Use only copper conductors.

4) Standard connection is 1 phase 3 wire. Connect the two lines to L1 and L2 on the terminal

block. If the brewer is wired for three phase, a lug, L3, is provided on the terminal block. A

neutral line must be connected to the N terminal.

5) The body of the brewer must be grounded. A ground lug is provided for this purpose.

Start-up

1) Turn on the water supply to the brewer. Check for leaks.

2) Turn on the electric supply. The brewer will begin to fill.

3) Replace the front access panel.

4) Once the brewer is full, it will take 15 to 35 minutes to heat. The water hot light will turn on

when up to temperature.

5) Insert the brew baskets and place a shuttle or airpot under the baskets. Brew at least one

batch from each side. Check the level in the container to be sure the brew volume is correct.

Remember that when using coffee, the level will be lower. Do this for both batch sizes when

provided. The water must be hot to check the levels. If adjustments are needed, see the

adjustments section of this manual.

WARNING

Never use the ground conductor as a neutral. This could cause electrocution.


