Side 1/4

Batteries: If the Base Station batteries are low, the Base

Station will beep every 30 minutes. The AA batteries

in the Motion Sensor will last up to 2 years depending

on use (Lithium batteries are recommended for colder

environments). If the Motion Sensor batteries are low, the

Base Station will beep every 30 minutes until the batteries

are replaced. The Motion Sensor will continue to operate

with a low battery, however the light will not illuminate. For

peak performance, inspect batteries annually and replace as

needed.

Programming Additional Motion Sensors: The Base Station

can learn the code of up to 7 additional Motion Sensors,

responding with unique buzzes. To program additional

Motion Sensors see Step 4.

To order additional Motion Sensors call 1-800-528-9131.

Clear Memory: Press and hold the Learn Button on the Base

Station until 3 beeps are heard.

On/Off: To turn the Base Station on and off, hold down the

power button until you hear the on/off tone.

Volume: The Base Station is equipped with adjustable

volume controls. The lowest volume setting is the mute

feature.

Carton Inventory

Antenna

On/Off Button

Volume

BASE STATION

Operation and Features

Overview

The Wireless Motion Detection System uses a Passive Infra-Red (PIR) Motion Sensor to detect movement of people and vehicles.

The Base Station is powered by the DC adapter and the 4 AA batteries supply power in case of a power outage.

NOTE: The Base Station is intended for indoor use only.

Wireless Motion Detection System

Models CWA2000 and CWA2000C

Base Station Motion Sensor

Rubber Pads

Mounting Plate

DC Adapter

(9 Vdc @ 200mA) Sun/Rain Shield

Swivel bushing

WARNING: This product can expose you to chemicals including lead, which are known to the State of California to cause cancer

or birth defects or other reproductive harm. For more information go to www.P65Warnings.ca.gov

Antenna

OFF

1 2

SWITCH SETTINGS

Switch #1 Switch #2

Learn Button

OFF Low Sensitivity

ON High Sensitivity (Default)

OFF 15 Feet (4.5 m) Detection Range

ON 30 Feet (9.1 m) Detection Range

(Default)

NOTE: To avoid detection of small animals move Switch #2

to OFF.

Assembly and Programming

Attach Motion Sensor box to

mounting plate with large silver

screw. Tighten screw until

Motion Sensor stays in place

when repositioned.

Install 4 AA Alkaline

batteries. (Lithium batteries

recommended for colder

environments.)

LED light will ﬂash.

Plug in the Base Station.

Adhere rubber pads to the

bottom of the base.

4 AA batteries are optional in

case of a power failure. OPTIONAL

DC Adapter Input

A Ensure Base Station and

Motion Sensor are in close

proximity to each other.

Press and release Learn

Button on Base Station.

Buzzer will sound.

B Within 60 seconds, press the

Learn Button on the inside

of the Motion Sensor. LED

light will illuminate and Base

Station will buzz.

Learn Button

Motion Sensor

SWITCH #1:

SWITCH #2:

4Learn Button

Insert battery pack facing away

from circuit board and fasten

cover with the smallest screws

(provided).

NOTE: Ensure the batteries do

not touch the circuit board and

the antenna and battery wires

are not pinched.

MOTION SENSOR INSTALLATION

Mount Motion Sensor

horizontally on solid surface

3-5 feet (1-1.5 m) off the

ground and within 1/2 mile

(0.8 km) of Base Station (rotate

sensor to access screw holes).

Unit should be able to swivel as

needed.

Attach sun/rain shield.

NOTE: Keep Motion Sensor

antenna away from metal

objects. Do not mount Motion

Sensor in direct sunlight, near

moving tree branches, or in the

path of a sprinkler system.

4 feet (1.2 m)

10-20 feet (3-6 m)

Vehicle Alert Installation: For cars, the best mounting

position is about 4 feet (1.2 m) high, between 10-20 feet

(3-6 m) back, and angled to see the back of car after passing

the sensor.

Test Motion Sensor by waving

hand in front of sensor. LED

light should ﬂash and the Base

Station will buzz X number of

times indicating which sensor

has been activated.
