MultiBoard

G81-7040/-8040/-7043/-8043

1 Advantages of the keyboards

• Cherry FTSC key technology

• Robust and reliable

• Programmable keys

• Magnetic card reader (G81-7040/-8040 only)

• EMV 2000-approved PC/SC chip card reader

• OPOS and JavaPOS support

• Client/server support

•Cherry Tools software for programming and

configuration

1.1 Status indicators

The left and center LEDs show the status of the

locked-key function of the Num and Caps keys.

The right LED illuminates green when the chip card

reader is ready for operation. It flickers red while

data is being sent from/to the chip card reader.

2 Connection of the keyboard

¾Insert the USB plug into any USB port on your

PC.

3 Installation of the software

Current software on the Internet

The software is continually updated. The current

version can be obtained on the Internet at:

http://support.cherry.de

1 Place the CD in your CD-ROM drive.

The CD-ROM starts automatically.

2 If the CD-ROM does not start automatically,

double-click the CD-ROM drive in Windows

Explorer and then the Start.exe file.

3 Follow the installation instructions on the screen.

3.1 Cherry Tools

The following functions are supported:

• Programming of keys

• Configuration of the keyboard

• Activation and configuration of the magnetic

card reader

3.2 Cherry Tools Runtime

Distributes existing configurations to other systems

(e.g. keyboard and magnetic card settings.) No

additional applications are installed beside the

drivers required for operation.

¾Read the installation instructions on the

accompanying CD-ROM.

3.3 Cherry OPOS/JavaPOS support

If you use applications which access the keyboard

or magnetic card reader via OPOS or JavaPOS:

Windows operating system

¾Install the Cherry OPOS Support or Cherry

JPOS Support software.

Linux operating system

¾Use the installation scripts for JavaPOS support

on the CD-ROM in the

Software\JavaPOS\Linux directory.

Operating Instructions

644-0426.00 US Okt 2005

3.4 Software for the chip card reader

¾Install the drivers of the chip card reader for the

PC/SC interface (1.0) via the Hardware

Assistant.

For additional CT-API support (MKT 1.0) and home

banking:

¾Run Cherry SmartDevice Setup.

4 Programming of keys and

magnetic card reader

The configuration of all functions can be done via

software macros. This means that the configuration

is not saved in the keyboard, but rather as a file on

the PC.

¾Install the Cherry Tools software.

You can configure all the functions of the

keyboard with the Designer found within the

software.

Operation is described in the direct help of the

Cherry Tools software. It provides you with

information where you need it and is called up

via F1.

5 Magnetic card reader

(G81-7040/8040 only)

The functions of the magnetic card reader are

available when one of the following Cherry

software packages has been installed:

•Cherry Tools

•Cherry Tools Runtime

•Cherry OPOS support

•Cherry JavaPOS support for Windows

•Cherry JavaPOS support for Linux

The magnetic card reader is able to read the tracks

individually, in pairs or all at once. Decoding of the

read data is carried out via software.

Definition of header and terminator:

• Header and terminator identify the start and end

of the transfer of magnetic card data. The

header/terminator code is inserted before/after

the actual magnetic card data.

Using the magnetic card reader

1 Insert magnetic card into the magnetic card

reader on the right with the magnetic strip facing

downwards and towards the keyboard.

2 Swipe magnetic card through the magnetic card

reader to the left.

An audible tone confirms a valid reading. (This

signal can be deactivated via the software.) The

data is transferred.

6 Chip card reader

The integrated chip card reader is available

after you have installed the software. It reads and

writes to all chip cards conforming to

DIN ISO 7816-1/2/3/4.

¾Insert the chip card into the chip card slot with

the chip facing downwards and towards the

keyboard.

After a discernable pressure point has been

passed, contact takes place.

7 RSI syndrome

RSI syndrome

RSI stands for "Repetitive Strain Injury". RSI arises

due to small movements continuously repeated

over a long period of time.

Typical symptoms are discomfort in the fingers or

neck.

1 Set up your workspace for maximum ergonomic

benefit.

2 Change the angle of the keyboard using the rear

supports.

3 Take several short breaks, with stretching

exercises if necessary.

4 Change the position of your body often.

8 Disposal

Dispose of the old unit via a

collecting point for electronic scrap or

via your dealer.
