Side 1/7

DSM2-6mkII

DIGITAL SPEAKER MANAGEMENT

170.659UK

Features

 96kHz sampling frequency, 32-bit A/D and D/A converter, 24-bit DSP processor

 Input channel: 6-band parametric EQ, Delay, Polarity

 Output channel: Signal select, 6-band parametric EQ, Gain, Delay, Polarity, Crossover, Limiter

 Built-in USB and RS485 com ports

 Program funcon, recall and copy

 30 internal user programs

 Password protecon

Introducon

Thank you for purchasing this high quality Citronic digital speaker management system. The aim of our audio

processing range is to oer cost-eecve, high performance sound sculpng tools for live sound

reinforcement and installaon applicaons. The Citronic DSM2-6 oers a comprehensive and professional

speaker management soluon delivering unsurpassed sound quality.

The DSM2-6 comprises a 2 input, 6 output digital sound processor with fully assignable high and low pass

crossover lters on each output for low or high frequency outputs or in combinaon for mid frequency

output. Each lter can be assigned as Buerworth, Linkwitz-Riley or Bessel type across various cut-o slopes

to give ulmate exibility.

Each input channel has gain and phase correcon and 6 bands of independent parametric or shelving EQ to

tailor the input tone.

Each output channel has 6 bands of independent parametric EQ for tone shaping and to compensate for

room or speaker anomalies. Also, each output has me alignment delay and adjustable limiter to protect the

outputs from overloading.

In addion to the user-friendly front panel menus, all funcons may be manipulated and stored via USB using

the included PC soware. A graphic interface allows quick and easy adjustment of all the main parameters.

Further slave DSM2-6 units can be linked via RS485 connecon (RJ45)

Signal connecon is XLR throughout, balanced or unbalanced and each output may be addressed from either

input A or B or A+B combined.

The internal memory can store up to 30 user programs and each can be named for easy idencaon. Each

can be recalled at will and the unit can be password protected to lock out the funcons to unauthorized

persons.

This unit has been built to Citronic’s exacng standards using high grade circuit boards and components

housed in a heavy duty steel chassis casing to give long term, reliable service.

Installaon

Set the DSM2-6 into a 1U space in a rack, ensuring enough depth to contain the unit and any connectors

aached to it. Secure the front panel with rack screws and nuts to hold in place and stop the unit slipping.

Plug the included power cable into the rear panel IEC connector and connect to the mains. Be sure to switch

the DSM2-6 on before switching on the power ampliers to avoid loud thumping sounds through the

speakers and switch the ampliers o before switching o the DSM2- 6.

Connecon to each channel is served by XLR for both inputs and outputs.

For balanced connecons, follow the table below.

Connecon

XLR connector

Hot (+)

Pin 2

Cold (-)

Pin 3

Earth

Pin 1

For unbalanced connecons, follow the table below.

Connecon

XLR connector

Signal (Hot)

Pin 2

Earth (Cold)

Pin 1 + 3
