Side 1/5

CEQ215 / CEQ231

Graphic Equalizers

Order ref: 170.923UK / 170.926UK

User Manual

Features

 Switchable Bypass per channel

 Switchable Low Cut filter per channel

 Independent Gain controls

 ±12dB adjustment per band

 Balanced or unbalanced signal path

 LED VU display per channel

2 170.923UK, 170.926UK User Manual

Caution: Please read this manual carefully before operating

Damage caused by misuse is not covered by the warranty

Introduction

Thank you for choosing a Citronic equalizer unit. This product has been designed to deliver professional tone-

shaping facilities with reliable and accurate function. In order to achieve the best results from this equipment

and avoid damage through misuse, please read and follow these instructions and retain for future reference.

Warning

To prevent the risk of fire or electric shock, do not expose any part of the unit to rain or moisture.

If liquids are spilled on the surface, stop using immediately, allow unit to dry out and have checked by

qualified personnel before further use.

Avoid impact, extreme pressure or heavy vibration to the unit.

There are no user serviceable parts inside the equalizer– refer all servicing to qualified service personnel.

Safety

 Check that the supplied mains lead is in good condition and the supply voltage is correct.

 Ensure signal leads are of good condition and connected to appropriate inputs/outputs

 Do not allow any foreign particles to enter the console through slider or connector apertures

Placement

 Keep out of direct sunlight and away from heat sources.

 Keep away from damp or dusty environments.

 When rack-mounting, avoid placing heavy units above the unit and ensure all connectors are accessible

Cleaning

 Use a soft cloth with a neutral detergent to clean the casing as required

 Use a soft brush to clear debris from the control surface

 Do not use strong solvents for cleaning the unit.

Produkt Specifikationer

Mærke:	Citronic
Kategori:	DJ Gear
Model:	CEQ231
Vekselstrømsindgangsspænding:	115-230 V
Vekselstrømsindgangsfrekvens:	50 - 60 Hz
Bredde:	482 mm
Dybde:	88 mm
Højde:	139 mm
Vægt:	3300 g
Produktfarve:	Sort
Equalizer:	Ja
Strømforbrug (typisk):	- W
Frekvensområde:	20 - 20000 Hz
LED-indikatorer:	Ja
Equalizerbånd, antal:	31
klirfaktor (THD):	0.005 %
Antal kanaler:	2 kanaler
Stativ-montering:	Ja
Output impedans:	330 ohm (Ω)
Indgangsimpedans:	40 ohm (Ω)
Rackkapacitet:	2U
Liniesignal-til-støjforhold (SNR):	102 dB
Inputbehandling:	Lavt snit
