1.
Select a desired station in Radio Mode for
waking up, press the POWER OFF button to
enter the Clock Mode.
2. To enter the alarm screen and to adjust the alarm
time: Press and hold the ALARM SET button and
press the HOUR & MIN buttons repeatedly. See its
diagram on the right.
3. After finish setting, release the ALARM SET button.
4. To turn the alarm on, press the ALARM ON/OFF
button, the alarm on icon‘ ’appears on the LCD,
see its diagram on the right.
5. To cancel the alarm function, press the ALARM
ON/OFF button a g a i n , t h e alarm on icon ‘ ’
disappears on LCD.
1. Remove the battery compartment cover.
2. Load 2 "AAA”( UM-4) size batteries into the
Battery Compartment, making sure that the
batteries are installed in the designated
numerical order and that the proper polarities
(+ and -) are maintained.
To prevent possible damage to this unit:
Load new batteries with their polarities ( + and -) aligned
correctly.
Do not apply heat to batteries, or internal short-circuit may
occur.
If this unit is not to be used for a long period o f time ,
remove all batteries and store them in a cool and dry
place.
Remove spent batteries and dispose of them properly.
Do not use old and new batteries together. Also never use
an alkaline battery with a manganese battery.
Battery life
If the sound become low or distorted, replace all the batteries
with new ones.
Operating
Instructions
1. Power OFF
2. Alarm ON/OFF
3. Time Set
4. Alarm Set
5. AM Power ON
6. FM Power ON
7. MIN
8. HOUR
9. Volume Dial
10. Tuning Dial
11. LCD
12. Tuning Indicator
13. Telescopic Antenna
14. Earphone Jack
15. Speaker
16.
CX50
DIGITAL DISPLAY MINI AM/FM RADIO
11214 13
15
16
23
4 5 6
7
8
11
9
10
Battery Compartment
(On the rear of the radio)
2. Tune in the desired station by turning the Tuning Dial.
The LCD shows the frequency.
3. Adjust the volume to a comfortable listening level by
turning the Volume Dial.
4. Adjust the antenna (See ANTENNA section).
5. Press the Power Off button to turn off the radio.
102.9
MHz
FM
12:21
PM
1. Press AM/FM button to turn on the AM/FM
radio and to enter its screen.
When it’s in Radio Mode, press the POWER OFF
button to enter the Clock Mode. See its diagram
on the right.
Press and hold TIME SET button and press the
HOUR & MIN buttons repeatedly to adjust the
hour and minute. After finish setting, release the
Time Set button.
6:21
PM
AL-SET
6:21
PM
AL-SET
POWER SOURCE
BATTERY OPERATIONS
RADIO OPERATIONS
CLOCK FUNCTIONS
WAKE UP TO RADIO BROADCAST
TO SET THE ALARM TIME
