INSTALLATION AND OPERATION MANUAL

RLFDX232 Series

SUBSTATION-RATED RS-232 & TTL LOGIC DATA

LINK/REPEATER FOR REPLACEMENT OF

GARRETTCOM/DYMEC 5843 & 5844 SERIES

The ComNet

™

RLFDX series of serial data link/repeaters are substation-rated and

industrially hardened form, fit, function and completely backwards-compatible

replacements for the popular Garrettcom/Dymec 5843 & 5844 series of RS-232

serial data link/repeaters. They are designed for deployment in environments where

high levels of electromagnetic noise and interference (EMI) and severe voltage

transients and surges are routinely encountered, such as electrical utility substations

and switchyards, heavy manufacturing facilities, trackside and roadside electronic

equipment, and other difficult out-of-plant applications. Optical connectivity provides

significantly extended transmission distances compared to copper media; high levels

of electrical isolation; enhanced reliability and protection for peripheral IEDs, RTUs,

and other equipment; and operational safety.

The RLFDX series of serial data link/repeaters are easily field-configurable for point-

to-point, point-to-multipoint/Local-Remote, loop, or bus topologies. They may be also

used for electrical data protocol translation: an RLFDX232-series RS-232 modem and

IED/RTU can communicate directly with an RLFDX485-series RS-422/RS-485 modem

and IED/RTU.

The extremely versatile and simple-to-install RLFDX series is ideal for any mission-

critical application where very high levels of reliability and network availability are of

the utmost importance.

Rev. 3.17.15

This manual serves the following

ComNet Model Numbers:

RLFDX232M2/24DC

RLFDX232M2/HV

RLFDX232M2/48DC

RLFDX232S2/24DC

RLFDX232S2/HV

RLFDX232S2/48DC

INS_RLFDX232_REV–

12/20/12 PAGE 2

INSTALLATION AND OPERATION MANUAL RLFDX232 SERIES

TECH SUPPORT: 1.888.678.9427

Contents

FCC/CE Regulation 4

Warranty 4

Disclaimer 4

Safety Information 4

ComNet / Garretcom Interoperability / Compatibility Listing 5

Warnings, Cautions, and Notes Used in this Publication 6

1. Introduction 7

1.1 Definitions 8

1.2 Model RLFDX232 Series Link/Repeaters 11

1.2.1 9 Pin Data Port D-connector 13

1.2.2 DTE/DCE Switch (Two Position Switch) 13

1.2.3 Data Coupling Switch 13

1.2.4 Repeat Switch 14

1.2.5 Handshaking Switch 4B 14

1.2.6 Pin 8 Current Output Option Switch 5B 14

1.2.7 Test Mode Option Switch 3B 15

1.2.8 Optical Ports 15

1.2.9 Diagnostic LEDs 16

1.2.10 Power Connections 16

1.2.10.1 Powering the 24DC Models 16

1.2.10.2 Powering the 48DC Models 17

1.2.10.3 Powering the HV Models 17

1.2.11 Peripheral Equipment 18

1.2.11.1 IED 18

1.2.11.2 Fiber Optic Cable (FOC) 18

2. Configurations, Operation, and Installation 19

2.1 Point-To-Point Configuration 20

2.1.1 Installation 21

2.2 LOOP OPERATION - Local/Remote CONFIGURATION 22

2.2.1 Installation 24

2.3 Loop Operation - Peer-To-Peer Configuration 25

2.3.1 Installation 27

3. Applications 28
