INSTALLATION AND OPERATION MANUAL

RLFDX485 Series

SUBSTATION-RATED RS-422 & RS-485 DATA

LINK/REPEATER FOR REPLACEMENT OF

GARRETTCOM/DYMEC 5845 & 5846 SERIES

The ComNet

™

RLFDX series of serial data link/repeaters are substation-rated and

industrially hardened form, fit, function and completely backwards-compatible

replacements for the popular Garrettcom/Dymec 5845 & 5846 series of RS-422 and

RS-485 serial data link/repeaters. They are designed for deployment in environments

where high levels of electromagnetic noise and interference (EMI) and severe voltage

transients and surges are routinely encountered, such as electrical utility substations

and switchyards, heavy manufacturing facilities, trackside and roadside electronic

equipment, and other difficult out-of-plant applications. Optical connectivity provides

significantly extended transmission distances compared to copper media; high levels

of electrical isolation; enhanced reliability and protection for peripheral IEDs, RTUs,

and other equipment; and operational safety.

The RLFDX series of serial data link/repeaters are easily field-configurable for point-

to-point, point-to-multipoint/Local-Remote, loop, or bus topologies. They may be also

used for electrical data protocol translation: an RLFDX232-series RS-232 modem and

IED/RTU can communicate directly with an RLFDX485-series RS-422/RS-485 modem

and IED/RTU.

The extremely versatile and simple-to-install RLFDX series is ideal for any mission-

critical application where very high levels of reliability and network availability are of

the utmost importance.

Rev. 4.7.15

This manual serves the following

ComNet Model Numbers:

RLFDX485M2/24DC

RLFDX485M2/HV

RLFDX485M2/48DC

RLFDX485S2/24DC

RLFDX485S2/HV

RLFDX485S2/48DC

INS_RLFDX485_REV–

12/20/12 PAGE 2

INSTALLATION AND OPERATION MANUAL RLFDX485 SERIES

TECH SUPPORT: 1.888.678.9427

Contents

FCC/CE Regulation 4

Warranty 4

Disclaimer 4

Safety Information 4

ComNet / Garretcom Interoperability / Compatibility Listing 5

Warnings, Cautions, and Notes Used in this Publication 6

1. Introduction 7

1.1 Definitions 8

1.2 RLFDX485(M,S)2/24DC Link/Repeaters 11

1.2.1 9 Pin Data Port D-connector 13

1.2.2 Switch Settings 13

1.2.3 HD / FD Switch 14

1.2.4 Repeat Switch 14

1.2.5 Logic Inversion Switch 14

1.2.6 Input Bias Switch 14

1.2.7 Input Data Coupling Switch 15

1.2.8 Enable Holdover Switch 15

1.2.9 Test Mode Option Switch 16

1.2.10 Optical Ports 16

1.2.11 Diagnostic LEDs 17

1.2.12 Power Connections 17

1.2.12.1 Powering Models RLFDX485(M,S)2/24DC 17

1.2.12.2 Powering Models RLFDX485(M,S)2/48DC 18

1.2.12.3 Powering Models RLFDX485(M,S)2/HV 18

1.2.13 Peripheral Equipment 19

1.2.13.1 IED 19

1.2.13.2 Fiber Optic Cable (FOC) 19
