INSTALLATION AND OPERATION MANUAL
RLFDX485 Series
SUBSTATION-RATED RS-422 & RS-485 DATA
LINK/REPEATER FOR REPLACEMENT OF
GARRETTCOM/DYMEC 5845 & 5846 SERIES
The ComNet
™
RLFDX series of serial data link/repeaters are substation-rated and
industrially hardened form, fit, function and completely backwards-compatible
replacements for the popular Garrettcom/Dymec 5845 & 5846 series of RS-422 and
RS-485 serial data link/repeaters. They are designed for deployment in environments
where high levels of electromagnetic noise and interference (EMI) and severe voltage
transients and surges are routinely encountered, such as electrical utility substations
and switchyards, heavy manufacturing facilities, trackside and roadside electronic
equipment, and other difficult out-of-plant applications. Optical connectivity provides
significantly extended transmission distances compared to copper media; high levels
of electrical isolation; enhanced reliability and protection for peripheral IEDs, RTUs,
and other equipment; and operational safety.
The RLFDX series of serial data link/repeaters are easily field-configurable for point-
to-point, point-to-multipoint/Local-Remote, loop, or bus topologies. They may be also
used for electrical data protocol translation: an RLFDX232-series RS-232 modem and
IED/RTU can communicate directly with an RLFDX485-series RS-422/RS-485 modem
and IED/RTU.
The extremely versatile and simple-to-install RLFDX series is ideal for any mission-
critical application where very high levels of reliability and network availability are of
the utmost importance.
Rev. 4.7.15
This manual serves the following
ComNet Model Numbers:
RLFDX485M2/24DC
RLFDX485M2/HV
RLFDX485M2/48DC
RLFDX485S2/24DC
RLFDX485S2/HV
RLFDX485S2/48DC
INS_RLFDX485_REV–
12/20/12 PAGE 2
INSTALLATION AND OPERATION MANUAL RLFDX485 SERIES
TECH SUPPORT: 1.888.678.9427
Contents
FCC/CE Regulation 4
Warranty 4
Disclaimer 4
Safety Information 4
ComNet / Garretcom Interoperability / Compatibility Listing 5
Warnings, Cautions, and Notes Used in this Publication 6
1. Introduction 7
1.1 Definitions 8
1.2 RLFDX485(M,S)2/24DC Link/Repeaters 11
1.2.1 9 Pin Data Port D-connector 13
1.2.2 Switch Settings 13
1.2.3 HD / FD Switch 14
1.2.4 Repeat Switch 14
1.2.5 Logic Inversion Switch 14
1.2.6 Input Bias Switch 14
1.2.7 Input Data Coupling Switch 15
1.2.8 Enable Holdover Switch 15
1.2.9 Test Mode Option Switch 16
1.2.10 Optical Ports 16
1.2.11 Diagnostic LEDs 17
1.2.12 Power Connections 17
1.2.12.1 Powering Models RLFDX485(M,S)2/24DC 17
1.2.12.2 Powering Models RLFDX485(M,S)2/48DC 18
1.2.12.3 Powering Models RLFDX485(M,S)2/HV 18
1.2.13 Peripheral Equipment 19
1.2.13.1 IED 19
1.2.13.2 Fiber Optic Cable (FOC) 19
