Side 1/2

Assembly Drawing

COUGAR Facebook

Power button

Reset button

USB 3.0 / USB 2.0

/ HD audio ports

Removable front panel

Tempered glass side panel

Tool-less screw

Tempered glass front panel

Vented slot cover

Power supply cover

3.5" HDD trays

(compatible with 2.5" HDD/SSD)

2.5" HDD/SSD trays

1 x 120mm fan for bottom panel

(optional, purchased separately)

2 x 140 / 3 x 120mm fans for top panel

(optional, purchased separately)

2 x 140 / 3 x 120mm fans for front panel

(3 x LED 120mm fans pre-installed)

Top panel

1 x 120mm fan for rear panel

(optional, purchased separately)

Slot side cover

Tempered glass top panel

Fan filters to prevent dust from

getting into the chassis

Specifications may vary based on different regions

For more information, please visit

Compucase Enterprise Co.,Ltd.

www.cougargaming.com

Made in China

Compucase Enterprise Co.,Ltd.

No. 225, Lane 54, An Ho Road Sec. 2 Tainan, Taiwan, R.O.C

Tel:+886-6-356-0606

Service E-Mail:service@cougargaming.com

COUGAR USA Technical Service

Tel: (833) 256-3778

Mail: rma@compucaseusa.com

https://cougargaming.com/support/contact/upload/

Middle Tower

3.5"：2

2.5"：4+2

(converted from 3.5" drive bays)

208mm x 565mm x 520mm

Mini ITX

Micro ATX / ATX

CEB

Max. 8

USB3.0 x 2

USB2.0 x 2

Mic x 1

Audio x 1

Motherboard Type

Dimensions (WxHxD)

Case Drive Bays

I/O Panel

Total Fan

7Expansion slots

Case Type

Front：LED 120mm x 3 (pre-installed) / 140mm x 2

Top：120mm x 3 / 140mm x 2

Rear：120mm x 1

Bottom：120mm x 1

Front：360/280/240/140/120mm

Top：360/280/240/140/120mm

Rear：120mm x 1

Bottom：120mm x 1

Standard ATX PS2

160mm

425mm

Water Cooling Support

Max. Graphic Card Length

Max. CPU Cooler Height

PSU

Cooling Fans

Front：120mm LED fan x 3 Fan Pre-installed

FEATURES

TEMPERED GLASS GAMING MID-TOWER

Panzer-G is the ideal case for everybody who wants both great functionality and

impressive aesthetics. Combining a transparent design covered in tempered glass

with plenty of space for your components and a well-thought pro-cooling structure,

this wonder is COUGAR's vision for the future of mainstream gaming PC cases.

TEMPERED GLASS GAMING MID-TOWER

•

4 Tempered Glass Covers (Front/Top/Left/Right)

•

Support for 4 Motherboard Form Factors (Mini ITX / Micro ATX / ATX / CEB)

•

Up to 3 Double-Slot 425mm Graphics Cards

•

Up to 8 Fans and 4 Water Cooling Radiators

ENGLISH

•

4 Abdeckungen aus Hartglas (vorne/oben/links/rechts).

•

Unterstützt 4 verschiedene Motherboard-Formfaktoren (bis E-ATX).

•

Bis zu 3 Doppelsteckplatz-425-mm-Grafikkarten.

•

Bis zu 8 Lüfter und 4 Flüssigkühler.

DEUTSCH

• 4 cubiertas de vidrio templado (frontal/superior/izquierda/derecha).

• Soporta 4 formatos diferentes de placa madre (hasta CEB).

• Hasta 3 tarjetas gráficas de doble ranura de 425mm.

• Hasta 8 ventiladores y 4 radiadores de refrigeración líquida.

ESPAÑOL

• 4 tampas de vidro temperado (frontal / superior / esquerda / direita).

• Suporta 4 formatos diferentes de placa-mãe (até CEB)

• Até 3 placas de vídeo de slot duplo de até 425mm de comprimento.

• Até 8 ventoinhas e 4 radiadores de resfriamento líquido.

PORTUGUÊS

• 4 боковые стенки из закаленного стекла

(спереди / сверху / слева / справа)

• Поддержка 4 различных форм-факторов материнской платы

(до CEB)

• До 3 видеокарт с двумя слотами длиной до 425 мм

• До 8 вентиляторов и 4 радиаторов водяного охлаждения

РУССКИЙ

• 4 couvercles en verre trempé (avant/supérieur/gauche/droite)

• Prise en charge pour 4 facteurs de forme du carte mère différents

(jusqu'à CEB)

• Jusqu'à 3 cartes graphiques à double fente 425 mm

• Jusqu'à 8 ventilateurs et 4 radiateurs de refroidissement par eau

FRANÇAIS

• 4 pannelli in vetro temperato

(Anteriore / superiore / sinistra / destra)

• Supporta 4 differenti tipi di schede madri (fino a CEB)

• Fino a 3 slot doppi per schede video da 425mm

• Fino a 8 ventole e 4 dissipatori a liquido.

ITALIANO

•

四面钢化玻璃侧盖(前/上/左/右)

•

支援4种规格尺寸的主机板(适用CEB最大尺寸)

•

支援3组高达425公厘的显卡双插槽

•

支援高达8个风扇和4个水冷散热器

中文

•

4面強化ガラスパネル採用（フロント・トップ・左右両サイド）

•

4種類のマザーボードフォームファクタ（最大CEBまで）に対応できます

•

最大3つのダブルスロットの425mmグラフィックスカードに対応できます

•

最大8つのファンと4つの水冷ラジエーターを搭載可能です

日本語

•

4 개의 강화 유리 커버 (앞 / 위 / 왼쪽 / 오른쪽)

•

4 가지 메인보드 폼 팩터 (CEB까지) 지원.

•

최대 3 개의 이중 슬롯 425mm 그래픽 카드

•

최대 8 개의 팬과 4 개의 수냉식 냉각기.

한국어

SUPERB DESIGN

You invest quite a lot of money in your PC components; it is now the time to see

them in their full glory. With four (front/top/left/right) tempered glass covers

and an attractively designed structure, Panzer-G brings PC case aesthetics to a

wholly new level.

LOADS OF SPACE

Panzer-G is not only gorgeous; it is also a future-proof case that will house

most of your current components as well as virtually anything you might want

to install in the future. Four different motherboard form factors (Mini ITX /

Micro ATX / ATX / CEB), up to three double-slot 425mm graphics cards and

loads of storage devices can fit into this marvelous case.

COOLING

To cool all your powerful components, Panzer-G supports up to eight fans and

four radiators for water cooling, while its internal structure minimizes cable clout

and helps airflow. Play without fear of overheating with Panzer-G!

This is not only a great looking and fully featured mid-tower; it is also a terribly

convenient way to house your computer. With tool-less removal of its four glass

covers, installing new components to keep your gaming rig up to date is easy and fast!

CONVENIENT

Produkt Specifikationer

Mærke:	Cougar
Kategori:	Ikke kategoriseret
Model:	Panzer-G
Type:	PC
Bredde:	208 mm
Dybde:	520 mm
Højde:	565 mm
Velegnet til:	Spil
Produktfarve:	Sort
Formfaktor:	Midi Tower
Antal USB 2.0-porte:	2
Antal USB 3.2 Gen 1 (3.1 Gen 1) type-A-porte:	2
LED-indikatorer:	Ja
Lydindgang:	Ja
Belysning:	Ja
Belysning placering:	Front
Lydudgang:	Ja
Antal understøttede HHD'er:	6
Antal 3.5" bays:	2
Understøttet motherboard, formfaktorer:	ATX, CEB, Micro ATX, Mini-ITX
Antal 2.5" bays:	4
Siderude:	Ja
Maksimal højde på CPU-køler:	160 mm
Maksimal længde på grafikkort:	425 mm
Understøttede HDD-størrelser:	2.5, 3.5 "
Frontventiler installeret:	3x 120 mm, 2x 140 mm
Understøttede diametre for frontventilatorer:	120,140 mm
Kapacitet for flydende nedkøling:	Ja
Øverste ventilatorer installeret:	3x 120 mm, 2x 140 mm
Kompatible væskekølere:	360mm / 280mm / 240mm / 140mm / 120mm
Understøttede størrelser på frontradiator:	120,140 mm
Understøttede størrelser på bagradiator:	120 mm
