Side 1/2
Supplied with carrying case, windscreen, two tie clips, and
viper grip clip.
Frequency Response :
20 Hz to 20 kHz
Sensitivity:
-40 dB re. 1 V/Pascal
Equivalent Acoustic Noise:
24 dBA SPL
Dimensions: .50” x .26” (12.7 mm x 6.6 mm)
Output Impedance
600 Ohms balanced for wired operation
1500 Ohms unbalanced for wireless
Overload Sound Level:
130 dB SPL @ 1% THD on 48 V Phantom
(dependent on transmitter for wireless)
Power Requirements :
Phantom: 6 to 50 Volts @ 4 mA
Wireless: 1.5 to 24 Volts 400 µA
300°
0°
330°
60°
30°
90°
120° 240°
270°
0
-5
-10
-15
-20
dB
Polar Response
COUNTRYMAN ASSOCIATES INC
EMW OMNIDIRECTIONAL
LAVALIER MICROPHONE
15 kHz
<
8 kHz
A world-favorite lavalier, the EMW delivers excellent sound with minimal clothing
noise, in a sleek, yet rugged, nearly waterproof design. That’s why the EMW
Lavalier has long been regarded as one of the best, most affordable workhorse
lavaliers on the market, which no audio kit should be without. From news
anchors and talk show guests to watersports documentaries and feature films,
Countryman EMW Lavaliers are ready for action.
Applications
The best mic for hiding under clothing in
film, theater, and TV production is also
an excellent general purpose lavalier
for churches, schools, interviews, and
news. The EMW’s immersability allows
use near water or in intense weather.
150°
180°
210°
Rugged and Reliable
The EMW is exceptionally resistant to
makeup, sweat, and moisture, and
is well-suited to use in hair or on the
body. The Aramid-reinforced cable
gives it world-class survivability.
Performance
The EMW delivers outstanding
sound quality, with very low rubbing
noise and an extremely uniform
omnidirectional pattern over a wide
range of frequencies. Choose from three
frequency responses: shelved for normal
lavalier use, peaked for use behind
clothing, or flat for miking instruments.
Tim Denmark / H2audiO hemmingshouse.com
Style
Designed with a small, sleek, classic
lavalier shape, the EMW is available
in five colors—Black, White, Light
Beige, Tan, and Cocoa. The EMW is
available with a wide assortment of
clips, including tie, double, magnetic,
and viper / vampire clips.
Frequency Response
20 50 100 500 1k 5k 10k 20 kHz200 2k
Peaked
Shelved
Flat
0
dB
+10
-20
-10
measured at 6 inches
Countryman Associates, Inc. 195 Constitution Drive, Menlo Park, CA 94025 US: (800) 669-1422 Intl: 650-364-9988 F: (650) 364-2794
sales@countryman.com For more information and warranty registration visit www.countryman.com Made in the United States.
Which response should I choose?
The EMW Lavalier is available in three frequency responses, all of which deliver audio quality
with exceptional warmth and smoothness.
• “F” Response: the attest possible curve for uncolored reproduction of audio sources such
as musical instruments or room ambient sounds.
• “S” Response: provides a smooth 6 dB “shelved up” curve between 2 kHz and 15 kHz to
compensate for lost facial reflections when the mic is used on the exterior of the body, as in
the typical lapel or tie-clip position. This is the standard “lavalier” frequency response.
• “P” Response: provides a sharp 12 dB “peaked” curve at 12 kHz to preserve sibilance and
intelligibility when the mic is hidden under clothing.
EMW Lavalier: Frequently Asked Questions
Which clip should I choose?
Countryman manufactures a wide variety of clips which increase the versatility of the EMW.
• The standard tie clip comes in black and white; both colors are provided with the EMW. This
lightweight plastic clip is a good choice for ties and lapels. The white clip can be colored with
a felt pen if a custom color match is necessary.
• The double tie clip can hold two EMW microphones for applications where low-prole
redundancy is important.
How water resistant is the EMW?
The EMW is very water resistant, designed for immersion in water down to one meter. The
stainless steel core and aramid-reinforced cable are coated in engineering polymers for
protection against a wide variety of liquids.
• The viper grip clip has two pins on the back and slides securely into cloth at any angle. The
clip is designed to hold the active side of the microphone a fraction of an inch away from the
back plate (A). The microphone’s inactive side (B) faces outward. Turning the active side of
the capsule into the surface of the clip in this way provides more protection from handling
noise and creates a boundary type effect. The viper grip is a good choice for discrete
placement on the inside or outside of clothing and is available in colors to match the EMW.
• The magnetic clip consists of two halves that can be placed on either side of a piece of cloth
and clamp together magnetically. The inner piece has a lanyard made of clear nylon line,
which can be hooked over a button to make retrieval easier. This clip is ideal for attaching
the mic to delicate materials where pins are inappropriate.
EMW in cola beverage.
B
A
