OPERATING and MAINTENANCE INSTRUCTIONS
Models: H137WSUA...D & H138WS18...D Series
Humidity Holding Hot Cabinet
5925 Heisley Road • Mentor, OH 44060-1833
Insulated
Hot Cabinets
FL-2355
Rev. 5 (11/15) Page 1 of 6
Call Toll-free: 877-CRES COR (273-7267) • Fax: 800-822-0393 • www.crescor.com
Model No. Volts Watts Amps Hertz Phase NEMA
H137WSUA12D*
H137WSUA5D*
H137WSUA6D*
H138WS185D*
H138WS1834D*
H138WS1816D*
120 2000 16.7 60 1 5-20P
H137WSUA12D208
H137WSUA5D208
H137WSUA6D208
H138WS185D208
H138WS1834D208
H138WS1816D208
208 2000 9.6 60 1 6-15P
H137WSUA12D240
H137WSUA5D240
H137WSUA6D240
H138WS185D240
H138WS1834D240
H138WS1816D240
240 2000 8.3 60 1 6-15P
*Model numbers ending in sufx 15A are 1500W, 12.5 Amps, 5-15P.
NOTE: The above model numbers are basic models.
They may include letters: E, L, M, P S, U. V, Z, HTor ending with and/or .
HOW TO INSTALL UNIT:
1. Place cabinet on level oor, in a well ventilated area.
2. Unpack and install inner pan slides parts.
3. Plug cord end into proper wall outlet.
Air is VERY HOT when door is opened.
WARNING
1. Push the switch on; the light will come on.
NOTE: The letters “LOTPR” (Low Temperature)
will show on the control panel until it
reaches 80°F (26°C).
2. Turn the control knob to show 220°F. Push the
knob to set the temperature. Run the unit for one
(1) hour.
3. Push the switch off the unit off and let cool.
4. Wipe the inside clean with detergent and hot water.
FIRST TIME OPERATION:
NOTE: A new cabinet needs to “burn off”
manufacturing oils and excess adhesive
before its rst use. Do NOT load food into
cabinet until this has been done!
HOW TO CHANGE FROM °C TO °F (if needed)
1. Push the switch on; the light will come on.
2. Push and hold the “SET” button and the button in
the lower left hand corner together for 5 seconds.
You are now entered into the menu.
3. Scroll over the”Unit” and change it to “C” , then
scroll to the “END”.
5925 Heisley Road • Mentor, OH 44060-1833
Call Toll-free: 877-CRES COR (273-7267) • Fax: 800-822-0393 • www.crescor.com
OPERATING and MAINTENANCE INSTRUCTIONS
Models: H137WSUA...D & H138WS18...D Series
Humidity Holding Hot Cabinet
Insulated
Hot Cabinets
FL-2355
Rev. 5 (11/15) Page 2 of 6
HOW TO HOLD:
No water is needed in pan.
1. Push the switch on; the light will come on.
NOTE: The letters “LOTPR” will show on the
control panel until it reaches 80°F (26°C).
2. Turn the “Hot Holding” control knob to
a
temperature between 140°F (60°C) to 220°F (104°C).
Push the knob to set the temperature.
3. Preheat the cabinet for 30 minutes.
NOTE:
Press the “Display” button to see the actual
temperature inside the cabinet.
HOW TO HOLD WITH HUMIDITY:
Fill water pan with 4 gallons (15 liters) of HOT water.
1. Push the switch on; the light will come on.
NOTE: The letters “LOTPR” will show on the
control panel until it reaches 80°F (26°C).
2. Turn the “Hot Holding” control knob to show 80°F.
(26°C.) to 220°F (104°C). Push the knob to set the
temperature.
3. Turn the “AquaTemp” knob to desired humidity
value setting. Push the knob to set the value
number.
4. Preheat the cabinet for 1/2 hour (30 minutes).
NOTE:
This cabinet operates with air temperature
priority. Humidity will only start after cabinet
is fully preheated. If cold or room temp water is
used, humidity build-up time will be longer.
"ON-OFF" SWITCH
"HOT HOLDING"
DIGITAL CONTROL
"AQUATEMP"
DIGITAL CONTROL
ON-OFF
LOW WATER LIGHT
HUMIDITY READING
ACTUAL CABINET
TEMPERATURE
DIGITAL CONTROL NOTES
*Press the “display” button to see the actual temperature
inside the cabinet (press again to shut off).
*Press the “display actual” button to see the
approximate relative humidity value (press again to shut
off).
*Small letters in upper right corners of the displays are:
Hot Holding control: “S” = setpoint temperature
“A” = actual temperature
AquaTemp control: “S” = setpoint reading
(in increments of 5)
“A” = approximate relative
humidity reading
NOTE: When the low water light is on, the “A”
numbers will not be close to an accurate
reading, and the water heater will not heat.
NOTE: These settings are based on laboratory condi-
tions and may differ from conditions at the
point of use. Experiment with the settings to
determine what is best for your application.
HOW TO TURN UNIT OFF:
Push switch off; light will go out.
