VECTOR CD1295 Series
Vector
™
Performance Loudspeaker – Dual 12” Bi-Ampli ed 3-Way Coaxial 90° x 45°
crestron.com
|
800.237.2041
> A space-efficient, professional performance loudspeaker for
large indoor spaces
> Dual 12” (305 mm) LF transducers for increased output and
improved pattern control
> Advanced coaxial transducer with 90° x 45° HF horn
> Available with HF horn rotated 90° for horizontal orientation
(model VECTOR CD1295-RH)
> Integrated HF compression driver with 3 inch (76 mm)
titanium diaphragm
> Delivers superior performance in combination with a
Crestron Avia
™
DSP
> Precisely tuned for accurate, uncolored sound reproduction
> Produces high intelligibility and natural sound quality for speech
and program material
> Achieves smooth bandwidth performance both within and
beyond the specified coverage pattern
> Uniform directionality affords consistent, targeted pattern control
> Capable of high SPLs without coloration or distortion
> Provides excellent cost-benefit compared to more
conventional designs
> 40° trapezoidal enclosure affords a clean, unimposing appearance
> Rugged yet light construction for easy, reliable installation
> Concealed M10 mounting points
> Yoke bracket or forged shoulder eyebolts available separately
> Neutrik
®
speakON
®
input and pass-through connections
Crestron
®
Vector
™
Performance Loudspeakers provide a professional
sound reinforcement speaker solution for large indoor spaces and venues.
Featuring a revolutionary coaxial transducer design complemented by
advanced Crestron Avia
™
digital signal processing, Vector loudspeakers
deliver exceptional intelligibility and natural sound quality for speech
reinforcement, foreground music, and multimedia presentation applications.
Compact, aesthetically-pleasing enclosures afford remarkable performance
in less space. A choice of sizes and coverage patterns is offered to address
the varying applications and room geometries found in auditoriums,
theaters, lecture halls, houses of worship, convention centers, hotel
ballrooms, sports facilities, night clubs, and public spaces.
The Vector CD1295 is a compact, trapezoidal speaker enclosure loaded
with one 2-way coaxial transducer plus a second dedicated low-frequency
transducer. The coaxial transducer is composed of a 12” (305 mm) LF driver
and a 90° x 45° HF horn with 3” (76 mm) diaphragm compression driver.
The second LF transducer is a 12” driver with enhanced low-frequency
performance. Advanced engineering and construction of the complete
speaker achieves a space-efficient design with high output capability and
consistent pattern control.
Its integrated coaxial transducer aligns the low-frequency and high-
frequency elements to produce precise transient response and uniform
directionality across the entire frequency range. The two 12” LF drivers
work together in a bi-amplified configuration to achieve an increase in
overall output and improved low-frequency pattern control.
Note: Specify model VECTOR CD1295-RH for applications requiring
the enclosure to be installed in a horizontal orientation. The VECTOR
CD1295-RH is assembled with its high-frequency horn rotated 90°.
Advanced Coaxial Transducer
The LF/HF transducer in the Vector CD1295 represents a revolutionary
advancement in coaxial speaker design. Its high-frequency horn features
a large 3 inch (76 mm) titanium diaphragm compression driver, which
operates at frequencies lower than typical, allowing the high-frequency
horn to smooth the response of the low frequency section to reduce
shadowing of the woofer by the horn. The woofer’s large radiating surface
works in conjunction with the high-frequency horn to improve directional
control at the lower end of the horn’s frequency range resulting in better
pattern control throughout the critical voice band. The large diaphragm
also allows the compression driver to produce higher sound pressure
levels without distortion to deliver incredibly clear and dynamic sound
quality for both speech and program material.
The complete coaxial transducer assembly employs a single neodymium
magnet with dual-gap geometry, which minimizes the spacing between
the compression driver and woofer voice coils. This integrated approach
virtually eliminates the delay between the two drivers, allowing a passive
crossover to be used to seamlessly blend the horn and woofer into a single
point source. The reduced demand on the internal crossover helps to
maximize efficiency and damping, and the use of a single neodymium
magnet reduces the speaker’s weight, size, and cost.
VECTOR CD1295 Series Vector
™
Performance Loudspeaker – Dual 12” Bi-Ampli ed 3-Way Coaxial 90° x 45°
crestron.com
|
800.237.2041
Dual Low-Frequency Drivers
The Vector CD1295 employs an innovative and unconventional bi-amplified
3-way configuration using dual 12” LF transducers. Relative to the coaxial
transducer, the dedicated LF transducer features increased excursion
capability below 100 Hz. The frequency range of both drivers overlaps
at precise levels to achieve a flat summed response, producing a higher
overall output level compared to a more traditional LF/MF/HF 3-way
system. The use of dual LF transducers also provides the benefit of
extending usable LF pattern control by over an octave, reducing acoustic
reflections in the room for better clarity and “projection.”
Crestron Avia
™
Digital Signal Processing
Every aspect of the Vector CD1295 is designed to take advantage of
the signal refining abilities of a
Crestron Avia DSP. Vector loudspeakers
and Crestron Avia processing work synergistically to produce a superior
speaker system tuned for accurate, uncolored reproduction of voice and
program signals. Precision signal processing is employed to accomplish
what can’t be done physically, strategically eliminating harsh-sounding
resonances caused by horn reflections while retaining every nuance of
the original signal.
Further refinements are employed to maximize transient response and
deliver smooth bandwidth performance both within and beyond the
speaker’s nominal coverage pattern. The result is an extremely natural
sounding speaker system with superior pattern control, improved
intelligibility, reduced listener fatigue, and higher gain before feedback.
Two channels of processing are employed to deliver an optimized signal to
each transducer.
Versatile Installation
The Vector CD1295 is particularly effective in systems where targeted
pattern control is desirable, including front of house, delay fill, and
foreground music applications. Its clean appearance and familiar format
facilitate acceptance by architects and interior designers, and the 40°
trapezoidal angle allows it to be mounted near walls or ceilings without
obstructing sight lines. Concealed M10 mounting points are included to
accommodate either an optional
yoke bracket or forged shoulder eyebolts
(each sold separately).
Note: Specify model VECTOR CD1295-RH for applications requiring
the enclosure to be installed in a horizontal orientation. The VECTOR
CD1295-RH is assembled with its high-frequency horn rotated 90°.
SPECIFICATIONS
Performance
LF Transducer: 12 inch (305 mm) woofer with 3 inch (76 mm) voice coil
and ceramic magnet
LF/HF Transducers: 12 inch (305 mm) woofer with 3 inch (76 mm) voice
coil, coaxial horn with 3 inch (76 mm) titanium diaphragm compression
driver, single neodymium magnet
Beamwidth: 90° x 45° nominal, available with horn rotated 90° for
horizontal orientation (model VECTOR CD1295-RH)
Impedance: 8 Ohms nominal (per section)
Frequency Range: 49 Hz to 19 kHz (+3/-10 dB)
Power Handling: LF: 350 Watts;
LF/HF: 400 Watts;
Based on the AES power handling of the transducers
Nominal Sensitivity:
LF: 98 dB;
LF/HF: 104 dB;
Measured at 1W/1m whole space using band limited pink noise
without processing
Nominal Maximum SPL:
LF: 129 dB peak, 123 dB continuous, at 350W/1m;
LF/HF: 136 dB peak, 130 dB continuous, at 400W/1m;
Without processing
Equalized Sensitivity: 98 dB at 1W/1m using an EIA-426-B signal
with processing
Equalized Maximum SPL:
LF: 133 dB peak, 127 dB continuous, at 350W/1m;
LF: 133 dB peak, 127 dB continuous, at 400W/1m;
With processing
Processing & Amplification
Digital Signal Processing: Requires processing using two output
channels of a Crestron Avia DSP, settings provided via model-specific
“Speaker Profiles” in the Crestron Avia Audio Tool software (SW-AAT)
Amplification: Bi-amplified, requires two channels of amplification
Recommended Amplifier Power: LF: 350 to 700 Watts at 8 Ohms;
LF/HF: 400 to 800 Watts at 8 Ohms
Connections
Input: (2) Neutrik NL4 speakON 4-pole chassis connectors;
Pins 1 +/–: LF speaker input and pass-through;
Pins 2 +/–: LF/HF speaker input and pass-through

Produkt Specifikationer

Mærke: Crestron
Kategori: Højttaler
Model: Vector CD1295-RH
